- Page 1 Chicken Isolator BCI-I User Manual BIOBASE GROUP Version 2020.07...
- Page 2 Disclaimer Biobase shall not be liable for any equipment failure or damage, or for any direct or indirect damage that may occur during the use of the equipment. 1.Malfunction or damage due to violation of the instructions, precautions, and intended use of this manual.
-
Page 3: Table Of Contents
Content Content........................1 1. Introduction....................... 2 2. Technical Parameters..................3 3. Features......................4 4. Structure......................5 5. Control System....................7 6. Installation and Operation................10 7. Maintenance and Trouble shooting..............12 1. Power failure....................12 2. Fan blower failure................... 13 3. Fluorescent lamp failure..................13 8. Labels.......................15 9. -
Page 4: Introduction
1. Introduction The experimental animal is used for scientific research, disease diagnosis, vaccine and blood serum products, as well as any other medicine management. The experimental animal is very important for scientific research, it is named as live reagent. Sterile chicken and SPF chicken are experimental material for Virology, nutrition, pathological study, they are indispensable for biological products production and inspection quarantine. -
Page 5: Technical Parameters
2. Technical Parameters Model BCI-I Parameters External Size 2200*850*1800mm (W*D*H) Animal Activity Area 1600*750*820mm (W*D*H) Waste collection Area 1600*750*250mm (W*D*H) Rated Voltage AC220±10% Rated Frequency 50Hz±1Hz Consumption 700W Air change Rate ≥20 times/h Airflow Velocity 0.1m/s~0.2m/s within the chicken living space... -
Page 6: Features
3. Features 1. LED display: real-time animal activity area temperature and humidity. 2. Automatic temperature control system，there are 2 heating lamps installed to make sure the inner chamber temperature within setting range. The operator can set temperature according to requirement. 3. -
Page 7: Structure
4. Structure The Isolator is composed by upper body and down body. Easy assembly and disassembly design. Pic 1 1. Pass box; 2. Pressure gauge; 3. Control system box; 4. Waste collection membrane; 5. Base stand; 6. Universal caster with brake; 7. UV lamp and fluorescent lamp installation groove;... - Page 8 Filter pattern Pic 2...
-
Page 9: Control System
5. Control System Pic 3 1. Fluorescent lamp; 2. UV lamp; 3.Blower; 4. High and low temperature alarm setting; 5. Heating lamp; 6. Humidity display; 7.Temperature display; 8. High temperature alarm indicator 9. Low temperature alarm indicator 5.1. Preparation Connect power supply cord （ 220V±10%， 50Hz） , turn on power button, then the display will show inner chamber temperature and humidity. - Page 10 Press “ ” button, the fan blower indicator on, and blower starts to run, press “ ” blower again, the fan blower indicator off and fan blower stops running. Keep pressing “ ” button 5 seconds, the humidity display window (refer to pic 3, 6. Humidity display) will show blower status (gear), press button to increase blower speed and...
- Page 11 temperature alarm value through Humidity display window ( press ”、“ ”buttons to modify the high temperature alarm value), then press “ ” button to save data and following turn to low temperature alarm setting status （ “HIGHT” indicator off, “LOW” indicator on, by now setting low temperature alarm value through Humidity display window ( press ”、“...
-
Page 12: Installation And Operation
6. Installation and Operation (1). Installation a) Remove package; b) Check the machine and make sure no damage; c) Count the accessories and files by referring to packing list; d) Move the machine to installation place; e) Take depressurization type water tank from Isolator inner chamber, adjust water level control knob according to water using requirement, then have the cover on and put water tank in the top of machine(refer to pic 1). - Page 13 Pic 5 (2). Operation a) Connect power supply (220V±10%，50Hz), turn on power button, the machine is now in stand-by status and the digital display shows inner chamber temperature and humidity; b) Turn on fan blower and adjust fan blower (refer to 5.4) to make the pressure gauge between 100Pa-150Pa.
-
Page 14: Maintenance And Trouble Shooting
7. Maintenance and Trouble shooting 1. Application environment Only professional staff is allowed to go inside isolator laboratory; the staff should wear protection suit when working inside room. No dusty materials are allowed in laboratory. Please keep the laboratory wall, ground and isolator surface clean. Please disinfect laboratory for a period of time;... -
Page 15: Fan Blower Failure
②Check if the power cord is broken or not by multimeter. ③Check the fuse. The fuse is located near power socket. If confirm the problems are not caused by ①②, please check if the fuse is fusing breaking and replace by new one. ④Check if the relay is broken or wires is well connecting;... - Page 16 ③ If confirm the problems are not caused by ①②, then try to connect power cord, turn on power button, and next to press Heating button, then remove the back panel of control system box. Detect the voltage of Heating lamp-ONE by mulitimeter, if there is voltage reading in multimeter, the heating lamp-ONE is broken and should be replaced by a new one.
-
Page 17: Labels
8. Labels 1. LOGO 2. Fuse 3. Ground... -
Page 18: Warranty
9. Warranty 1. Warranty period 12 months since the date of shipment, exclude consumables and vulnerable parts (lamps, fuse, filters, glasses). 2. The warranty is responsible to factory defects, any man-made defects or nature force majeure defects are not included. 3. -
Page 19: Appendix A Circuit Chart
Appendix A Circuit Chart... -
Page 20: Appendix B Packing List
Appendix B Packing list Item Quantity Main body RVV power cord Food feeding bucket Depressurization water tank User Manual Fuse（10A）... - Page 21 BIOBASE GROUP 2# building, No.9 Gangxing Road, High-tech Zone, Jinan City, Shandong Province, China Tel: +86-531-81219803/01 Fax: +86-531-81219804 Inquiry: export@biobase.com Complaints: customer_support@biobase.cc After-sales service: service_sd@biobase.cc; service_ivd@biobase.cc Web: www.biobase.cc/www.meihuatrade.com / www.biobase.com...
