Structure And Components; System Connection; Operation Steps - Provision ISR I1-325CS Manual

Structure and Components

Shield
IR Led
Lens
Bracket
Color Camera
AES Auto Electronic Shutter Switch (Auto)
BLC Backlight Compensation Switch (Auto)
AGC Auto Gain Control Switch (Auto)
AWB Auto White Balance Switch (Auto)
Video Cable:
Power Supply Socket
Video out

Operation Steps

Confirm that the power supply for the camera is correct;
1
Connect Power Supply Socket to the power supplier.
2
Connect "Video Out" of the camera to the monitor or
other video equipment (DVR) with a 75 ohm cable (RG59).
3

System connection

Video Cable
Use one camera and one monitor
1
2
Use Several Cameras and one Monitor
EN EN
Monitor
BNC
BNC
DC 12V
Monitor
Video Divider
MULTIPLEXER
DVR
VCN
