Maxxus 90R Pro Installation & Operating Manual page 29

Teil Beschreibung
80 Cover (L )
81 Brake adjustment bar (8010-24)
82 Pedal (L) (8020-21)
83 Pedal (R ) (8020-22)
84 Saddle (8010-22)
85 Back cushion (8010-23)
86 Feet pad(8500-55)
87 wheel (8500-56)
88 Tube plug(OMA-05-05-055)
89 Circle Tube plug
90 Square Tube plug
91 Foam Grip
92 Handle pulse
93 Crank set cover
94 Saddle cushion block set
95 Stand post communication wire
96 Main frame communication wire
97 Magnectic sensor
98 Brake wire
99 Magnectic wire
100 Battery
101 Stand post handle wire
102 Handle pulse wire-2
103 Handle pulse wire -4
104 Console wire
105 Console handle pulse wire
106 Alu rails plug
107 Bottle holder
108 Bottle
109 Ipad Holder
110 Hand pulse bottom cover
Ausführung
Ø49×22×M10×26
Ø54.5×23.5
Ø32×t1.5
25×50×t1.5
Ø29×t3.0×530
Ø20×20
L-800mm
L-800mm
L-600mm
L-600mm
29
Spare Parts List
Menge
1
1
1
1
1
1
4
2
2
2
1
2
2
2
2
1
1
1
1
1
1
1
1
1
1
1
2
1
1
1
2
