4 Peeler specifications

4 Peeler specifications
Width of liner (a)
Length of label (b)
Minimum width of label (c)
Maximum width of label
Thickness of label
Thickness of liner
Maximum diameter of roll media :
Inner diameter of roll media
D u a r l i b y t i
Peeling position accuracy
1 − 4.65 in (25.4 − 118 mm)
:
1 − 4.72 in (25.4 − 120 mm)
:
Label: fine media/Thickness: 0.09 mm
(including glue layer)/Rolled inwards
Label must be positioned at 0.63 − 0.87in
:
(16 − 22 mm) from left edge of liner,
which is viewed from front of media exit
: To be narrower than liner
: 0.0067 in (0.17 mm) or less
: 0.0027 in (0.07 mm) or less
8 in (203 mm)
: 3 in (76 mm) or more
: 1 0 0 k m r o o n e
the label above)
±1.0 mm
:
Peeling position varies depending on the type of
media, the size of roll media and the size of ink
ribbon, so adjust it to the optimum condition as
needed
a
c
Direction of media feed
– 13 –
m l i o i l n p e e e l d a l b e
b
s l ( w h e n u s n i g
