CAPI error code Meaning
3305h
D channel layer 1 disconnection
3306h
D channel layer 2 disconnection
3307h
D channel layer 3 disconnection
3308h
B channel layer 1 disconnection
3309h
B channel layer 2 disconnection
330Ah
B channel layer 3 disconnection
330Bh
B channel layer 2 disconnection
330Ch
B channel layer 3 disconnection
Error messages from the ISDN (DSS1 protocol)
3400h
Disconnection by the network, or no reason
specified
3480h
Normal disconnection
3483h
Data transfer service not available
34B5h
Wrong remote number, service or service
attribute
34B8h
Remote number has changed
34B9h
Remote terminal device not ready
34Bah
No remote device has answered the call
34BBh
Remote terminal device busy
34Beh
Call refused by remote side
34D9h
Network busy
34F1h
Remote error
Error messages from the ISDN (1TR6 protocol)
3400h
Disconnection by the network, no reason
specified or reason not translatable
3480h
Normal disconnection
3483h
Service not available on local or remote
side, or wrong number
348Ah
Own line busy
3490h
Semi-permanent connections not supported
by the network
3491h
Semi-permanent connections not supported
by local or remote side
34A0h
Outgoing calls locked
MicroLink ISDN/PCC-16 Manual © 1997 ELSA GmbH
Appendix: CAPI Error Codes
Reason and possible solution
Check the cable connection to the ISDN S
socket and disconnect other ISDN devices
from the S
bus to exclude possible error
0
sources. Test the adapter board directly at
the NT (Network Terminator)
Check the D channel protocol of the loaded
CAPI driver (DSS1 or 1TR6)
Disconnected by the remote side or
connection error.
Re-establish the connection
Connection error caused connection restart -
data loss possible
Try to call again
Both sides have terminated the connection
properly
Check the remote number and the
availability of the desired services (this
applies also to private branch exchanges)
Ask for the new number of the remote side
Check whether the remote side is ready for
operation
Check whether the remote side is ready for
operation and check the MSN or EAZ used
Try to call again later
Contact the remote side
Try to call again later
Try to call again and check the CAPI driver
Try to call again
Both sides have terminated the connection
properly
Check the remote number and the
availability of the desired services (this
applies also to private branch exchanges)
Your line is occupied by other terminal
devices. Terminate other connections first
Apply to your network operator for semi-
permanent connections
Ask your network operator to unlock your
line for outgoing calls
0
29
