Perforated part is required for actuating the tamper in case of any attempt to dismantle
the hub. Do not break it off!
3. Power cable socket
4. Ethernet cable socket
5. Slot for micro SIM 2
6. Slot for micro SIM 1
7. QR Code
8. Tamper button
9. Power button

Operating principle

The hub monitors the security system operation by communicating with connected
devices via the Jeweller encrypted protocol
2000 m without obstacles (for example, walls, doors, inter-�oor constructions). If
the detector is triggered, the system raises the alarm in 0.15 seconds, activates the
sirens, and noti�es the central monitoring station of the security organization and
the users.
If there is interference at the operating frequencies or when jamming is attempted,
Ajax switches to a free radio frequency and sends noti�cations to the central
monitoring station of the security organization and to system users.
What jamming of a wireless security system is and how to resist it
Hub 2 Plus supports up to 200 Ajax devices connected, which protect against
intrusion, �re, and �ooding, as well as control electrical appliances automatically
according to scenarios or manually from an app.
To send photos from MotionCam MotionCam Outdoor /
. The communication range is up to
motion detector, a
