Embraer EMB145 Operation Manual page 986

WEIGHT AND
BALANCE
Forward limits
Weight Arm
(lb) (in)
27337 608.64
29542 588.34
34170 588.34
38000 588.34
48501 595.56
Aft limits
Weight Arm
(lb) (in)
27337 608.64
29542 623.30
34170 623.30
38000 619.36
48501 619.36
Drawing the fuel index lines over the constrained CG envelope and
searching for the tangency points, we determine the following
constrained ZFW CG points (see Figure 2):
Weight Index
(lb) (IU)
29414 27.7
31252 28.7
39462 38.5
Page
20
1-06-40
AIRPLANE
OPERATIONS
MANUAL
CG Index
(%) (IU)
30.0 42.3
12.0 10.2
12.0 9.7
12.0 9.4
18.4 28.5
CG Index
(%) (IU)
30.0 42.3
43.0 69.5
43.0 78.4
39.5 77.1
39.5 94.8
Code
03
REVISION 29
