CARGO RESTRAINT NET (HORIZONTAL NET)
The cargo restraint net (tie-down) provides vertical restraint for the
baggage and cargo. It is attached to the cargo compartment floor with
anchor plates. Adjustable straps allow the arresting net to extend and
retract. Some airplanes are equipped with retaining strips located at
the upside of the baggage compartment which are used to hold the net
while the baggage is placed under it. Decals on the cargo net
assembly indicate orientation (FWD, AFT, UPSIDE, or R/L) of the net
in the cargo compartment. The net may be a two-piece assembly.
For the cargo restraint net P/Ns 7162041-501 or -503 the maximum
load that can be placed under it is 450 kg (992 lb) and, for the cargo
restraint net P/N 7162041-505, it is limited to the maximum capacity of
the baggage compartment.
