H-479, H-480
RUBBERMAID
®
DIGITAL SCALES
ULINE MODEL NO.
RUBBERMAID MODEL NO.
Capacity
Resolution/Accuracy
Weighing Units
Power Source
Platform Size
Display Indicator Size
POWER SUPPLY
BATTERY USE: Battery compartment is located on
underside of the display indicator back. Connect
battery poles accordingly.
ADAPTER USE: First, plug into bottom right of display
indicator. Then, plug into wall outlet.
NOTE: When using the AC adapter, if display
fluctuates between "----" and numbers, reverse
adapter in wall outlet.
DISPLAY INDICATOR MOUNTING
The display indicator can be mounted to a wall up to
9' from the base.
PAGE 1 OF 9
1-800-295-5510
uline.com
TECHNICAL DATA
H-480
4010
150 lb. / 60 kg
0.2 lb. / 0.1 kg
110V Adaptor or 9V battery
12 x 12 x 1⁄"
SETUP
1.
Drill two holes 1⁄" apart. (See Figure 1)
Figure 1
2. Screw the two screws into the wall, letting the heads
protrude 1/8" from the wall. Extending the screw
heads further could damage the scale.
3. Align holes on back of indicator with screws.
Indicator should slide onto screws, firmly and
securely.
Para Español, vea páginas 4-6.
Pour le français, consulter les pages 7-9.
H-479
4040
400 lb. / 180 kg
0.5 lb. / 0.2 kg
lb. / kg
5 x 3⁄"
Drill Hole
0424 IH-479

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RUBBERMAID H-479 and is the answer not in the manual?

Questions and answers

Related Manuals for U-Line RUBBERMAID H-479

Summary of Contents for U-Line RUBBERMAID H-479

  • Page 1 Para Español, vea páginas 4-6. Pour le français, consulter les pages 7-9. H-479, H-480 1-800-295-5510 uline.com RUBBERMAID ® DIGITAL SCALES TECHNICAL DATA ULINE MODEL NO. H-480 H-479 RUBBERMAID MODEL NO. 4010 4040 Capacity 150 lb. / 60 kg 400 lb. / 180 kg Resolution/Accuracy 0.2 lb.

  • Page 2: Operation

    OPERATION TURNING SCALE ON/OFF TARE Press the ON button to turn the scale on. Proceed Place a container on the scale. with weighing the items once 0.0 lb. appears on 2. Press the ZERO button to tare the container weight. display.

  • Page 3: Maintenance

    MAINTENANCE CARE AND CLEANING Protect scale from shock overload, liquid spills, 2. Preserve the finish of the scale by wiping with damp, extreme temperatures and other abuses. soft cloth and mild, nonabrasive detergent. TROUBLESHOOTING OPERATING ISSUE RECOMMENDATIONS Numbers will not display or scale is Remove and reinsert the cord going into the display.

  • Page 4: Información Técnica

    H-479, H-480 800-295-5510 uline.mx RUBBERMAID ® BÁSCULAS DIGITALES INFORMACIÓN TÉCNICA NO. DE MODELO DE ULINE H-480 H-479 NO. DE MODELO DE RUBBERMAID 4010 4040 Capacidad 60 kg/150 lbs. 180 kg/400 lbs. Resolución/Precisión 0.1 kg/0.2 lbs. 0.2 kg/0.5 lbs. Unidades de Pesaje kg/lbs.

  • Page 5: Apagado Automático

    FUNCIONAMIENTO ENCENDER/APAGAR LA BÁSCULA TARA Presione la tecla ON (Encendido) para encender la Coloque un contenedor sobre la báscula. báscula. Proceda a pesar los artículos una vez que la 2. Presione el botón ZERO para obtener la tara por peso pantalla muestre el texto 0.0 lb.

  • Page 6: Cuidado Y Limpieza

    MANTENIMIENTO CUIDADO Y LIMPIEZA Proteja la báscula de sobrecargarla, derrames 2. Conserve el acabado de la báscula limpiándola de líquidos, temperaturas extremas y otros malos únicamente con un paño suave y húmedo y un manejos. detergente suave no abrasivo. SOLUCIÓN DE PROBLEMAS PROBLEMA DE FUNCIONAMIENTO RECOMENDACIONES Los números no aparecen o la pantalla de...

  • Page 7: Données Techniques

    H-479, H-480 1-800-295-5510 uline.ca RUBBERMAID – BALANCES NUMÉRIQUES DONNÉES TECHNIQUES RÉF. ULINE H-480 H-479 RÉF. RUBBERMAID 4010 4040 Capacité 60 kg / 150 lb 180 kg / 400 lb Résolution/précision 0,1 kg / 0,2 lb 0,2 kg / 0,5 lb Unités de pesage kg / lb Source d'alimentation électrique Adaptateur 110 V ou pile 9 V Dimensions de la plateforme...
  • Page 8 FONCTIONNEMENT METTRE EN MARCHE ET ÉTEINDRE LA BALANCE TARE Appuyez sur la touche ON (Marche) pour mettre en Placez un contenant sur la balance. marche la balance. Commencez à peser les éléments 2. Appuyez sur la touche ZERO (Zéro) pour tarer le lorsque 0.0 lb.

  • Page 9: Dépannage

    ENTRETIEN ENTRETIEN ET NETTOYAGE Protégez la balance contre les chocs, les 2. Préservez la finition de la balance en la nettoyant déversements de liquides, les températures seulement à l'aide d'un chiffon doux humide et d'un extrêmes et autres détériorations. détergent doux non abrasif. DÉPANNAGE PROBLÈME RECOMMANDATIONS...
