Movement BOLT PLATE LOADED HACK MACHINE Assembly Manual page 23

ASSEMBLY
STEP 3
2
NAME
Screw Hex. Socket Cyl. Head
M10X30
3
NAME
Flat washer - M10
4
NAME
Hex nut insert - M10
C NAME
Foot support
Tool Assembly by two
Allen 8 mm people is
recommended
Qty
5x
Qty
10x
Qty
5x
4
3
C
4
3
2
3
3
2
8
