Summary of Contents for Casablanca Lanai
-
Page 2: Table Of Contents
• This fan is designed to be installed on an existing electrical outlet box. The outlet box must be UL Listed for ceiling fan installations, if it is not, a new box must be installed. Casablanca extension poles are available for sloped or high ceiling installations. -
Page 3: Mounting Recommendations
MOUNTING RECOMMENDATIONS Before mounting your Casablanca fan, read the following helpful recommendations. The location of the fan, air circulation, and fan size are all important factors to consider before installation. Location Ceiling fans have practical uses in almost every room in your home. We suggest you follow these mount- ing recommendations as you decide where to install your Casablanca fan. -
Page 4: Preparation Instructions
Unpacking: Before assembling and installing your ceiling fan, remove all parts from the shipping cartons and check them against the parts listed here. Before discarding packaging material, be certain that all parts have been removed. ALLEN SET SCREW ⁄ -20 x ⁄... -
Page 5: Fan Installation
Installing a New Ceiling Fixture Outlet Box If you do not have an existing fixture located where you wish to place your Casablanca fan, an approved ceiling fixture outlet box must be installed and wired. Warning: To reduce the risk of fire, electrical shock,... -
Page 6: Canopy Hardware
CANOPY HATCH Step 3. Thread the wires from the ceiling through the opening in the canopy gasket. Attach the canopy to the crossbar mounting bracket with three of the 8-32 x 2 long canopy screws and canopy lock washers. Using the screwdriver, tighten the screw firmly by hand only. -
Page 7: Canopy Hatch Installation
ANAI CANOPY HATCH INSTALLATION Step 6. Tuck the wires into the canopy with the wire nuts pointed upwards, so that the WHITE and BLACK wires are on opposite sides of the canopy and all wires are clear of the canopy opening. Step 7. -
Page 8: Blade Installation
ANAI BLADE INSTALLATION Step 10. Attach each blade to a blade holder securing it with the four blade screws provided. Using the screwdriver, tighten securely BLADE SCREW by hand only. (4 PER BLADE) BLADE BLADE HOLDER REMOVE SHIPPING BLOCKS Step 11. On the flywheel remove the five SHIPPING shipping blocks by unscrewing the screws. -
Page 9: 3-Speed Operation
PULL CHAIN SWITCH TROUBLESHOOTING Never Lubricate this Fan! The precision motor at the heart of your Casablanca fan features sealed bearings that are lubricated for life. Do not attempt to oil the motor. Changing Light Bulbs Be sure to turn power to the fan OFF at the wall switch or circuit breaker before changing light bulbs. - Page 10 761 C • P , CA 91768 ORPORATE ENTER RIVE OMONA : 888-CASA-1ST (227-2178) www.CasablancaFanCo.com ©C 2000 C • U.S. P OPYRIGHT ASABLANCA OMPANY ATENT ENDING RINTED IN...
