Embraer EMB145 Operation Manual page 1004

LOADING
EMB-145 CONFIGURATION OPTION 1A
SEATS PASSENGER
ROW
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
WARDROBE
RH STOWAGE
COMPARTMENT
LH STOWAGE
COMPARTMENT
FWD GALLEY
AFT GALLEY
* Total Galley Volume: 1.27 m
** Reference values. Check airplane placards for actual values.
Page
1-07-30 2
AIRPLANE
OPERATIONS
MANUAL
SEATS
1
2
3, 4, 5
6, 7, 8
9, 10, 11
12, 13, 14
15, 16, 17
18, 19, 20
21, 22, 23
24, 25, 26
27, 28, 29
30, 31, 32
33, 34, 35
36, 37, 38
39, 40, 41
42, 43, 44
45, 46, 47
48, 49, 50
Balance Arm
m (in)
4.90 (192.91)
5.53 (217.72)
5.38 (211.81)
5.53 (217.72)
6.79 (267.32)
3
(44.7 cu.ft)/3 half trolleys.
Code
41
BALANCE ARM
(m)
6.324
7.111
7.899
8.686
9.474
10.261
11.048
11.836
12.623
13.411
14.198
15.163
15.951
16.738
17.525
18.313
19.100
19.888
Volume
3
m (cu.ft)
0.93 (32.9)
0.17 (6.0)
0.11 (3.9)
*
*
(in)
248.98
279.96
310.98
341.97
372.99
403.98
434.96
465.98
496.97
527.99
558.98
596.97
627.99
658.98
689.96
720.98
751.97
782.99
Capacity
kg (lb)
70 (154) **
61 (135) **
2.3 (5.1) **
51 (113) **
149 (328) **
REVISION 38
