MES600 Series
Managed Industrial Ethernet Switch
User Manual
Version: 02
Issue Date: 2018-08-16
Industrial Ethernet Communication Solutions Expert
3onedata Co., Ltd.

Advertisement

Table of Contents
loading

Related Manuals for 3onedata MES600 Series

Summary of Contents for 3onedata MES600 Series

  • Page 1 MES600 Series Managed Industrial Ethernet Switch User Manual Version: 02 Issue Date: 2018-08-16 Industrial Ethernet Communication Solutions Expert 3onedata Co., Ltd.
  • Page 2 Purchased product, service or features should be constrained by 3ondedata commercial contracts and clauses. The whole or part product, service or features described in this document may beyond purchasing or using range. 3onedata won't make any statement or warranty for this document content unless any other appointment exists.
  • Page 3 3onedata Co., Ltd. 3/B, Zone 1, Baiwangxin High Technology Industrial Park, Song Bai Road, Headquarter address: Nanshan District, Shenzhen, 518108, China Technology support: tech-support@3onedata.com Service hotline: +86-400-880-4496 E-mail: sales@3onedata.com Fax: +86-0755-26703485 Website: http://www.3onedata.com...
  • Page 4 Represent the words click to achieve hyperlink. Font color as: "Light blue". About This Chapter The "About This Chapter" section provides links to each section and corresponding principles / operating chapters in this chapter. Icon Convention Format Description 3onedata proprietary and confidential Copyright © 3onedata Co., Ltd.
  • Page 5 Pay attention to the operation or information to ensure success device configuration or normal working. Revision Record Version NO. Revision Date Revision Description 2018-04-11 Product release 2018-08-16 Delete Gigabit product function 3onedata proprietary and confidential Copyright © 3onedata Co., Ltd.

  • Page 6: Table Of Contents

    L2 FEATURES ........................18 VLAN ........................18 VLAN ......................... 18 5.1.1 ....................21 TATIC FILTERING QOS ............................23 ....................23 LASSIFICATION S ........................24 ........................25 REDUNDANCY........................27 ......................27 APID SwRing ........................27 7.1.1 RSTP .......................... 31 7.1.2 3onedata proprietary and confidential Copyright © 3onedata Co., Ltd.
  • Page 7 14.2 ..................63 ONFIGURATION ROBLEM 14.3 ....................64 LARM ROBLEM 14.4 ....................65 NDICATOR ROBLEM MAINTENANCE AND SERVICE ..................67 15.1 ....................67 NTERNET ERVICE 15.2 ....................67 ERVICE OTLINE ................68 15.3 RODUCT EPAIR OR EPLACEMENT 3onedata proprietary and confidential Copyright © 3onedata Co., Ltd.

  • Page 8: Preface

    The switch default management as follows: IP Setting Default Value IP Address 192.168.1.254 Subnet Mask 255.255.255.0 While configuring the switch via Web: Before remote configuration, please make sure the route between computer and  3onedata proprietary and confidential Copyright © 3onedata Co., Ltd.
  • Page 9 In windows system, if user adopts the advanced configuration function of IP address and accesses the switch device via setting IP dummy address, the following managed functions can't be achieved: IEEE 802.1x polling. 3onedata proprietary and confidential Copyright © 3onedata Co., Ltd.

  • Page 10: Log In The Web Configuration Interface

    Step 6 End. After login in successfully, user can configure relative parameters and information according to demands. Notes: After login in the device, modify the switch IP address for usage convenience. 3onedata proprietary and confidential Copyright © 3onedata Co., Ltd.

  • Page 11: System Status

    2.2 Port information Switch a total of 8 ports, ports can confirm whether the port with the equipment complies with the information bar. Equipment at work, via the port status of the port 3onedata proprietary and confidential Copyright © 3onedata Co., Ltd.
  • Page 12  FULL: Indicates that the port State is full duplex;  HALF: Indicates that the port State is half-duplex (if the ports are not connected,  the port status is HALF); 3onedata proprietary and confidential Copyright © 3onedata Co., Ltd.

  • Page 13: Serial Device Server

    The last of the data 1,1.5,2 Stop bits (bits) package Max frame The length of frame from 1-1460 serial data to Ethernet data. space(bytes) Character delay（ms） 1-500 The time space from serial 3onedata proprietary and confidential Copyright © 3onedata Co., Ltd.
  • Page 14 The last bit of the single Packet. Typical value is 1, 1.5 and 2 bit. When data bits is 5, stop bit 1.5 and 1 option. When data bits is 6, 7, 8, stop bit 1 and 2 option. [Max frame space] 3onedata proprietary and confidential Copyright © 3onedata Co., Ltd.

  • Page 15: Configure Working Mode

    Target address Default is192.168.0.254 COM1 default is 31000， COM4 default is 31003, Target port 1-65535 between them, add step by step Connect immediately/data Default is connect Connect mode 3onedata proprietary and confidential Copyright © 3onedata Co., Ltd.
  • Page 16 The IP address or domain name address that device will connect, both of them can correspond the host computer address on the Internet [Target port] The port that device will be connected, default is 1~65535. [Connect mode] 3onedata proprietary and confidential Copyright © 3onedata Co., Ltd.
  • Page 17 ”www.test.com”（the choice this time is DNS）the “Destination Port” connected to serial port is host computer ”www.test.com” 31002 port ， Connection mode is Immediately, Disconnect Timeou time is 300 seconds, click “Apply’, setting successful. 3onedata proprietary and confidential Copyright © 3onedata Co., Ltd.
  • Page 18 VSP Management Software user manual. Advanced mode TCP server  Under this mode, series is server, SWITCH can choice 0-4 channel connection at the same time, configuration mode is the same based mode. 3onedata proprietary and confidential Copyright © 3onedata Co., Ltd.

  • Page 19: Serial Port Information

    Start address value must less than or equal to end address.  3.1.3 Serial port information It main function of serial port information: Display incorrect data statistics and connection information that send by serial port. 3onedata proprietary and confidential Copyright © 3onedata Co., Ltd.
  • Page 20 Industrial Ethernet Switch User Manual 3onedata proprietary and confidential Copyright © 3onedata Co., Ltd.

  • Page 21: Port Configuration

    The default is “Enable”. Whether selecting flow control to the port. Only can Flow Control selecting flow control when the port enable. The default is off. Port setting interface, as shown in Figure. 3onedata proprietary and confidential Copyright © 3onedata Co., Ltd.
  • Page 22 When one end is auto-negotiation, and the other end to force rate setting, according to  the Ethernet standard consultation rate for corresponding obligatory rate for half-duplex mode Port flow control auto-negotiation mode can be set only when other modes cannot be set  3onedata proprietary and confidential Copyright © 3onedata Co., Ltd.

  • Page 23: Bandwidth Management

    Broadcast storm is the accumulation of broadcast and multicast traffic on a computer network. Extreme amounts of broadcast traffic constitute a broadcast storm. A broadcast storm can consume sufficient network resources so as to render the network unable to transport normal traffic. 3onedata proprietary and confidential Copyright © 3onedata Co., Ltd.
  • Page 24 The recommended setting is 3% based on the above theory.  Please be caution to use MAC control frame and destination lookup failure frame,  disabling IGMP Snooping will have impact on the transmission of the multicast. 3onedata proprietary and confidential Copyright © 3onedata Co., Ltd.

  • Page 25: L2 Features

    Choice “Add/Edit” Step 3 Choice “Apply”, then port 2 and port 3 were divided in VLAN3, they are in same VLAN, Step 4 can transfer and receive data for each other. 3onedata proprietary and confidential Copyright © 3onedata Co., Ltd.
  • Page 26 Choice “Add/Edit” Button, the VLAN item will be added in VLAN table, Will be replace Step 4 directly if there have same VLAN before configuration. Choice “Apply” Step 5 2. Delete Item Delete the item in the table 3onedata proprietary and confidential Copyright © 3onedata Co., Ltd.
  • Page 27 3, PVID is 3, Choice” Keep VID and priority”, then port 2 and port 3 can communication, port 4 and port 5 can communicate, port 2 and port 3 cannot communicate with port 4 and port 5. 3onedata proprietary and confidential Copyright © 3onedata Co., Ltd.

  • Page 28: Static Filtering

    Join Port Select desired configuration port The configured static multicast address entries added to the list Selected multicast address is a static entry in the list, click Delete <Delete>, delete this entry 3onedata proprietary and confidential Copyright © 3onedata Co., Ltd.
  • Page 29 All none multicast address did not allow adding in this table and the format must according to XX-XX-XX-XX-XX-XX, did not have space or other illegal character, otherwise, will be display warning information. 3onedata proprietary and confidential Copyright © 3onedata Co., Ltd.

  • Page 30: Qos

    Default priority is based on port priority, default priority is different from COS and TOS, it did not have relationship with data package, it had relationship with switch port’s priority. If the port’s priority is higher, the data packet will be transferred at first. 3onedata proprietary and confidential Copyright © 3onedata Co., Ltd.

  • Page 31: Cos

    Ethernet standard by four bytes which was published as IEEE 802.3ac in 1998. The QoS technique developed by the working group, also known as class of service (CoS), is a 3-bit field called the Priority Code Point (PCP) within an Ethernet frame 3onedata proprietary and confidential Copyright © 3onedata Co., Ltd.

  • Page 32: Tos

    So far, the defined DSCP with default DSCP, the value is 0; class selector DSCP defined backward-compatible with precedence, value(8,16,24,32,40,48,56); Expedited Forwarding (EF), generally used for low latency service, the recommended value is 46 (101110); identified by forwarding (AF) 3onedata proprietary and confidential Copyright © 3onedata Co., Ltd.
  • Page 33 Priority value (17-32) is defined as the second queue, the priority value (33-48) is defined as the third queue, the priority value (49-64 is defined as the fastest queue, the highest priority. 3onedata proprietary and confidential Copyright © 3onedata Co., Ltd.

  • Page 34: Redundancy

    When network is broken, it has link redundancy and self-recovery capability and self-recovery time is less than 20ms. SW-Ring is the patented technology of 3onedata Co.,Ltd. designed for industrial control network requiring high reliability. SwRing technology support maximum 250 pieces switches, in which the SwRing its self-recovery time is <20ms.
  • Page 35 4 different ring group: Single, Coupling, Chain and Dual_homing. Step 3 Enable Ring Group 1 (or Group 2), and enter into Network ID (support 0-255 number only). Select Ring Port between Port 7 and Port 8. 3onedata proprietary and confidential Copyright © 3onedata Co., Ltd.
  • Page 36 Step 2 type: single ring. Step 3 Set ring port as port 4 in ring group 2, Coupling ctrl port: 2, network ID: 3, type: coupling ring, figure as shown below. 3onedata proprietary and confidential Copyright © 3onedata Co., Ltd.
  • Page 37 4 with network cable, Connect 100 device’s port 1 to 105 device’s port 4 with network cable. 2. Method to enable Ring V3 Chain ring The structure of Chain ring as figure below 3onedata proprietary and confidential Copyright © 3onedata Co., Ltd.

  • Page 38: Rstp

    1998 and 2004, incorporating various extensions. Although the purpose of a standard is to promote interworking of equipment from different vendors, different implementations of a standard are not guaranteed to work, 3onedata proprietary and confidential Copyright © 3onedata Co., Ltd.
  • Page 39 RSTP for several purposes; its default value is 2 seconds. Standard IEEE 802.1D-2004 incorporates RSTP and obsoletes the original STP standard Select RSTP function in rapid ring network interface as follows: 3onedata proprietary and confidential Copyright © 3onedata Co., Ltd.
  • Page 40 The example of Configuration: The priority of network bridge is “32768”，If there did not have network ID less than itself, itself is root network bridge. There did not have same network ID in network. Every 2 seconds, the network bridge will transmit BPDU 3onedata proprietary and confidential Copyright © 3onedata Co., Ltd.

  • Page 41: Port Trunking

    (typically 2-4) to a logical channel. Device supported 2 trunking group, operate method: choice apply, choice the port need to trunking the port list, Choice setting, available after reboot. If the port already 3onedata proprietary and confidential Copyright © 3onedata Co., Ltd.
  • Page 42 STP channel. Port 1 as the system reserved, cannot be used as trunking.  The ports of having been set to the port aggregation that cannot be set to ring ports.  3onedata proprietary and confidential Copyright © 3onedata Co., Ltd.

  • Page 43: Lldp

    Switch will not send out the LLDP information, but the information from the vicinity of the unit LLDP analysis. Will reduce the LLDP information received from the neighbors, but will send LLDP information. 3onedata proprietary and confidential Copyright © 3onedata Co., Ltd.

  • Page 44: Neighbor Information

    The management address is encapsulated in the Management Address TLV field of the LLDP message and is sent to the neighbor node. 3onedata proprietary and confidential Copyright © 3onedata Co., Ltd.

  • Page 45: Access Control

    The identity of visitor with the letter combination is no more than 16 bytes Password: Visitor use password, user authority allows the letter combination no more than 16 bytes Confirm password Make sure the last time input password is correct. 3onedata proprietary and confidential Copyright © 3onedata Co., Ltd.

  • Page 46: Dhcp Server

    1 device-b, device b to automatically obtain IP addresses 192.168.1.19; if the device is connected to port 2 and an equipment b equipment b able to automatically obtain an IP address 192.168.1.20. 3onedata proprietary and confidential Copyright © 3onedata Co., Ltd.

  • Page 47: Mac Port Lock

    And also become he MAC address binding. Static MAC address list is designed to limit the movement of the computer, any computer's MAC and port binding, this computer inserts to the other port cannot 3onedata proprietary and confidential Copyright © 3onedata Co., Ltd.

  • Page 48: Safety Management

    Security management can filter the MAC, set the port to allow or prohibit a specific MAC address. MAC filtering MAC address filtering interface includes enabling or disabling MAC address filtering, MAC address filtering rule setting and rule list view, as shown in Figure. 3onedata proprietary and confidential Copyright © 3onedata Co., Ltd.
  • Page 49 Industrial Ethernet Switch User Manual 3onedata proprietary and confidential Copyright © 3onedata Co., Ltd.

  • Page 50: Remote Monitoring

    SNMP community name defines the relationship of SNMP NMS and SNMP Agent. User can choose the following one or more features related to community name. 3onedata proprietary and confidential Copyright © 3onedata Co., Ltd.
  • Page 51 Set: Manager can use this to set up some variable value of Agent. Trap: Agent uses this to send an alarm to manager. Read Community Use a character string to name a SNMP community. This community only has Get privilege. Read/Write Community 3onedata proprietary and confidential Copyright © 3onedata Co., Ltd.

  • Page 52: Email Warning

    Email warning function will send the warn information immediately by Email if these things happen: NTP information, connection statue changed, login information, broadcast storm information, operating record, and other system log. Mail server 3onedata proprietary and confidential Copyright © 3onedata Co., Ltd.

  • Page 53: Relay Alarm

    Port Alarm Alarm when port disconnects. Enable port alarm, if port was in unusual status (Connect or disconnect), device will output a signal, inform the device work unusual. 3onedata proprietary and confidential Copyright © 3onedata Co., Ltd.
  • Page 54 In default status, the type of relay output is open, the alarm light is OFF, and have no alarm, relay alway open. When the device have alarm, the light is ON, relay close. 3onedata proprietary and confidential Copyright © 3onedata Co., Ltd.

  • Page 55: Port Statistics

    Numbers of the unicast data packets received by the port Multicast Numbers of the multicast data packets received by the port Broadcast Numbers of the broadcast data packets received by the port Drop 3onedata proprietary and confidential Copyright © 3onedata Co., Ltd.

  • Page 56: Tx Frame Statistics

    Number of incorrect or incomplete FCS data packets (including FCS) more than 1522 bytes SysbolErr Number of data packets which is incorrect, incomplete or including invalid characters (including FCS) between 64 bytes and 1518/1522 bytes (Enable VLAN) 11.2 TX frame statistics 3onedata proprietary and confidential Copyright © 3onedata Co., Ltd.
  • Page 57 Numbers of discarded packets caused by conflict happening more than 16 times. Res Busy Discarded Number of discarded packets out of stack queue because of lack of resources (large amounts of low priority data after enabling QoS) 3onedata proprietary and confidential Copyright © 3onedata Co., Ltd.

  • Page 58: Traffic Statistics

    Each switch maintains a MAC address table. In this table, MAC addresses and switches port one-to-one correspondence. When the switches received a data frame, according to the MAC address table to determine 3onedata proprietary and confidential Copyright © 3onedata Co., Ltd.
  • Page 59 "certification"，shows MAC address static certification that is not aging treatment, if displays “static” means that MAC address is a permanent static address that is not aging treatment. Notes: 3onedata proprietary and confidential Copyright © 3onedata Co., Ltd.
  • Page 60 Multicast address list displays the IGMP snooping item, in the address list here all  unicast address. MAC address aging time is 300 seconds, the port is disconnected our parent program to  clear all the corresponding port items. 3onedata proprietary and confidential Copyright © 3onedata Co., Ltd.

  • Page 61: Network Diagnosis

    It is also good to locate the failure when network is cut Example as figure below: Port 4 collects all of the data from port 4 and port 5 3onedata proprietary and confidential Copyright © 3onedata Co., Ltd.
  • Page 62 This function is not often used. Otherwise other port-based higher management function  like RSTP,IGMP SNOOPING Port mirroring function can only deal with the normal FCS packets. It cannot deal with  error data frames. 3onedata proprietary and confidential Copyright © 3onedata Co., Ltd.

  • Page 63: Basic Settings

    It provides coordinated universal time including scheduled adjustments. No information about time zones or daylight saving time is transmitted; this information is outside its scope and it must be obtained separately. 3onedata proprietary and confidential Copyright © 3onedata Co., Ltd.
  • Page 64 (UTC± 12) by the 180th meridian, part of which coincide with the International Date Line. NTP Server It provides host name or IP address of NTP timing. System Time Device time 3onedata proprietary and confidential Copyright © 3onedata Co., Ltd.

  • Page 65: Device Address

    Default Gateway Default gateway in the host PC is generally called default route. Default route refer to a kind of router that destination address of IP data packet will choose when it 3onedata proprietary and confidential Copyright © 3onedata Co., Ltd.

  • Page 66: System Identification

    In System Identification interface we can see Model, Name, Description, Serial NO., and Contact Information. We can modify these above items by this function. It will take effect after system reboot. Figure below is initial device settings of Switch. 3onedata proprietary and confidential Copyright © 3onedata Co., Ltd.

  • Page 67: System File Upgrade

    Display Installation Location of the device, the length is not more than 30 bytes. 13.5 System File Upgrade The menu included 4 functions: Factory default, Download Configuration, upload configuration, upgrade firmware. 3onedata proprietary and confidential Copyright © 3onedata Co., Ltd.
  • Page 68 Click "Download" Step 6 Choose the name of the file and the place to save. 3. Upload Configuration If you know the IP address of the device, user name and password: 3onedata proprietary and confidential Copyright © 3onedata Co., Ltd.

  • Page 69: System Logout

    IP will not be updated in the new configuration when upload configuration. 13.6 System logout Knock<OK> button, after confirmation, device will be logout. After 20 seconds, know menu bar and back to WEB manged login interface. 3onedata proprietary and confidential Copyright © 3onedata Co., Ltd.

  • Page 70: Faq

    How to configure the device restore default setting via DIP switch? Turn the DIP switch 2 to ON position, and restore default setting after power on again. Why the bandwidth can't be increased after configure Trunking (port aggregation) function? 3onedata proprietary and confidential Copyright © 3onedata Co., Ltd.

  • Page 71: Alarm Problem

    When the device alarms, except BlueEyes_II software nether alarm information display area will display alarm information, is there any other way to notify technical staffs? When the device alarms, monitoring host computer buzzer will continue to emit alarm sounds. 3onedata proprietary and confidential Copyright © 3onedata Co., Ltd.

  • Page 72: Indicator Problem

    The switch halts after communicate for a period time, and returns to normal after reboot, what's the reason? Reasons may include: Surrounding environment disturbs the product; troubleshooting, product grounding adopts shielding line or shields the interference source. 3onedata proprietary and confidential Copyright © 3onedata Co., Ltd.
  • Page 73 Network cable is disturbed by static electricity or surge; Troubleshooting, change the shielded cable or install a lightning protector. High and low temperature influence; troubleshooting, check the device temperature usage range. 3onedata proprietary and confidential Copyright © 3onedata Co., Ltd.

  • Page 74: Maintenance And Service

    Users using our company products can call technical support office. Our company has professional technical engineers to answer the questions and help solve the products or usage problems ASAP. Free service hotline: +86-400-880-4496 3onedata proprietary and confidential Copyright © 3onedata Co., Ltd.

  • Page 75: Product Repair Or Replacement

    According to the company's handling procedure, customers should negotiate with our company's technical staff and salesmen to complete the product maintenance, replacement or return. 3onedata proprietary and confidential Copyright © 3onedata Co., Ltd.
  • Page 76 Industrial Ethernet Switch User Manual 3onedata Co., Ltd. Headquarter address: 3/B, Zone 1, Baiwangxin High Technology Industrial Park, Song Bai Road, Nanshan District, Shenzhen Technology support: tech-support@3onedata.com Service hotline: +86-400-880-4496 Official Website: http://www.3onedata.com 3onedata proprietary and confidential Copyright © 3onedata Co., Ltd.
