Structure and Components

Video Cable
1
2
Color Camera
AES Auto Electronic Shutter Switch (Auto)
BLC Backlight Compensation Switch (Auto)
AGC Auto Gain Control Switch (Auto)
AWB Auto White Balance Switch (Auto)
Video Cable:
Power Supply Socket
Video out

Operation Steps

Confirm that the power supply for the camera is correct;
1
Connect Power Supply Socket to the power supplier.
2
Connect "Video Out" of the camera to the monitor or
other video equipment (DVR) with a 75 ohm cable (RG59).
3

System connection

Lens
EN EN
BNC
Use one camera and one monitor
MULTIPLEXER
VCN
Use Several Cameras and one Monitor
Monitor
BNC
DC 12V
Monitor
Video Divider
DVR
4
