LOADING
EMB-145 CONFIGURATION FAB VIP
SEATS
ROW
1
2
3
4
5
6
7
8
9
10
11
12
13
PASSENGER AVERAGE CG:
RH WARDROBE
FWD GALLEY
CATERING
AFT GALLEY
CATERING
LH DOUBLE
WARDROBE
LH STOWAGE
RH STOWAGE
* Total Galley Volume: 1.49 m
** Reference values. Check aircraft placards for actual values.
Page
1-07-30
AIRPLANE
OPERATIONS
MANUAL
PASSENGER
SEATS
1, 2
3, 4
5, 6
7, 8, 9
10, 11, 12
13, 14, 15
16, 17, 18
19, 20, 21
22, 23, 24
25, 26, 27
28, 29, 30
31, 32, 33
34, 35, 36
Balance Arm
m (in)
4.88 (192.09)
5.53 (217.83)
6.80 (267.56)
6.14 (241.77)
11.35 (446.81)
11.35 (446.81)
3
Code
2 74
BALANCE ARM
(m)
7.998
9.090
10.182
12.623
13.411
14.198
15.163
15.951
16.738
17.525
18.313
19.100
19.888
15.030 m / 591.73 in.
Volume
3
m (cu.ft)
0.93 (32.8)
*
*
1.07 (37.6)
0.09 (3.3)
0.25 (8.8)
(52.7 cu.ft) / 4 half trolleys.
(in)
314.88
357.87
400.87
496.97
527.99
558.98
596.97
627.99
658.98
689.96
720.98
751.97
782.99
Capacity
kg (lb)
70 (154) **
113 (249) **
149 (328) **
80 (176) **
23 (50) **
36 (80) **
