Fiber Optic Ethernet Ports
Fiber optic Ethernet ports are available with either SC (Standard or Subscriber
Connector) or ST (Straight Tip) connectors. Make sure the Transmit (Tx) and Receive
(Rx) connections of each port are properly connected and matched to establish a
proper link.
Available Ports
1
1
2
Figure 3.3
Specifications
For specifications on the available fiber optic Ethernet ports, refer to
Ethernet Port Specifications (Page
RUGGEDCOM RMC41
Installation Manual, 04/2021, C79000-G8976-1010-11
Tx Connector
Rx Connector
SC Port
2
1
Tx Connector
1
Rx Connector
2
Figure 3.4
17)".
Communication Ports
3.2 Fiber Optic Ethernet Ports
2
ST Port
"Fiber Optic
