ASSEMBLY
STEP 1
1
NAME
Screw Hex. Socket Cyl. Head
M10X70
3
NAME
Flat washer - M10
A
NAME
Rear support
Tool
Assembly by two
Allen 8 mm
people is
recommended
Qty
2x
Qty
2x
1
1
3
6
A
