- Page 1 Drive Technology \ Drive Automation \ System Integration \ Services CMS Electric Cylinder Addendum to the Operating Instructions Edition 11/2007 11704217 / EN...
- Page 2 SEW-EURODRIVE – Driving the world...
-
Page 3: Table Of Contents
Position of the mount-on components of CMS71 ........9 Operation of the Star Vario / Star Control Lubricator ........10 Star Vario ....................10 Star Control....................12 Technical Data....................14 CMS50 ...................... 14 Addendum to the Operating Instructions – CMS Electric Cylinder... -
Page 4: Mechanical Installation
CMS from being exceeded. This requires soft, damping elements. Their purpose is to absorb the energy and then limit the end position mechanically. -
Page 5: Calculating The Stroke Lengths
Safety distance [M] Weight 1.3.1 Calculating the effective stroke The effective stroke can be calculated as follows: = A - T - 2 x S - 2 x S → < H Addendum to the Operating Instructions – CMS Electric Cylinder... -
Page 6: New Stroke Length Of Cms50S
CMS50S/B/RH1M X = 163 47.5 CMS50S/B/AS1H X = 201 (174 + X) Plug max. 270° rotatable Closing plug for lubricating point Plug, signal taper greasing nipple DIN71478-H1 64.5 M16/14 mm deep Plug, power 599623051 Addendum to the Operating Instructions – CMS Electric Cylinder... - Page 7 CMS50S/B/RH1M X = 163 47.5 CMS50S/B/AS1H X = 201 (404 + X) Plug max. 270° rotatable Closing plug for lubrication point Plug, signal taper greasing nipple DIN71478-H1 179.5 M16/14 mm deep Plug, power 599624715 Addendum to the Operating Instructions – CMS Electric Cylinder...
-
Page 8: Position Of The Mount-On Components Of Cms50
The A-side endshield and the cover disc can only be rotated together. 180° Plug position 270° (basis) 180° Position B-side (A-side endshield) 180° Position lubrication point 270° 180° Position B-side (cover disk) 270° 0° Position A-Side 270° 90° 631432459 Addendum to the Operating Instructions – CMS Electric Cylinder... -
Page 9: Position Of The Mount-On Components Of Cms71
Lubricators can only be mounted on if the lubricating point is positioned at 270°. 180° Position B-side 270° Plug position 270° (basis) 180° Position lubrication point 270° 180° 180° Position Sealing air connection 270° 0° Position A-side 90˚ 270° 0° 90° 633772427 Addendum to the Operating Instructions – CMS Electric Cylinder... -
Page 10: Operation Of The Star Vario / Star Control Lubricator
This chapter's content is an excerpt from the current perma operating instruc- tions. SEW-EURODRIVE does not assume liability for the correctness and complete- ness of the content. A requirement of fault-free operation and fulfillment of any rights to claim under limited warranty is that you adhere to the information given in the Star Vario and Star Control lubricator operating instructions by perma-tec GmbH &... - Page 11 Clean pipes and connection parts, switch the Pipes or connection parts clogged Lubricator indicates a system fault via unit off and back on flashing red LED Back pressure is too high Reduce back pressure Addendum to the Operating Instructions – CMS Electric Cylinder...
-
Page 12: Star Control
Depending on the fill level of the installed LC unit, the end signal may be erroneous after this procedure! This is why you must manually check the end of the lubrication pe- riod. 1) Lubricant container Addendum to the Operating Instructions – CMS Electric Cylinder... - Page 13 Almost empty LC unit replaced with a par- tially empty LC unit Lubricator does not dispense the Switch setting not changed correctly See section 2.2.2 altered quantity Addendum to the Operating Instructions – CMS Electric Cylinder...
-
Page 14: Technical Data
Weight, variant without brake [kg] Weight, variant with brake [kg] 1) Depending on max. amplifier current, dynamic or static load of spindle; prior to project planning with maximum force please contact SEW- EURODRIVE. Addendum to the Operating Instructions – CMS Electric Cylinder... - Page 15 SEW-EURODRIVE – Driving the world...
