U-Line OHAUS DEFENDER 5000 User Manual

H-2289, H-2290, H-2291
OHAUS DEFENDER
5000 DIGITAL SCALE
CONTROL PANEL
CONTROL FUNCTIONS
BUTTON
Turns the indicator ON.
PRIMARY FUNCTION
If indicator is ON, sets
(Short Press)
zero.
Turns the indicator off.
SECONDARY FUNCTION
(Long Press)
Accepts the current
setting on the display.
MENU FUNCTION
(Short Press)
PAGE 1 OF 32
1-800-295-5510
uline.com
TM
OVERVIEW OF CONTROLS
4
1 2 3
6
7
8
On/Zero Print
Off Units
Yes
ON/ZERO PRINT
Sends the current value to
the COM port if AUTOPRINT
is set to off.
OFF UNITS
Changes the weighing
unit.
YES
Advances to the next
menu or menu item.
Rejects the current setting
on the display and
advances to the next
available setting.
Increments the value.
5
No
FUNCTION
Initiates an application mode.
Temporarily displays the active
mode's reference data.
In weigh mode, temporarily
displays 10x expanded resolution
Allows changing the application
mode.
Press and hold allows scrolling
through modes.
NO
Moves back to previous menu
item.
Decrements the value.
Para Español, vea páginas 11-21.
Pour le français, consulter les pages 22-32.
CONTROL PANEL PARTS
# DESCRIPTION
1 Under LED
2 Accept LED
3 Over LED
4 Capacity Label Window
5 TARE Menu Button
6 FUNCTION Mode Button
7 PRINT Units Button
8 ON/ZERO Off Button
Function
Mode
Back
Performs a tare
operation.
MODE
Enter the user menu.
BACK
Exits the user menu.
Aborts the calibration
in progress.
Tare
Menu
Exit
TARE
MENU
EXIT
