Assembly and Operating Instructions
max. 150 kg
~ 45 Min.
52 kg
L 127 | W 56 | H 124
TFZ901.02
Art. No. TF-Z9
TF TF-
Racing Bike Z9

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Racing Bike Z9 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Taurus Racing Bike Z9

Summary of Contents for Taurus Racing Bike Z9

  • Page 1 Assembly and Operating Instructions max. 150 kg ~ 45 Min. 52 kg L 127 | W 56 | H 124 TFZ901.02 Art. No. TF-Z9 TF TF- Racing Bike Z9...

  • Page 3: Table Of Contents

    Content GENERAL INFORMATION Technical Data Personal Safety Electrical Safety Set-Up Place ASSEMBLY General Instructions Scope of Delivery Assembly Equipment setting OPERATING INSTRUCTIONS Console display Button function Turning on and setting the equipment Programmes 3.4.1 Manual programme 3.4.2 Training programmes 3.4.3 User-defined programme 3.4.4 Target heart rate 3.4.5 Recovery heart rate Heart rate measuring...
  • Page 4 ORDERING SPARE PARTS Serial Number and Model Name Parts List Exploded Drawing WARRANTY CONTACT...
  • Page 5 With Taurus® fitness equipment, the focus is on what sport is all about: maximum performance! Therefore, the equipment is developed in close consultation with athletes and sports scientists.
  • Page 6 ABOUT THIS MANUAL Please carefully read the entire manual before installation and first use. The manual will help you to quickly set up the system and explains how to safely use it. Make sure that all persons exercising with the equipment (especially children and persons with physical, sensory, mental or motor disabilities) are informed about this manual and its contents in advance.

  • Page 7: General Information

    GENERAL INFORMATION Technical Data LCD display of + speed in km/h + training time in min + training distance in km + cadence (rotations per minute) + calories burnt + heart rate (when using a chest strap) + Watt Total number of training programs: Pre-set programs: Heart rate controlled programs: User defined programs:...

  • Page 8: Personal Safety

    Personal Safety DANGER ⚠ Before you start using the equipment, you should consult your physician that this type of exercise is suitable for you from a health perspective. Particularly affected are persons who: have a hereditary disposition to high blood pressure or heart disease, are over the age of 45, smoke, have high cholesterol values, are overweight and/or have not exercised regularly in the past year.

  • Page 9: Electrical Safety

    Electrical Safety DANGER ⚠ In order to reduce the risk of an electric shock, always unplug the equipment from the mains socket immediately after your workout, before assembly or dismantling, and before maintenance or cleaning. Do not pull on the cable. ⚠...

  • Page 10: Set-Up Place

    Set-Up Place WARNING ⚠ Do not place the equipment in main corridors or escape routes. ⚠ CAUTION Choose a location in which to place the equipment such that there is enough free space/ clearance to the front, the rear and to the sides of the equipment. The training room should be well ventilated during training and not be exposed to any draughts.

  • Page 11: Assembly

    ASSEMBLY General Instructions ⚠ DANGER Do not leave any tools, packaging materials such as foils or small parts lying around, as otherwise there is a danger of suffocation for children. Keep children away from the equipment during assembly. ⚠ WARNING Pay attention to the instructions attached to the equipment in order to reduce the risk of injuries.

  • Page 12: Scope Of Delivery

    Scope of Delivery The scope of delivery consist of the following parts. At the beginning, check whether all parts and tools belonging to the device are included in the scope of delivery and whether damage has occurred. In the event of complaints, the contractual partner must be contacted directly. CAUTION ⚠...

  • Page 13: Assembly

    Assembly Before assembly, take a close look at the individual assembly steps shown and carry out the assembly in the order given. NOTICE First loosely screw all parts together and check that they fit properly. Tighten the screws using the tool only when you are instructed to do so. Step 1: Mounting the front and rear base Mount the rear base (3) to the main frame (1) with Allen screws (5), washers (7), and spring...
  • Page 14 Step 2: Mounting the handlebar and the saddle The connecting rod (8) and the saddle post (9) are already pre-mounted and both can be infinitely adjusted in height with the knob. ࣑ ATTENTION Pay attention to the fact that the safety lines on connecting rod (handlebar) and saddle post must not be exceeded when adjusting.
  • Page 15 Step 4: Mounting the console Mount the console mount (14) to the connecting rod (handlebar) with a screw (86) (fig. a). Insert the console cable (105) through the hole of the console mount (fig. b). Connect the cable (41) (fig. c). Mount the console (85) to the mount with a screw (84) (fig.
  • Page 16 Step 5: Mounting the pedals Screw the pedals (25R, 25L) very carefully clockwise or counter-clockwise to the pedal crank arms. Some lubricating grease or oil might facilitate screwing and can avoid damages to the thread. The right as well as the left pedals are marked with letters R (= right) or L (= left). tep- 5 Step 6: Connecting the equipment to the mains supply...

  • Page 17: Equipment Setting

    Equipment setting Operating the emergency brake: Push the emergency brake (34) for safety reasons, whenever it is required to get off the equipment and/or to stop the flywheel of the equipment. Adjustment When you take a moment to adjust your indoor cycle correctly to your body, you increase the comfort and the safety of your training.
  • Page 18 Adjusting the saddle position Saddle height • Stand beside the saddle post and adjust the saddle to hip height. • Rotate the pedal crank so that the pedals are in the vertical position. • Place a foot on the lower pedal and get on the indoor cycle. Your knee should be slightly bent. •...

  • Page 19: Operating Instructions

    OPERATING INSTRUCTIONS NOTICE Familiarise yourself with all the functions and setting options of the device before starting training. Have the proper use of this product explained to you by a specialist. Console display Time Setting from 0:00 to 99:00, Display from 0:00 to 99:59 Speed Display from 0.0 to 99.9 Distance...

  • Page 20: Button Function

    Button function Recovery Test for determining the recovery heart rate. Reset Hold the button for two seconds to start the console again. Return to the main menu while setting. Down Selecting programmes and value settings. Selecting programmes and value settings. Start/Stop Start and stop your training.

  • Page 21: Manual Programme

    3.4.1 Manual programme When you have chosen the manual programme (MANUAL), you can set various target values for: time, distance, calories and watt. The first three are being counted down. For example if you set your target distance to 20 km, the system will count down until zero is reached and an acoustical signal will be heard (fig.

  • Page 22: User-Defined Programme

    Profiles of pre-set training programmes: P 01 Peak P 02 Longitudinal Valley P 03 Valley P 04 Hill P 05 Hill cli P 06 High land P 07 Canyon P 08 Hill valley P 09 Hills P 12 Hig land longitudinal valley P 10 Mountain P 11 High land valley 3.4.3...

  • Page 23: Target Heart Rate

    3.4.4 Target heart rate When you have chosen the target heart rate programme (HRC Mode), you can set your age with the arrow buttons (fig. 9). Then you choose from 55%, 75%, 90%, and target heart rate (TAG). The system calculates the respective pulse value and displays it in the pulse window (fig.

  • Page 24: Heart Rate Measuring

    Heart rate measuring Note: For some people, the skin resistance change caused by the heart rate is so minimal that the measurements do not allow for usable values. Strong callus or sweat on the hands may also impair a correct measurement. In such cases, the heart rate will not be shown at all or only incorrectly. If the measurement is incorrect or not taken at all, please check if it happens to only one person or to several people.
  • Page 25 Anaerobic (maximum) load training: The main goal of maximum load training is to improve recovery after short, intense loads in order to be able to quickly return to the aerobic zone. In order to achieve this training goal, a high intensity (approximately 90% of the maximum heart rate) with short, intense load is required, which is followed by a recovery phase in order to prevent muscle fatigue.

  • Page 26: Storage And Transport

    STORAGE AND TRANSPORT General Instructions ⚠ WARNING The storage location should be chosen so that improper use by third parties or children can be prevented. If your equipment does not have transportation wheels, the equipment must be disassembled before transportation. ࣑...

  • Page 27: Troubleshooting, Care And Maintenance

    TROUBLESHOOTING, CARE AND MAINTENANCE General Instructions ⚠ WARNING Do not make any improper changes to the equipment. CAUTION ⚠ Damaged or worn components may affect your safety and the life of the equipment. Therefore, immediately replace damaged or worn components. In such a case, contact the contract partner.

  • Page 28: Error Codes And Troubleshooting

    Eliminate sources of interference (e.g. Sources of interference in mobile phone, WLAN, lawn mower the room and vacuum cleaner robot, etc..) unsuitable chest strap Use a suitable chest strap (see RECOMMENDED ACCESSORIES). Wrong position of chest No pulse display strap Reposition chest...

  • Page 29: Maintenance And Inspection Calendar

    Maintenance and Inspection Calendar To avoid damage from body sweat, the equipment must be cleaned with a damp towel (no solvents!) after each training session. The following routine tasks must be performed at the specified intervals: Part Weekly Monthly Display console Plastic covers Moisture of the felt brake Screws and cable connections...

  • Page 30: Recommended Accessories

    RECOMMENDED ACCESSORIES To make your training experience even more efficient and pleasant, we recommend that you add suiting accessories to your fitness equipment. This could be a floor mat, for example, which makes your fitness equipment stand more securely and also protects the floor from falling sweat, but it could also be additional handrails on some treadmills or silicone spray to keep moving parts in good shape.

  • Page 31: Ordering Spare Parts

    10 of this operating manual. NOTICE The serial number of your equipment is unique. It's located on a white sticker. Enter the serial number in the appropriate field. Serial number: Brand / Category: Taurus / Indoor cycle Model Name: Article Number: TF-Z9...

  • Page 32: Parts List

    Parts List Name Specification Qty. Main Frame Front Stabilizer Rear Stabilizer Left Triangle Cap 95.7*57.2*51.3 Right Triangle Cap 95.7*57.2*51.3 Allen Bolt M8x1.25x20L,8.8level Spring Washer D15.4xD8.2x2T Flat Washer D16xD8.5x1.2T Front Post Seat Post Seat 150*260*65,clamp,DD2681 Seat Adjustable Tube L Knob 25L M12*25L Handlebar Computer Fixing Plate...
  • Page 33 Screw M10*1.5*20L M10*1.5*8T Round Cross Bolt M5x0.8x15L D6*26.5*7.7 Cross Screw ST4.2*1.4*20L Left Cover Of Brake 95.4*53*33.4 Right Cover Of Brake 95.4*53*31.2 Brake Handlebar 101.1*48.2*37 Belt PK,J5,1295L Puelly D239.8*23,PK,J6 Bb Sets 127.5L Flat Washer D25*D8.5*2T Outer Flywheel D420*14 Inner Flywheel D290*34.3 Cable Plug D4*D12*13 Swing Connection Fixing...
  • Page 34 Bushing D22.2*D8.2*7T Nylon Nut M8*1.25*8T Screw ST4*1.41*12L Idle Wheel Fixing Plate Carriage Bolt M8*1.25*20L,8.8level Adjustable Bolt M6*1.0*46 M6*1*5T Bearing 6203-2RS plastic cover Flat Washer D18*D8.5*1.2T C Ring S-17(1T) Curved Washer D17*D22*0.3T M8*1.25*6T Screw M8*1.25*16L Spring D1.4*55L Fixing Plate Of Brake Strap 100*63*3.0T Bolt M8*52L 15MM...
  • Page 35 Round Magnet Round Screw M5*10L Sensor Bracket 24*22*2.5T Sensor Cable Adaptor output:9V.500MA Electric Cable 700L Cable Buckle 17.5*8.2*2.2 Cross Screw ST4.2x1.4x12L Motor Upper Computer Cable 300L...

  • Page 36: Exploded Drawing

    Exploded Drawing...

  • Page 37: Warranty

    WARRANTY Training equipment from Taurus® is subject to strict quality control. However, if a fitness equipment purchased from us does not work perfectly, we take it very seriously and ask you to contact our customer service as indicated. We are happy to help you by phone via our service hotline.
  • Page 38 Warranty Conditions For the warranty to be valid, the following steps must be taken: Please contact our customer service by email or phone. If the product under warranty has to be sent in for repair, the seller bears costs. After expiry of the warranty, the buyer bears the costs of transport and insurance.

  • Page 39: Contact

    CONTACT TECHNICAL SUPPORT TECHNICAL SUPPORT & SERVICE TECHNICAL SUPPORT & SERVICE �� �� �� +49 4621 4210-900 80 90 16 50 +33 (0) 172 770033 +49 4621 4210-945 +49 4621 4210-933 �� +49 4621 4210-698 �� �� info@fitshop.dk service-france@fitshop.fr �� technik@sport-tiedje.de ��...
  • Page 40 LIVE FITNESS WEBSHOP AND SOCIAL MEDIA Sport-Tiedje is Europe’s largest specialist store www.sport-tiedje.co.uk for home fitness equipment with currently over www.sport-tiedje.de/blog 70 stores and one of the world’s most renowned online mail order companies for fitness equipment. Private customers order via the 25 www.facebook.com/SportTiedje web shops in the respective national language or have their desired equpiment assembled on...
