Embraer EMB145 Operation Manual page 1251

GROUND SERVICING
The following table gives the surface conditions and wind velocities at
which mooring is necessary;
Surface Condition
Wet Concrete
Dry Concrete
To moor the aircraft, proceed as follows:
− Tow the aircraft to a parking area where there are tiedown anchors
available.
− Carry out the normal parking procedure.
− Install the tiedown rings (two), one in each primary brace strut of the
main landing gear.
− Attach a nylon rope to the tiedown ring with a bowline knot, and
then attach the other end of the rope to the tiedown anchor on the
ground by knotting it with a bowline knot. See the corresponding
illustration on the previous page.
Page
1-12-15
AIRPLANE
OPERATIONS
MANUAL
Wind Limitation Table
Ice
Snow
Code
4 01
Wind Velocity
25 Kt
40 Kt
55 Kt
60 Kt
APRIL 28, 2000
