- Page 1 IEM615 Series Managed Industrial Ethernet Switch Module Hardware User Manual Version: 02 Issue Date: 2018-12-28 Industrial Ethernet Communication Solutions Expert 3onedata Co., Ltd.
- Page 2 3onedata Co., Ltd. Trademark statement are the registered trademark owned by 3onedata Co., Ltd. And other trademarks mentioned in this manual belong to their corresponding companies. Notes Purchased product, service or features should be constrained by 3ondedata commercial contracts and clauses.
- Page 3 3onedata Co., Ltd. 3/B, Zone 1, Baiwangxin High Technology Industrial Park, Song Bai Road, Headquarter address: Nanshan District, Shenzhen, 518108, China Technology support: tech-support@3onedata.com Service hotline: +86-400-880-4496 E-mail: sales@3onedata.com Fax: +86-0755-26703485 Website: http://www.3onedata.com...
-
Page 4: Preface
The "About This Chapter" section provides links to each section and corresponding principles / operating chapters in this chapter. Icon Convention Format Description Reminder the announcements in the operation, improper operation may result in data loss or equipment damage. 3onedata proprietary and confidential Copyright © 3onedata Co., Ltd. - Page 5 Configuration, operation, or tips for device usage. Pay attention to the operation or information to ensure success device configuration or normal working. Revision Record Version NO. Revision Data Revision Description 2013-11-21 Product release 2018-12-28 Document upgrading 3onedata proprietary and confidential Copyright © 3onedata Co., Ltd.
-
Page 6: Table Of Contents
100M E ....................18 THERNET TTL UART P ...................... 20 TTL CAN P ......................23 CONSOLE P ) ................. 24 EBUGGING I/O A ....................25 LARM NTERFACE ..................... 25 ESET NTERFACE 3onedata proprietary and confidential Copyright © 3onedata Co., Ltd. -
Page 7: Product Overview
Hardware User Manual Product Overview 1.1 Product Introduction IEM615 series are layer 2 managed embedded industrial Ethernet switch modules with the features of high integration, small size, rich functions, simple and convenient operation. This series include following port types: 5 100M Ethernet ports, support 10/100Base-T(X) copper port and 100Base-FX ... -
Page 8: Product Specification
Consumption Full-load consumption <1.5W Environmental Limit Operating temperature -40~75℃ Storage temperature -40~85℃ Operating humidity 5%~95% Physical Characteristics Installation Embedded installation (insertion form of pin header and female header) Size (W×H×D): 55mm×9.7mm×40mm 3onedata proprietary and confidential Copyright © 3onedata Co., Ltd. -
Page 9: Dimension
Hardware User Manual Dimension 2.1 Package Design The module structure chart as follows: 3onedata proprietary and confidential Copyright © 3onedata Co., Ltd. - Page 10 Refer to the following view for the specification of corresponding pin header of the female header B. Unit: mm Refer to the following view for the specification of corresponding pin header of the female header A and C. Unit: mm 3onedata proprietary and confidential Copyright © 3onedata Co., Ltd.
-
Page 11: Product Dimension
Hardware User Manual 2.2 Product Dimension Structure chart of the module as follows: Unit: mm 3onedata proprietary and confidential Copyright © 3onedata Co., Ltd. -
Page 12: Description Of Pin Definition
To facilitate the user to view the pin definition when routing the PCB (printed circuit board), the pin definition diagram adopts top view angle as shown below. The top view of the module pin number and name as follows: 3onedata proprietary and confidential Copyright © 3onedata Co., Ltd. -
Page 13: Description Of Pin Definition Name
Hardware User Manual 3.2 Description of Pin Definition Name Pin Identification Description Ground Receive Data Transmit Data VIN_3V3 VIN: Voltage Input 3V3: 3.3VDC 3onedata proprietary and confidential Copyright © 3onedata Co., Ltd. -
Page 14: List Of Pin Definition
CAN_TD CAN: Controller Area Network, CAN Port TD: Transmit Data 3.3 List of Pin Definition Pin definition of female header A (JP1) (A1-A50) Pin No. Pin Name Pin No. Pin Name 3onedata proprietary and confidential Copyright © 3onedata Co., Ltd. - Page 15 TX4- TX4+ TX5+ TX5- RX5+ RX5- VIN_3V3 VIN_3V3 VIN_3V3 RELOAD OUT_2V5 OUT_2V5 Pin definition of female header B (JP2) (B1-B32) Pin No. Pin Name Pin No. Pin Name RESET_IN SPEED1 LINK1 3onedata proprietary and confidential Copyright © 3onedata Co., Ltd.
- Page 16 Pin Name USER_IO1 ALARM_OUT2 ISP_EN UPDATA RDFS ALARM_OUT1 RUN_LED ALARM_IN1 ALARM_IN0 U1_CONFIG U2_CONFIG UART2_RX UART2_TX C1_CONFIG C2_CONFIG UART2_RTS UART2_CTS UART1_RST UART1_CTS U0_TXD U0_RXD UART1_TX UART1_RX U1_DCD U2_DCD UART1_DTR UART1_DSR CAN2_ERR CAN1_ERR 3onedata proprietary and confidential Copyright © 3onedata Co., Ltd.
-
Page 17: Detailed Description Of The Pin Definition
100M fiber ports, RX- [1:5] is directly connected to the negative output terminal of the fiber receiver. It is recommended to keep the pin reserved when it's not used. 3onedata proprietary and confidential Copyright © 3onedata Co., Ltd. - Page 18 +3.3VDC power supply through a 4.7kΩ resistor, corresponding 100M Ethernet ports 1-5 are configured as 100M fiber ports. The pin is recommended to be grounded when it's not used. 3onedata proprietary and confidential Copyright © 3onedata Co., Ltd.
-
Page 19: Power Supply And Ground Signal
Pin Name Pin No. Type Function Description UART1_RX Input UART1 Received signal UART1_TX Output UART1 Transmitted signal UART1_RTS Output UART1 Request to Send signal Note: When UART1 is extended to RS-485/422 serial 3onedata proprietary and confidential Copyright © 3onedata Co., Ltd. -
Page 20: Ttl Can Port
3.4.5 CONSOLE Port (Debugging Port) The description of CONSOLE port pin definition: Pin Name Pin No. Type Function Description U0_RXD Input UART0 Received signal, used CONSOLE port to debug this module only. 3onedata proprietary and confidential Copyright © 3onedata Co., Ltd. -
Page 21: I/O Alarm Interface
Output CAN2 error indicator, Active low level. LINK1 Output 100M Ethernet port connection and data LINK2 transmission indication pin LINK[1:5]. LINK3 When the pin LINK[1:5] outputs high levels, it means the corresponding 100M LINK4 3onedata proprietary and confidential Copyright © 3onedata Co., Ltd. -
Page 22: Other Pins
The module samples the signal of this pin when powered on. The module program starts to upgrade when the pin receives low levels. RDFS Input Restore to default factory settings, active 3onedata proprietary and confidential Copyright © 3onedata Co., Ltd. -
Page 23: Reserved Pins
Reserved This pin isn’t used, please suspend it. 3.4.9 Reserved Pins Pin Name Pin No. Type Function Description This pin isn’t used, please B3, B5, B6, B7, B9 Reserved suspend it. 3onedata proprietary and confidential Copyright © 3onedata Co., Ltd. -
Page 24: Reference Circuit
100M Ethernet port 1-5 will be data configured to 100M fiber port. transmission When the pin is not used, it’s TX-[1:5] The negative output recommended to be grounded. data transmission 3onedata proprietary and confidential Copyright © 3onedata Co., Ltd. - Page 25 The central tap of the network transformer needs to connect to the pins of the module, such as A47, A48, etc., which provide +2.5V level. Reference Circuit for 100M Fiber Port 3onedata proprietary and confidential Copyright © 3onedata Co., Ltd.
-
Page 26: Ttl Uart Port
32 nodes on one bus. It usually adopts master-slave communication mode in RS-485 communication network, which is one master with multiple slaves. RS-485 transmits signal in differential mode. 3onedata proprietary and confidential Copyright © 3onedata Co., Ltd. - Page 27 Hardware User Manual Reference Circuit for RS-485 (Two-wire System) with Isolation Isolated power supply: Signal isolation: Automatic direction control circuit: 3onedata proprietary and confidential Copyright © 3onedata Co., Ltd.
- Page 28 Hardware User Manual Serial to RS-485 circuit: Reference Circuit for RS-422 The connection method of RS-422 four-wire system adopts full-duplex communication method, which can realize point-to-multipoint communication. 3onedata proprietary and confidential Copyright © 3onedata Co., Ltd.
-
Page 29: Ttl Can Port
CANL end can only be low level or suspension. Due to their different level properties, a terminal resistor needs to be added at the terminal of CAN. 3onedata proprietary and confidential Copyright © 3onedata Co., Ltd. -
Page 30: Console Port (Debugging Port)
UART0 received signal, merely used for CONSOLE port to debug this module. U0_TXD Output UART0 transmitted signal, merely used for CONSOLE port to debug this module. Reference Circuit for CONSOLE Port 3onedata proprietary and confidential Copyright © 3onedata Co., Ltd. -
Page 31: I/O Alarm Interface
Pin Name Type Configuration Method RESET_IN Input Module reset pin. The system would be in reset status when the duration of low level being input to the pin is larger than 200ms. 3onedata proprietary and confidential Copyright © 3onedata Co., Ltd. - Page 32 Hardware User Manual Reference Circuit for Reset 3onedata proprietary and confidential Copyright © 3onedata Co., Ltd.
- Page 33 Hardware User Manual 3onedata Co., Ltd. Headquarter address: 3/B, Zone 1, Baiwangxin High Technology Industrial Park, Song Bai Road, Nanshan District, Shenzhen Technology support: tech-support@3onedata.com Service hotline: +86-400-880-4496 Official Website: http://www.3onedata.com 3onedata proprietary and confidential Copyright © 3onedata Co., Ltd.
