Summary of Contents for Casablanca III
-
Page 2: Table Of Contents
• This fan is designed to be installed on an existing electrical outlet box. The outlet box must be UL Listed for ceiling fan installations, if it is not, a new box must be installed. Casablanca extension poles are available for sloped or high ceiling installations. -
Page 3: Mounting Recommendations
MOUNTING RECOMMENDATIONS Before mounting your Casablanca fan, read the following helpful recommendations. The location of the fan, air circulation, and fan size are all important factors to consider before installation. Location Ceiling fans have practical uses in almost every room in your home. We suggest you follow these mount- ing recommendations as you decide where to install your Casablanca fan. -
Page 4: Preparation Instructions
PREPARATION INSTRUCTIONS Unpacking: Before assembling and installing your ceiling fan, remove all parts from the shipping cartons and check them against the parts listed here. Before discarding packaging material, be certain that all parts have been removed. ALLEN SET SCREW ⁄... -
Page 5: Fan Installation
Check the ceiling fixture outlet box to be sure that it is marked ‘Approved for ceiling fan mounting’ . If it is not, a new box must be installed. -
Page 6: Canopy Installation
• WHITE wire from fan to white NEUTRAL wire in ceiling fixture outlet box. Secure with wire nut. • BLUE wire and BLACK power wire from fan to BLACK power wire in ceiling outlet box. Secure with wire nut. CANOPY INSTALLATION... -
Page 7: Canopy Hatch Installation
Step 6. Install canopy hatch with the last canopy screw and lock washer. To do this, tilt the fan body away from the hatch opening. Using the screwdriver, tighten the screws firmly by hand only, Step 7. -
Page 8: Blade Installation
STRADA BLADE INSTALLATION Step 9. Attach the blades to the blade holders by first pressing the BADGE STYLE blade badge into the blade, then BLADE HOLDER installing the blade holder using the four blade screws provided for each blade. Using the screwdriver, tighten securely by hand. -
Page 9: 3-Speed Operation
Replace reverse switch assembly; replace PCB assembly; or replace motor unit. FAN WILL NOT OPERATE AT PROPER SPEEDS OR WILL NOT OPERATE AT ANY SPEED: Defective three-speed pull-chain switch assembly; or defective capacitor: Replace three-speed pull-chain switch assembly; or replace PCB assembly. - Page 10 761 C • P , CA 91768 ORPORATE ENTER RIVE OMONA : 888-CASA-1ST (227-2178) www.CasablancaFanCo.com ©C 2000 C • U.S. P OPYRIGHT ASABLANCA OMPANY ATENT ENDING RINTED IN...
