MEGOHMMÈTRE
I I I I I
MEGOHMMETER
I I I I I
MEGOHMMETER
I I I I I
MEGAOHMMETRI
I I I I I
MEGAOHMETRO
I I I I I
F R A N Ç A I S
E N G L I S H
D E U T S C H
I T A L I A N O
E S P A N O L
Office: Jl. Radin Inten II No. 62 Duren Sawit, Jakarta 13440 - Indonesia
Workshop: Jl. Pahlawan Revolusi No. 22B, Jakarta 13430 - Indonesia
Phone: 021-8690 6777 (Hunting)
Notice de fonctionnement
User's manual
Bedienungsanleitung
Libretto d'Istruzioni
Manual de Instrucciones
C.A 6511
C.A 6513
MEGOHMMETER
Mobile: +62 816 1740 8925
Fax: 021-8690 6777
Advertisement
Table of Contents
Related Manuals for Chauvin Arnoux C.A 6511
Summary of Contents for Chauvin Arnoux C.A 6511
- Page 1 MEGOHMMÈTRE I I I I I C.A 6511 MEGOHMMETER I I I I I MEGOHMMETER I I I I I C.A 6513 MEGAOHMMETRI I I I I I MEGAOHMETRO I I I I I MEGOHMMETER F R A N Ç A I S...
- Page 2 English SAFETY PRECAUTIONS - Before any measurement check that there is no voltage present on the circuit to be tested. - Use the appropriate leads supplied with the instrument. - At rest, the needle must indicate 0 on the voltmeter scale. If not, adjust it by means of the central (6) zero reset screw.
-
Page 3: Table Of Contents
SUMMARY Pages DESCRIPTION ............................................................................. Battery test ....................................Insulation/voltage measurement ........................Continuity measurement ............................Resistance measurement (C.A 6513 only) ..................MAINTENANCE ....................................Changing the batteries/fuse ..........................Fitting the shockproof case ........................... Cleaning ....................................Metrological check ................................Repairs - maintenance .............................. SPECIFICATIONS .................................. -
Page 4: Description
Connect the instrument to the installation to be tested using the accessories supplied (leads and crocodile clip). It is preferable that the "+" is connected to the earth. Select an insulation measurement position with the switch (500 V for the C.A 6511, 500 or 1000 V for the C.A 6513). -
Page 5: Continuity Measurement
CONTINUITY MEASUREMENT After having connected the instrument to the installation to be tested, you must check that no voltage is present (see "Insulation measurement/voltage"). Set the switch to the "10 Ω" position. The measurement is done automatically without having to press the yellow button. Read the value on the white scale 0 to 10 Ω. -
Page 6: Maintenance
This instrument should be checked at least once a year. For checks and calibrations, contact one of our accredited metrology laboratories (information and contact details available on request), at our Chauvin Arnoux subsidiary or the branch in your country. REPAIRS-MAINTENANCE For all repairs before or after expiry of warranty, please return the device to your distributor. -
Page 7: Specifications
SPECIFICATIONS FUNCTIONAL SPECIFICATIONS Insulation Measurement range : 0.1 to 1000 MΩ Scale 0,1 MΩ to 1000 MΩ Accuracy ± 5% of the measurement Range 500 V 1000V* Empty voltage 600V 1200V Test current ≥ 1 mA for ≥ 1 mA for R ≤... -
Page 8: Voltage
Voltage Measurement range : 0 to 600 V AC Scale 0 - 600 V Accuracy ± 3% of end of scale Input impedance 300 kΩ Reference conditions Distortion quantities Reference conditions Temperature 20 °C ± 3K Relative humidity 45 to 55 % RH Supply voltage 5.5 V ±... -
Page 9: Variations In The Nominal Working Range
Variations in the nominal working range. % variation of Limits of working the measurement Distortion quantities range Typical Max. Operating 0 + 90 ° ≤ 5 % of position 0 - 90 ° the measurement Temperature -10 to + 55 °C 3 % / 10°C (1) 5 % / 10°C (1) Humidity... -
Page 10: Electromagnetic Compatibility
Electrical safety Dual insulation instrument in accordance with standard EN61010-1, for a set live-earth voltage of 600 V, installation category III, and degree of pollution 2. Reminders of definitions : - Installation category : classification of installations in accordance with standardised limits for transient access voltages depending on the nominal voltage of the network in relation to ground.
