- Page 1 NG 2000-5000 User Manual 2014 © Peak Scientific - Rev. 6 – 10/01/14...
-
Page 2: Table Of Contents
Generator Environment General Dimensions Wall Mounting Electrical Connection Fuse External Connections Start-up Procedure IMPORT ANT DOCUMENTS Normal Operation Principal of Operation Unusual Operation Service Requirements Service Schedule Service Plans Cleaning Page 2 2014 © Peak Scientific - Rev. 6 – 10/01/14... -
Page 3: Change History
Please review each of the following sections carefully. Thank you for selecting Peak Scientific to meet your Gas Generation needs, and should you require any further assistance or support please do not hesitate to contact Peak Scientific or the Peak Partner from which you purchased your Generator. -
Page 4: Introduction
NG Range User Manual Introduction Welcome to the User Manual for the Peak Scientific high purity Nitrogen gas generator. Enclosed in this manual you will find the information required to ensure that your generator is operated and serviced according to our recommended guidelines, which will prepare you for long and trouble free Nitrogen generation. -
Page 5: Warranties And Liabilities
(other than pursuant to clause 6 above) that may be suffered by the Customer or any third party. Page 5 2014 © Peak Scientific - Rev. 6 – 10/01/14... -
Page 6: Safety Notices
These instructions must be read thoroughly and understood before installation and operation of your Peak Generator. Use of the Generator in a manner not specified by Peak Scientific MAY impair the SAFETY provided by the equipment. When handling, operating or carrying out any maintenance,... -
Page 7: Declaration Of Conformity
All evaluation, testing and certification issued by: York EMC Services Ltd Donibristle Industrial Park Dunfermline, Fife KY11 9HZ Signed: Name: Chris Pugh Date: February 2014 Position: Engineering Director Page 7 2014 © Peak Scientific - Rev. 6 – 10/01/14... -
Page 8: Environmental Declaration
Where a specific certificate of compliance is required, this can be requested, on a product serial number basis, directly from Peak Scientific Instruments Ltd, by contacting us through our website on www.peakscientific.com... -
Page 9: Technical Specification
77 (170) 88 (176) 88 (176) Shipping Crate Dimensions cm (“) 64 (25.1) x 60 (23.6) x 146 (57.4) Shipping Weight 87 (192) 107 (236) 110 (242) 110 (242) Page 9 2014 © Peak Scientific - Rev. 6 – 10/01/14... -
Page 10: Unpacking
NG Range User Manual Unpacking Although Peak Scientific takes every precaution with safe transit and packaging, it is advisable to fully inspect the unit for any sign of transit damage. Check ‘SHOCKWATCH’ label for signs of rough handling prior to un-packing –... -
Page 11: Removing The Generator From The Crate
The generator should then be tilted back slightly and then up and out of the foam base and onto the floor. Page 11 2014 © Peak Scientific - Rev. 6 – 10/01/14... -
Page 12: Installation
Please refer to the drawing below for the general dimensions of the unit. Maximum Ambient Conditions: 25°C (dry bulb) 70%RH (Max) Non-Condensing General Dimensions NG2000-5000 Page 12 2014 © Peak Scientific - Rev. 6 – 10/01/14... -
Page 13: Wall Mounting
Finally, using the dimensions provided, fix the wall plugs to the wall, ensuring wall plug is suitable for the type of wall. If not, use the correct type. Secure the generator to the wall with the screws from the fittings kit. Page 13 2014 © Peak Scientific - Rev. 6 – 10/01/14... -
Page 14: Electrical Connection
The water vapour is safely removed from the unit by the ventilation system. Air Inlet Nitrogen Outlet Power Switch Power Inlet/Fuse Drawer Page 14 2014 © Peak Scientific - Rev. 6 – 10/01/14... -
Page 15: Start-Up Procedure
The generator is protected from over-pressure and its normal operating cycle ensures frequent venting. Page 15 2014 © Peak Scientific - Rev. 6 – 10/01/14... -
Page 16: Important Documents
MODEL TYPE: INSTALLATION DATE (DD/MM/YYYY): TELEPHONE: Important Please Note: You have 1 month to register your Peak Scientific product from the date of shipment. If you wish to defer installation of your generator you must notify Peak Scientific within month shipment date. -
Page 17: Normal Operation
Unusual Operation If at any time the Generator begins to emit excessive noise or vibration, then it should be switched off and you should contact Peak Scientific or the Peak Partner from which the Generator has been purchased. Page 17... -
Page 18: Service Requirements
Service Kit NG250-5000 08-4723 Service Plans Peak Scientific offer two service plans. The Complete Service Plan, specifically designed for Generators operated in critical environments, also includes full breakdown cover, guaranteed response times and Generator upgrades if available. Our Standard Service Plan, covering the basic needs of our Generators, features special deals on spare parts and breakdowns. - Page 19 São Paulo SP Brasil 107-0061 Singapore, 118223 Tel: +886 2 8226 2383 Tel: +1 866 647 1649 Tel: +81 3-6864-0468 Tel: +65-6777 1966 Fax: +886 2 8226 9499 Fax: +65-6777 1978 2014 © Peak Scientific - Rev. 6 – 10/01/14...
