Aruba 8360 Switch Series Installation
and Getting Started Guide
Part Number: 5200-6930
Published: December 2020
Edition: 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 8360 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Aruba 8360 Series

Summary of Contents for Aruba 8360 Series

  • Page 1 Aruba 8360 Switch Series Installation and Getting Started Guide Part Number: 5200-6930 Published: December 2020 Edition: 1...
  • Page 2 © Copyright , 2020 Hewlett Packard Enterprise Development LP Notices The information contained herein is subject to change without notice. The only warranties for Hewlett Packard Enterprise products and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty. Hewlett Packard Enterprise shall not be liable for technical or editorial errors or omissions contained herein.

  • Page 3: Table Of Contents

    LEDs..................... Power off the switch......................... Mount the switch..........................Two-post rack mount option....................Four-post rack mount option....................Installing the Aruba X544 Universal 4-Post Duct Kit............34 Install transceivers......................... Connect the switch to a power source................... Setup for initial configuration......................41 Connect network cables........................
  • Page 4 Connectivity standards........................Chapter 8 Cabling and technology information........Cabling specifications..........................Technology distance specifications......................Chapter 9 Support and other resources............Accessing Aruba Support..........................Accessing updates............................Warranty information..........................Regulatory information..........................Documentation feedback..........................Aruba 8360 Switch Series Installation and Getting Started Guide...

  • Page 5: Chapter 1 About This Document

    Aruba X742 Pwr2Prt Fan (JL715A) (JL708A) Related publications • Start Here: Installation, Safety, and Regulatory Information for the Aruba 8360 Switches • ArubaOS-Switch and ArubaOS-CX Transceiver Guide • ArubaOS-CX software manuals To view and download these publications, visit the Aruba Support Portal at https:// asp.arubanetworks.com/downloads.

  • Page 6: Chapter 2 Introducing The Switches

    ◦ • Switch features Overview The Aruba 8360 Switch Series is a family of premium networking switches, ideal for enterprise data centers, network aggregation and core. They provide the foundation for high-performance networks supporting IoT, mobile, and cloud applications. These switches are intended for indoor use only. They are for use in commercial applications. A typical installation is in an environmentally controlled data center.

  • Page 7: Front Of The Switches

    Front of the switches Figure 1: Front of all 8360 switches Table 1: Front of all 8360 switches Label Description JL700A/JL701A Aruba 8360 32Y4C JL702A/JL703A Aruba 8360 16Y2C JL706A/JL707A Aruba 8360 48XT4C Table Continued Chapter 2 Introducing the switches...
  • Page 8 System LEDs (Back Status, Unit Identification/Locator and Global Status) Reserved for future use Out-Of-Band-Management Link/Activity LED Out-Of-Band-Management Port (1000/100/10 Mbps) USB2.0 Type-A port (Aux) Switch Identification Tab (Pull tab) LED mode LEDs (Spd Mode, Usr1 and Usr2 Table Continued Aruba 8360 Switch Series Installation and Getting Started Guide...

  • Page 9: Network Ports

    NOTE: For supported transceivers, see the latest version of the ArubaOS-Switch and ArubaOS-CX Transceiver Guide. Split mode (QSFP28) QSFP ports on the Aruba 8360 switch series are capable of operating as: • 100G ports • 40G ports • Split into 4 individual 25G or 10G ports...

  • Page 10: Management Ports

    Console Port Aruba 8360 switches include an RJ-45 serial console port on the rear of the switch. This port is used to connect a console to the switch by using an RJ-45 serial cable (not supplied). A DB9-to-RJ-45 console cable can be ordered from HPE: JL448A, Aruba X2C2 RJ45 to DB9 Console Cable.

  • Page 11: Chassis And Port Leds On The Front Of The Switch

    Chassis and Port LEDs on the front of the switch Figure 3: Chassis and Port LEDs for the Aruba 8360 32Y4C (JL700A/JL701A) Table 4: Chassis and Port LED labels for the Aruba 8360 32Y4C (JL700A/JL701A) Label Description SFP28 ports QSFP port indicator LEDs...
  • Page 12 Usr2 is reserved for future use. Figure 4: Chassis and Port LEDs for the Aruba 8360 48XT4C (JL706A/JL707A) Table 5: Chassis and Port LED labels for the Aruba 8360 48XT4C (JL706A/JL707A) Label Description Top (left) and Bottom (right) RJ-45 port indicator LEDs...
  • Page 13 QSFP port indicator LEDs Usr2 is reserved for future use. Figure 5: Chassis and Port LEDs for the Aruba 8360 12C (JL708A/JL709A) Table 6: Chassis and Port LED labels for the Aruba 8360 12C (JL708A/JL709A) Label Description QSFP port indicator LEDs...

  • Page 14: Led Mode Select Button And Mode Leds

    FLASH Amber Fault QSFP port Displays Link/Activity or Startup OS-CX: No valid indicator Mode information for the link port. SVOS: Off Normal No valid link Half-Bright Green Valid link indication Table Continued Aruba 8360 Switch Series Installation and Getting Started Guide...
  • Page 15 LEDs Function Switch Behavior LED State Meaning FLASH Full-Bright Indicator of traffic Green activity. The blink time is roughly proportional to the % of full bandwidth utilization of the port. Fault No fault FLASH Amber Fault Displays Link and Activity Startup No valid link Out-Of-Band-...

  • Page 16: Switch Product Label

    Blinks synchronously with Global Status LED. Switch product label The switch product label is an Aruba Orange-colored tab on the bottom right side of the switch front panel. Pull the tab out to view the product label information. The product label information includes the part number, model number, serial number, and MAC address.

  • Page 17: Back Of The Switch

    RJ-45 and USB-C are connected, USB-C has priority. Power supplies The Aruba 8360 switch does not have a power switch; it is powered on when at least one installed power supply is connected to an active AC power source. The power supplies automatically adjust to any voltage between 100-127 and 200-240 volts and either 50 or 60 Hz.
  • Page 18 The Aruba 8360 switch power supplies adapt electrical power for use with the switch. The chassis has two slots that can hold individual power supplies to support load sharing, redundancy, and fault tolerance. Two 550W color coded power supplies are available for use with Aruba 8360 switches.

  • Page 19: Power Supply Instructions

    The Aruba 8360 switch is shipped with two hot-swappable, field-replaceable, AC power supplies. Each power supply has a country-specific power cord for connection to an AC power outlet. The switch can operate with one active power supply. Power supply instructions WARNING: For indoor use only.

  • Page 20: Redundancy

    Redundancy With power redundancy, the Aruba 8360 switch can continue normal operation even when one power supply fails or is powered off. When two power supplies are installed, if one becomes unavailable (fails, is powered off or removed) the remaining power supply provides full power for the device.
  • Page 21 Fan tray Color code Aruba 8360 Port-to-Power Fan Tray (JL714A) Aruba 8360 Power-to-Port Fan Tray (JL715A) Blue Figure 9: Aruba 8360 fan trays Table 12: Aruba 8360 Fan trays Label Description Status LED (JL715A) Release Latch (JL715A) Status LED (JL714A) Release Latch (JL714A) The switch can tolerate the failure of a single fan tray while maintaining a safe operating temperature.

  • Page 22: Fan Tray Status Led

    • Support for many advanced features to enhance network performance: For a description, see the OS-CX guides for your switch. • Ability to update the switch software. To download product updates, go to the Aruba Support Portal. Aruba 8360 Switch Series Installation and Getting Started...

  • Page 23: Chapter 3 Installing The Switch

    • USB Bluetooth adapter: Enables you to configure your switch from a mobile device. Requires the Aruba CX Mobile App. For information about using the Aruba CX mobile app to configure the switch, see the Fundamentals Guide for your switch and software release.

  • Page 24: Parts Not Included

    Parts not included NOTE: If you have not already done so, order an Aruba rack mount kit for use with your 8360 switch. Rack mounting your Aruba 8360 switch is supported using these rack mount kits: • JL602A, Aruba X412 1U Universal 2-Post Rack Mount Kit (Ordered separately.) •...

  • Page 25: Prepare The Installation Site

    CAUTION: • Do not ship any switch in a rack without checking for restrictions in the latest Aruba 8360 Switches Installation and Getting Started Guide. Otherwise, you may void the switch warranty. • Ensure the power source circuits are properly grounded. Then connect the switch to the power source by using the power cord supplied with the switch.

  • Page 26: Install Power Supplies

    Skip this step if two power supplies are already installed in the switch If two power supplies are not already installed in the switch, install power supplies in both slots before proceeding. • Aruba 8360 550W 100-240VAC (JL600A) Port-to-Power Airflow • Aruba 8360 550W 100-240VAC (JL712A) Power-to-Port Airflow NOTE: •...

  • Page 27: Install Fan Trays

    Install fan trays Prerequisites Skip this step if all three fan tray slots are already populated with fan trays. Use the following steps to install a fan tray in any empty fan tray slot. NOTE: • Ensure that a replacement fan has the same airflow as other fan trays installed in the switch (Port-to-Power or Power-to-Port).

  • Page 28: Power-On The Switch And Check Leds

    Power-on the switch and check LEDs Prerequisites The Aruba 8360 switch does not contain a power on/off switch. It is turned on by connecting the AC power cord to the switch and an AC power source. Check LEDs for proper switch operation. For further detail see Chassis and Port LEDs on the front of the...
  • Page 29 Rear position (switch extends 335 millimeters behind the rack post) ◦ Aruba X414 1U Universal 4-Post RM Kit (JL9583B) 4-Post rack mountable with 4-Post rack mount kit in Port-to-Power or Power-to-Port configurations. Aruba X544 Universal 4-Post Duct Kit (JL716A) For use with Power-to-Port configurations with ports mounted on the hot aisle of the 4-post rack.

  • Page 30: Two-Post Rack Mount Option

    The switch is designed to be mounted in any EIA-standard 19-inch telco rack or communication equipment cabinet using the Aruba X412 1U Universal 2-Post Rack Mount Kit (JL602A; sold separately). WARNING: For safe operation, please review the mounting precautions in Installation precautions and guidelines, before mounting a switch.
  • Page 31 NOTE: See Mounting an Aruba 8360 switch for further detail. Figure 12: Attaching two-post mounting brackets to the switch WARNING: For safe reliable installation, only use the screws provided in the accessory kit to attach the mounting brackets to the switch.

  • Page 32: Four-Post Rack Mount Option

    Figure 13: Mounting the switch in a two-post rack (Center-of-Gravity position) Four-post rack mount option The Aruba 8360 switch can be mounted in four-post racks and cabinets by using the Aruba X414 1U Universal 4-Post Rack Mount Kit (JL9583B) or the Aruba X544 Universal 4-Post Duct Kit (JL716A); sold separately.
  • Page 33 NOTE: The 12-24 screws supplied with the four-post rack mount kit are the correct threading for standard EIA/TIA open 19- inch racks. If installing the switch in an equipment cabinet such as a server cabinet, use the clips and screws that came with the cabinet in place of the 12-24 screws that are supplied with four-post rack mount kit (JL9583B).

  • Page 34: Installing The Aruba X544 Universal 4-Post Duct Kit

    5. Secure the rear-post brackets to the rack rear posts using two number 10-32 screws. Installing the Aruba X544 Universal 4-Post Duct Kit The air duct kit (JL716A) allows cool air to be brought in from the aisle side of a rack for power-to-port airflow switches.
  • Page 35 NOTE: • Installation of the duct kit may reduce accessibility to fans and power supplies. It is recommended to provide space in the rack above the duct kit for fan and power supply access. • Switches with different depths will align with different mounting points on the inner rack slides.
  • Page 36 Install the four post rack rail kit in the rack with the rear of the rails pointing toward the front (cold aisle) of the rack. Aruba 8360 Switch Series Installation and Getting Started Guide...
  • Page 37 Install the switch with air duct kit into the rack rails and secure the switch and rack rails with two (2) 10-32 screws. Chapter 3 Installing the switch...
  • Page 38 Aruba 8360 Switch Series Installation and Getting Started Guide...

  • Page 39: Install Transceivers

    This can take 1-3 seconds, with the worst case being 5 seconds. WARNING: • The Aruba transceivers are Class 1 laser devices. Avoid direct eye exposure to the beam coming from the transmit port. • The transceivers operate only at full duplex. Half duplex operation is not supported.
  • Page 40 Figure 16: Installing a transceiver Interface group operation The SFP28 ports 1-4 in the Aruba 8360 32Y4C (JL700A/JL701A) are organized into an interface-group of 4 ports. All transceivers in that interface-group must have the same speed. For example, if the interface-group is configured for 25 Gbps operation, any 10 Gbps transceivers installed will be in conflict with the interface- group configuration and will not be enabled.

  • Page 41: Connect The Switch To A Power Source

    • Using the Aruba CX mobile app: The Aruba CX mobile app can connect to the switch through the USB Bluetooth adapter. For information about using the Aruba CX mobile app to configure the switch, see the Fundamentals Guide for your switch and software release.

  • Page 42: Connecting Cables To Transceivers

    If the port LED does not come on when the network cable is connected to the port, see Diagnosing with the LEDs in the Troubleshooting chapter. NOTE: Ports are disabled by default. Aruba 8360 Switch Series Installation and Getting Started Guide...

  • Page 43: Chapter 4 Initial Configuration With An Out-Of-Band Serial Connection

    Chapter 4 Initial configuration with an out-of-band serial connection Terminal configuration To connect a console to the switch, configure the PC terminal emulator as a DEC VT-100 (ANSI) terminal or use a VT-100 terminal, and configure either one to operate with these settings: •...

  • Page 44: Console Cable Pinout

    Console cable pinout The Aruba X2C2 RJ45 to DB9 Console Cable (JL448A) has an RJ-45 plug on one end and a DB-9 female connector on the other end. Figure 17: RJ-45 to DB-9 pinouts Table 14: Mapping of RJ-45 to DB-9...

  • Page 45: Chapter 5 Replacing Components

    If the Aruba 8360 switch is configured with a redundant power supply, the switch will not suffer any loss of traffic or performance if a power supply fails. To maintain system redundancy, a failed power supply should be replaced as soon as possible.

  • Page 46: Replacing A Fan Tray

    4. Connect the AC power cable to the new power supply's connector Replacing a fan tray The Aruba 8360 switch is equipped with three field-replaceable, hot-swappable fan trays. The switch can tolerate the failure of a single fan tray while maintaining a safe operating temperature. To maintain system redundancy, a failed fan tray should be replaced as soon as possible.
  • Page 47 CAUTION: • The Aruba 8360 switch is not compatible with fan trays from other Aruba hardware platforms. • After removing a fan tray, wait at least five seconds before inserting a replacement fan tray in the same slot. • Replace only one fan tray at a time. Removing more than one fan tray at a time compromises system cooling, risks damage to the hardware, and can cause the switch to shut down abruptly.
  • Page 48 If the switch is connected to an AC power source, the fan tray should immediately start running. Figure 19: Replacing a failed fan tray Table 16: Replacing a failed fan tray labels and descriptions Label Description Fan tray release latch Fan tray handle Aruba 8360 Switch Series Installation and Getting Started Guide...

  • Page 49: Chapter 6 Troubleshooting

    You can perform more in-depth troubleshooting on these devices using the software tools available with the switches, including the full-featured console interface, the built-in web browser interface, Aruba Central or Aruba AirWave. This chapter describes the following: •...

  • Page 50: Diagnosing With The Leds

    Either the PSU1 or PSU2 LED is off but not both. Either the PSU1 or PSU2 LED is on/flashing amber, but not both. Either the PSU1 or PSU2 LED is on/flashing green, but not both. Aruba 8360 Switch Series Installation and Getting Started Guide...

  • Page 51: Diagnostic Tips

    If the power source and power cord are OK and this condition persists, the switch power supply may have failed. Call your Aruba authorized network reseller, or use the electronic support services from Aruba to get assistance.
  • Page 52 Check the switch Event Log and show interface command output for indication of the fault condition. If a port failed selftest, contact Aruba support. If there is a group speed mismatch, see Interface group operation. If the port has a transceiver installed, verify the transceiver is either a supported Aruba transceiver for SFP28/QSFP+/QSFP28.
  • Page 53 Problem Solution The port is not able to Try the following procedures: establish link. For the indicated port, verify that both ends of the cabling, at the switch and the connected device, are connected properly. Verify the connected device and switch are both powered on and operating correctly.

  • Page 54: Hardware Diagnostic Tests

    IP address. These tests can be performed through the switch console interface from a terminal connected to the switch or through a Telnet connection, or from the switch’s web browser interface. Aruba 8360 Switch Series Installation and Getting Started Guide...

  • Page 55: Testing End-To-End Networking Communications

    If a battery failure occurs, contact your authorized Aruba representative for assistance. Batteries are not customer-serviceable and battery failures should be referred only to service personnel authorized by Aruba. For important safety, environmental, and regulatory information, see Safety and Compliance Information for Server, Storage, Power, Networking, and Rack Products, available at http://www.hpe.com/support/Safety-Compliance-EnterpriseProducts...

  • Page 56: Physical

    44.25 cm (17.4 in) 406.4 cm (16.0 in) 4.4 cm (1.73 in) 7.71 kg (17.00 lb) Aruba 8360-16Y2C (JL718A) Aruba 8360-16Y2C PrtToPwr Configuration (JL702A) Aruba 8360-16Y2C PwrToPrt Configuration (JL703A) Table Continued Aruba 8360 Switch Series Installation and Getting Started Guide...

  • Page 57: Chapter 7 Specifications

    Switch Width Depth Height Weight 44.25 cm (17.4) 406.4 cm (16.0 in) 4.4 cm (1.73 in) 8.01 kg (17.65 lb) Aruba 8360-12C (JL721A) Aruba 8360-12C PrtToPwr Configuration (JL708A) Aruba 8360-12C PwrToPrt Configuration (JL709A) 44.25 cm (17.4) 406.4 cm (16.0 in) 4.4 cm (1.73 in)

  • Page 58: Electrical

    Pwr2Prt3F2PS Bdl 550W Pwr2Prt (JL712A) (JL707A) Aruba 8360-12C Pwr2Prt3F2PS Bdl (JL709A) Aruba 8360-24XF2C Pwr2Prt3F2PS Bdl (JL711A) Power supplies automatically adjusts to any voltage between 100-240 volts and either 50 or 60 Hz. Aruba 8360 Switch Series Installation and Getting Started Guide...

  • Page 59: Power Cords

    Power cords Aruba includes the power cord intended for use with your Aruba switch and power supply. Different countries/regions may require different power cords. For a list of the power cords that apply to your switch, see Included parts. CAUTION: Only Aruba-approved power cords may be used with Aruba devices. To access power cord information for your switch, see Included parts.

  • Page 60: Environmental Specifications

    Sound Pressure (LpAm - Bystander): 45.8 dB Sound Power (LWAd): 6.4 Bel Aruba 8360-16Y2C PrtToPwr Configuration (JL702A) Sound Pressure (LpAm - Bystander): 42.8 dB Sound Power (LWAd): 6.0 Bel Table Continued Aruba 8360 Switch Series Installation and Getting Started Guide...

  • Page 61: Rohs

    Sound Pressure (LpAm - Bystander): 45.3 dB Sound Power (LWAd): 6.2 Bel Aruba 8360-24XF2C PrtToPwr Configuration (JL710A) Sound Pressure (LpAm - Bystander): 42.6 dB Sound Power (LWAd): 6.0 Bel Aruba 8360-24XF2C PwrToPrt Configuration (JL711A) Sound Pressure (LpAm - Bystander): 44.4 dB Sound Power (LWAd): 6.2 Bel...

  • Page 62: Connectivity Standards

    • Use only an approved Laser Class 1 SFP transceiver. Japan Power Cord Warning Connectivity standards NOTE: These connectivity standards are general and may not apply to your 8360 series switch. Aruba 8360 Switch Series Installation and Getting Started Guide...
  • Page 63 Table 21: Technology standards and safety compliance Technology Compatible with these EN/IEC standard Lasers IEEE standards compliance 100-TX1000-T10GBASE-T IEEE 802.3u 100BASE-TX IEEE 802.3ab 1000BASE-T IEEE 802.3an 10GBASE-T 1000-SX IEEE 802.3z 1000BASE-SX EN/IEC 60825 Class 1 Laser Product Laser Klasse 1 1000-LX IEEE 802.3z 1000BASE-LX EN/IEC 60825...
  • Page 64 Laser Klasse 1 25-Gig DAC IEEE 802.3by 25GBASE-CR 25-Gig DAC 0.65M IEEE.802.3by 25GBASE- CR-N 25-Gig DAC 3M IEEE.802.3by 25GBASE- CR-S 25-Gig DAC 5M IEEE.802.3by 25GBASE- CR-L 25-Gig AOC (not an IEEE standard) Aruba 8360 Switch Series Installation and Getting Started Guide...

  • Page 65: Chapter 8 Cabling And Technology Information

    This chapter includes switch connector information and network cable information for cables that should be used with Aruba 8360 switches. NOTE: Incorrectly wired cabling is a common cause of problems for LAN communications. Aruba recommends that you work with a qualified LAN cable installer for assistance with your cabling requirements. Cabling specifications...
  • Page 66 The patch cables are frequently overlooked when testing cable and they must also comply with the cabling standards. For 10GBASE-T, Category 6 patch cables are sensitive to Aruba 8360 Switch Series Installation and Getting Started Guide...

  • Page 67: Technology Distance Specifications

    Therefore, Aruba recommends using Category 6A patch cables, or using cable management options to tie down (dress) the Category 6 patch cables so they cannot move.
  • Page 68 2 - 150 meters 100GBASE- twinaxial copper (various lengths offered) 100GBASE-SR4 multimode fiber 1500 MHz*km 2 - 100 meters 3500 MHz*km 2 - 150 meters 100GBASE-LR4 single mode fiber 2 - 10,000 meters Aruba 8360 Switch Series Installation and Getting Started Guide...

  • Page 69: Chapter 9 Support And Other Resources

    Chapter 9 Support and other resources Accessing Aruba Support Aruba Support Services https://www.arubanetworks.com/support-services/ Aruba Support Portal https://asp.arubanetworks.com/ North America telephone 1-800-943-4526 (US & Canada Toll-Free Number) +1-408-754-1200 (Primary - Toll Number) +1-650-385-6582 (Backup - Toll Number - Use only when all other...

  • Page 70: Warranty Information

    Aruba Support Portal https://asp.arubanetworks.com/downloads If you are unable to find your product in the Aruba Support Portal, you may need to search My Networking, where older networking products can be found: My Networking https://www.hpe.com/networking/support To view and update your entitlements, and to link your contracts and warranties with your profile, go to the Hewlett Packard Enterprise Support Center More Information on Access to Support Materials page: https://support.hpe.com/portal/site/hpsc/aae/home/...

This manual is also suitable for:

8360 32y4c8360 16y2c8360 48xt4c8360 12c8360 24xf2c
