WIRELESS REMOTE KIT
P/N 2883455
APPLICATION
Verify accessory fitment at Polaris.com.
IMPORTANT
This Wireless Remote Kit is intended for use with HD
4500 Lb. Winch Kit (PN 2882714).
BEFORE YOU BEGIN
Read these instructions and check to be sure all parts and tools are accounted for. Please retain these
installation instructions for future reference and parts ordering information.
KIT CONTENTS
This Kit includes:
REF
QTY
PART DESCRIPTION
1
1
Receiver, Wireless
2
4
Screw, Torx
3
1
Remote, Wireless
4
1
Holder, Wireless Remote
5
2
Screw, Torx
1
Instructions
Pan Head, High/Low - #14 X 0.75
®
Pan Head, High/Low - #10 X 0.75
®
Instr 9929286
Rev 01 2018-04
PART NUMBER
-
7519731
-
-
7512026
9929286
Page 1 of 5
