Movement BOLT PLATE LOADED HACK MACHINE Assembly Manual page 25

ASSEMBLY
STEP 5
5 NAME
Screw Hex. Socket Cyl. Head
M8X16
6 NAME
Bush
7 NAME
Olympic Adapter
9 NAME
Headless Screw
10 NAME
Stop
Tool
Assembly by two
Allen 6 mm
people is
recommended
Qty
4x
Qty
4x
Qty
4x
Qty
8x
Qty
4x
9
9
10
9
10
10
7
6
5
7
9
6
5
10
9
10
