- Page 1 IES7110-3G series Managed Industrial Ethernet switches CLI user manual Version 1.0.0, Aug. 2017 www.3onedata.com...
- Page 2 IES7110-3GS IES7110-3GT Trademarks Notice is registered trademarks of 3onedata Co.,Ltd. All other trademarks or registered marks in this manual belong to their respective manufacturers. Agreement As the product version upgrades or other reasons, this document is subject to change without notice.
-
Page 3: Table Of Contents
CLI user manual Content Chapter 1 Login Ethernet Switch ............................. 1 1.1 Configuration through console port ........................1 1.2 Configuration through Telnet ..........................4 1.3 Agreement ................................5 1.4 Command line port ..............................6 1.4.1 View of Command Lines ..........................6 1.4.2 Command lines Online help ........................... - Page 4 CLI user manual 7.3 Configuration of showing static multicast address ................... 19 Chapter 8 QoS .................................. 20 8.1 Enter the multicast filtering view ......................... 20 8.2 Enable Dscp / Cos ..............................20 8.3 QoS queue configuration ............................. 20 8.4 The value of Dscp/Tos mapping ......................... 21 8.5 The default port priority allocation ........................
- Page 5 CLI user manual 15.3 IP address and default gateway setting ......................34 15.4 User name, password settings .......................... 35 15.5 Display device IP, subnet mask, default gateway ..................35 15.6 Restore factory settings ............................. 36 15.7 The address of the DNS server settings ......................36 15.8 Obtain an IP address automatically set ......................
-
Page 6: Chapter 1 Login Ethernet Switch
CLI user manual Chapter 1 Login Ethernet Switch 1.1 Configuration through console port 1. Connection switches to configure terminal As shown in Figure 1.1.1, the establishment of the local configuration environment, only the computer serial cable and connected to the Console port of the Ethernet switch. (Figure 1.1.1) This cable is used for connecting the switch Console port and the external monitoring terminal equipment. - Page 7 CLI user manual (Figure 1.1.3) 2) Choose connecting serial port. Choose connecting serial port under “Connect using”（pay attention to the chosen serial port is consistent with the port connected with the configuration cable) ,Click “OK”. As shown in Figure 1.1.4. (Figure 1.1.4) 3) Set serial port parameters.
- Page 8 CLI user manual (Figure 1.1.5) 4) Hyper terminal attribute. In the Hyper Terminal window select [document / property / setting] into the attributes settings window. Select the terminal simulation of type VT100 or automatic detection, click < OK > button to return to the hyper terminal window. (Figure 1.1.6)
-
Page 9: Configuration Through Telnet
CLI user manual 5) For the switch power, power after the hyper terminal display Ethernet switch self-test information, after the prompt the user to type the carriage return, until the emergence of <user name> command prompt, this time to enter the correct username and password, enter the switch system mode can be configured, the specific configuration commands refer to the later chapters of the contents of the book in. -
Page 10: Agreement
CLI user manual 3） Hit “Enter”, checkout successful and till PC show“Please input hostname and password”, ask user to input user name and password, default is admin, figure 1.2.3 as follows: (Figure 1.2.3) 4） Use command to configure the switch and check the running statues, if need help, please input“?”... -
Page 11: Command Line Port
CLI user manual 1.4 Command line port The switch provide command lines port and its configuration for user’s easy configuration and management. Command lines port includes the following features: 1. Local configuration through Console port; 2. Supports history command saving which means it can save 10 pieces. History commands can be selected by up and down key. -
Page 12: Command Lines Online Help
CLI user manual like add Vlan, pvid, port type, etc. Show or modify static Multicast_filters# Multicast multicast address, like Static Multicast Filtering static multicast address. Show or modify value QoS_config# of Qos, Tos, like Qos, Tos etc. Show or modify Ring Ring# Ring Ring... - Page 13 CLI user manual List --List commands of current menu Help --Help commands of current menu Quit --Quit from CLI Exit --Exit from current menu Reboot --Reboot switch Port <dir> --Enter port setting menu Bandwidth <dir> --Enter bandwidth management menu Vlan <dir>...
-
Page 14: Frequent Incorrect Information Of Command Lines
CLI user manual Switch# inf+<Tab> Switch# information 1.4.3 Frequent Incorrect Information of Command Lines All commands typed by users, if it is certificated by grammar, it can run correctly, or users will be sent incorrect information. Frequent incorrect information is in table 1.4.3 as below: Table 1.4.3 Frequent incorrect information English incorrect information Reason... -
Page 15: Chapter 2 Device System Based Information Configuration
CLI user manual Chapter 2 Device system based information configuration Device information includes Device Type, Hardware Version, Device Name, Software Version, Device Description, Device SN and Contact Way. Among them, Hardware Version and Software Version can be only read, not modified. 2.1 Enter into the view of device information Please check the view as figure 2.1.1 Table 2.1.1... -
Page 16: Configuration Information
CLI user manual 2.3 Configuration information Please reference user configuration device information as table 2.3.1: Table 2.3.1 Operating Command Description Type: configurable type, the length is Configure Device Type config –t type between 1～17 characters Name: configurable name, the length is Configure Device Name config -n name between1～17 characters... -
Page 17: Chapter 3 Port Configuration
CLI user manual Chapter 3 Port Configuration Port information including link state (link or LOS), the port state (full or half), rate mode (automatic negotiation, 10Mbps, 100Mbps), interface type (electric or optical), flow control, port is enabled. 3.1 Port information The Ethernet port characteristics of the switches support: 10/100Base-Tx Ethernet port can operate in half duplex, full duplex, auto negotiation mode. -
Page 18: To Enable Or Disable The Port
CLI user manual 3.4 To enable or disable the port The user can use the following command to open or close the port. By default, the port is enabled. Table 3.4.1 to enable or disable the port: Table 3.4.1 Operating Command Description Enable... -
Page 19: Chapter 4 Bandwidth Management
CLI user manual Chapter 4 Bandwidth Management 4.1 Enter rate management view Bandwidth allocation including: 1. Entrance velocity distribution; 2. The outlet velocity distribution; 3. Check the entrance rate configuration information; 4. Check the export rate of configuration information; Table 4.1.1 in bandwidth management view: Operating Command Description... -
Page 20: Configuration Of Type Of Ingress Limited Packets
CLI user manual Operating Command Description Config inrate <portlist>:1,3,5-10 or all <portlist> <low_bw> Ingress <Bandwidth>: <normal_bw> bandwidth (128k,256k,512k,1M,2M,4M,8M,16M,32M,64M,128M,256M) <medium_bw> 0: unlimited <high_bw> Example: set the 1 and 2 port of Ingress bandwidth is Low priority for 1M, general priority is 2M, Medium priority for 4M, higher priority for the 8M. -
Page 21: Chapter 6 Vlan
CLI user manual Chapter 6 VLAN 6.1 Introduction to VLAN VLAN (Virtual Local Area Network) is a virtual local area network, is a kind of device by LAN logical rather than physical division into a network, in order to achieve the virtual group technology. -
Page 22: Enter The Port Configuration View Based On Vlan
CLI user manual Operating Command Description Show type<portlist> -Portlist Example:1,3,5-10 or all, 0 --CPU Show port type (Trunk or Access) port 6.4 Enter the port configuration view based on Vlan Table 6.4.1 to enter the port configuration view based on vlan: Operating Command Description... -
Page 23: Enter Configuration View Based On 802.1Qvlan
CLI user manual 6.5 Enter configuration view based on 802.1QVlan Table 6.5.1 into the 802.1Q Vlan configuration based view: Operating Command Description <portlist>:1,3,5-10 or all 0 --CPU port Pvid setting config pvid <portlist> <pvid> <pvid>:1,3,5-10 or all 0 --CPU port config type <portlist>... -
Page 24: Chapter 7 Static Multicast Filtering View
CLI user manual Chapter 7 Static Multicast filtering view 7.1 Enter the multicast filtering view Static multicast configuration includes: 1. Add static multicast address; 2. Delete the multicast address; 3. Display the multicast address; Table 7.1.1 into the static multicast view command: Operating Command Description... -
Page 25: Chapter 8 Qos
CLI user manual Chapter 8 QoS 8.1 Enter the multicast filtering view QoS configuration includes: 1. Enable Tos, Cos 2. Qos queue mechanism settings（8:4:2:1, high priority first) 3. Cos/Tos value mapping 4. Default port priority 5. Show configuration information of QoS Table 8.1.1 to enter the Qos configuration view: Operating Command... -
Page 26: The Value Of Dscp/Tos Mapping
CLI user manual 8.4 The value of Dscp/Tos mapping The user can use the following command to configure the Dscp/cos value map Table 8.4.1 Dscp/cos mapping configuration command: Operating Command Description <coslist>:CoS Mapping value,0,1,2-7 The value of Cos Config cos <coslist> <classlist> <classlist>:The priority queue, mapping low,normal,medium,high... - Page 27 CLI user manual Operating Command Description To view the ToS/CoS enabled Show state <portlist> <portlist>:port 1,2,3-10 or all state Show default To view the default port priority <portlist>:port 1,2,3-10 or all <portlist>...
-
Page 28: Chapter 9 Ring Configuration
CLI user manual Chapter 9 Ring configuration 9.1 Enter the ring network configuration view The ring network configuration including: 1. The Ring1/Ring2/ Ring3 configuration; 2. Ring network information view; 3. The RSTP configuration 4. RSTP state information view Table 9.1.1 into the ring network configuration view: Operating Command Description... -
Page 29: The Ring1 Configuration
CLI user manual 9.4 The Ring1 configuration User can use the following command to configure Ring 1 after enabling it. SWRing1 configuration： Operating Command Description Configure Config ring1 <portlist> <portlist>: Ring Port Ring1 Example: Configure Port 3 and 4 to be Ring Port of Ring1. Switch(Ring)# Enable ? {1|2|3|4} --Enable Ring I... -
Page 30: The Ring3 Configuration
CLI user manual Switch(Ring)# Enable 2 [OK] Tip: This configuration will be validated after restarting Switch(Ring)# config ring2 1 255 0 6,7 0 [OK] Tip: This configuration will be validated after restarting Example: to modify the first groups in Ring2 ring ID 1, ports 4, 5 Switch(Ring)# modify ring2 1 -p 4,5 [OK] Tip: This configuration will be validated after restarting... -
Page 31: The Rstp Configuration
CLI user manual Tip: This configuration will be validated after restarting Example: to modify the first groups in Ring3 ring network ports 5, 6 Switch(Ring)# modify 1 -p 5,6 [OK] Tip: This configuration will be validated after restarting 9.7 The RSTP configuration RSTP enabled, can use the following command to set the RSTP. - Page 32 CLI user manual Operating Command Description <options> --modify pathcost Range [0-200000000] Modify --modify portpriority rstp_port{1|2|3|4|5|6|7|G1|G2|G3}<options> {0|16|32|48|64|80|96|112|128| <parameter> 144|160|176|192|208|224|240} --modify p2p {no|yes|auto} --modify edge {no|yes} --modify enable {no|yes} Example: RSTP port configuration Switch(Ring)#Enable 4 [OK] Tip: This configuration will be validated after restarting Switch(Ring)# Config rstp_state 32768 2 15 20 [OK] Tip: This configuration will be validated after restarting...
-
Page 33: Chapter 10 Trunk Configuration
CLI user manual Chapter 10 Trunk configuration 10.1 Enter the port Trunk view Port Trunk configuration includes: 1. Port trunk configuration; 2. Delete port information fusion; 3. Port trunk information view; Table 10.1.1 to enter the port trunk view: Operating Command Description To perform the operation in the... -
Page 34: Chapter 11 The Snmp Configuration
CLI user manual Chapter 11 The SNMP configuration 11.1 Configure the view into the SNMP The Snmp configuration including: 1. Close the Snmp 2. To view the Snmp configuration information 3. The Snmp configuration Table 11.1.1 to enter the Snmp configuration view: Operating Command Description... -
Page 35: Chapter 12 Alarm Configuration
CLI user manual Chapter 12 Alarm configuration 12.1 Enter the alarm information view Alarm configuration including: 1. Power alarm; 2. Port alarm; 3. Delete alarm information; 4. Alarm information view; Table 12.1.1 enter the alarm configuration view: Operating Command Description Enter the alarm configuration Alarm To perform the operation in the system... - Page 36 CLI user manual Operating Command Description {1|2|all}:Show the way power alarm Show power alarm 1: The first power supply； Show power {1|2|all} information 2: The second way power Only applicable to DC Show port alarm Show port <portlist> <portlist>:Alarm ports 1,2,3-10 or all information Show alarm output Show type...
-
Page 37: Chapter 13 Port Statistics
CLI user manual Chapter 13 Port Statistics 13.1 Enter the port statistical configuration view Port statistics: 1. Statistics port number and type 2. Clean up the count the number of frames 3. Statistics port flow 4. Clean up the total flow 5. -
Page 38: Chapter 14 Port Mirroring
CLI user manual Chapter 14 Port mirroring 14.1 Enter the port mirroring view Port mirroring configuration includes: 1. Port mirroring configuration; 2. Delete port mirroring; 3. View port mirroring; Table 14.1.1 to enter the port mirroring configuration view: Operating Command Description Enter the port mirroring configuration To perform the operation in the... -
Page 39: Chapter 15 System Management
CLI user manual Chapter 15 System management 15.1 Enter the System management configuration view System management includes: 1. System timeout; 2. The default gateway, IP address configuration; 3. The user name, password configuration; 4. Device IP, subnet mask, default gateway, see; 5. -
Page 40: User Name, Password Settings
CLI user manual Operating Command Description device <A.B.C.D>:ip address address Ip <A.B.C.D> <A1.B1.C1.D1> <A1.B1.C1.D1>:The subnet mask configuration The default gateway Gateway <A.B.C.D> <A.B.C.D>:The gateway address configuration Example: the equipment configuration for 192.168.254 IP 255.255.255.0, subnet mask, default gateway for 192.168.1.1 Switch(Manage)# ip 192.168.1.254 255.255.255.0 [OK] Switch(Manage)# gateway 192.168.1.1... -
Page 41: Restore Factory Settings
CLI user manual 15.6 Restore factory settings The user can restore to factory settings following command equipment Table 15.6.1 restores factory settings command: Operating Command Description Restore the device to To perform the operation in the system Restore factory settings manage Example: To restore the device to factory settings Switch（manage) # restore... -
Page 42: The System Upgrade
CLI user manual To download the configuration file as follows: 1. Enter the command: Switch (manage) # download Please select file path and ready to receive file. Or press [Esc] to quit. 2. Super terminal and to select file folder [transfer] →[To receive the file] →[browse] →[Select the folder] →[Users want to download folder] →[OK] →...
