Loading Paper in the Multi-Purpose Tray
Use the multi-purpose tray when you want to copy or print on the different paper
which is in the cassette.
Open the multi-purpose tray and pull out the auxiliary tray.
For opening the multi-purpose tray, see "Opening the Multi-Purpose Tray," on p. 2-10.
2
Spread the paper guides a little wider than the actual paper width.
Gently load the stack of paper with the printing side facing up until
it touches the back of the tray.
Be sure that the paper stack is loaded under the paper limit guides.
CAUTION
When loading paper, be careful not to cut your hands with the edges of the paper.
IMPORTANT
2-12
Loading Paper
Paper limit guide
The maximum amount of paper that can be loaded in the multi-purpose tray may vary
depending on the paper type. For more details, see "Acceptable Paper," on p. 2-2.
