Fiber Optic Ethernet Ports
Fiber optic Ethernet ports are available with either MTRJ (Mechanical Transfer Reg-
istered Jack), LC (Lucent Connector), SC (Standard or Subscriber Connector) or ST
(Straight Tip) connectors. Make sure the Transmit (Tx) and Receive (Rx) connections
of each port are properly connected and matched to establish a proper link.
1
1
2
Figure 4.4
1
1
2
Figure 4.6
For specifications on the available fiber optic Ethernet ports, refer to
ernet Port Specifications (Page
RUGGEDCOM M2100F
Installation Manual, 01/2020, C79000-G8976-1342-06
All manuals and user guides at all-guides.com
2
Tx Connector
Rx Connector
MTRJ Port
Tx Connector
Rx Connector
SC Port
1
Tx Connector
1
Rx Connector
2
Figure 4.5
2
1
Tx Connector
1
Rx Connector
2
Figure 4.7
27)".
Communication Ports
4.2 Fiber Optic Ethernet Ports
2
LC Port
2
ST Port
"Fiber Optic Eth-
23
