ENSURE THAT THE UNIT IS PROPERLY SUPPORTED
BEFORE PERFORMING ANY MAINTENANCE
OR REPAIR WORK. FOLLOW THE UNIT
MANUFACTURER'S RECOMMENDATIONS FOR
LIFTING AND SUPPORTING THE UNIT. USE PROPER
PERSONAL PROTECTIVE EQUIPMENT.
1. Using the properly-rated floor jack, lift the trailer
according to the manufacturer's recommendation.
2. Support framework in accordance with the
manufacturer's recommendation.
NOTE: The holes in the step selected for attaching
hardware are based on the application and the shape of
the vehicle's chassis. The step should protrude from the
vehicle a desired amount. The lip on the chassis into which
the screws are drilled varies in units, and this will require
users to decide which step holes for attaching hardware
are most appropriate. From a rigidity standpoint, the first
holes in front are the best. Similarly, in the back, more
stability is created the farther back the bolts are located.
But the location of the attaching holes depends on the
needs of the customer.
3. Loosely attach the step's rear bolts. Insert them in the
back hole of the step or another hole location depending
on application (Fig.1).
Fig.1
lci1.com 574-537-8900
Innolight Sliding
Electric Step
Installation and Owner's Manual
(For Aftermarket Applications)
4. Install the front brackets using the long bolts, washers
and nuts. Insert bolts into the third hole from the front or
another hole location depending on application. Tighten to
4 Nm (3 ft-lbs) (Fig.2).
Fig.2
5. Select rear channel fastening points at the structural
parts of the vehicle for which the manufacturer guarantees
the design will support the mechanical resistance to the
maximum loads of the step in addition to its own weight.
6. Place an insert (Fig.3) on the special attaching tool and
install in selected hole in the chassis.
Fig.3
4
CCD-0002550 Rev: 11.18.19
