Summary of Contents for ELSA TanGo 2000

  • Page 1 ELSA TanGo 2000...
  • Page 2 1995. Trademarks All brands or product names are or may be trademarks of their respective owners. The ELSA logo is a registered trademark of ELSA AG, Aachen, Germany. ELSA reserves the right to vary specifications without notice and accepts no liability for technical errors and/or omissions.
  • Page 3 Internet Explorer) is required for reading and printing HTML files. The ACROBAT Reader program is required to read and print PDF files. It can also be found on the ELSA TanGo CD and may be installed using the CD setup program.
  • Page 4 (FAQs), a wealth of tips and tricks, current drivers and selected links to other WWW pages. Before you continue The installation of the ELSA TanGo 2000 is described in the Installation Guide. Please read the information there before continuing with this manual.

  • Page 5: Table Of Contents

    Telephone and Answering Machine Function ........... 9 Connecting to BBSs ..................10 Installation of ELSA Configuration Manager under Windows 95 and NT 4.0 ..11 Installation of ELSA-ZOC under Windows 95 and Windows NT 4.0 ....12 Installation of Telix for DOS ................. 13 Installation of LapLink for Windows 95..............
  • Page 6 Contents Warranty Conditions..................... 29 Glossar .......................... 31 Index ..........................35 ELSA TanGo 2000...

  • Page 7: Introduction

    Introduction Introduction ELSA TanGo 2000 one of the family of ISDN products from ELSA. It is an external terminal adapter for connecting your PC to an ISDN Basic Rate Interface point-to-point or point-to-multipoint connection, or to private branch exchanges (PBX systems) with an S interface.
  • Page 8 ISDN connection and the line to facilitate troubleshooting of possible system faults. 24-hour access – is available to ELSA Support in the ELSA LocalWeb, the Internet and ELSA's CompuServe forum. Guaranteed – 6-year warranty on the ELSA TanGo 2000.

  • Page 9: What Do I Need For Elsa-Rvs-Com

    What do I need for ELSA-RVS-COM ? The following minimum requirements must be fulfilled: Computer: To run ELSA-RVS-COM , your computer should be equipped with a 486 or Pentium CPU. RAM: a minimum of 16 MB. To ensure reliable operation, 32 MB or more are recommended.

  • Page 10: Ce Conformity

    All ISDN terminal units with the CE seal therefore comply with: NET 3 (ISDN Basic Rate Access) EMC compatibility standards Safety standards and may therefore be connected to the Euro-ISDN in all EU countries. ELSA TanGo 2000...

  • Page 11: Software On The Elsa Tango Cd

    Telephone functions when using a full-duplex sound card, including microphone and speakers Installation under Windows 95 and Windows NT 4.0 To install ELSA-RVS-COM on your computer under Windows 95 or Windows NT 4.0, please proceed as follows: Start Windows 95 or Windows NT 4.0. When installing under Windows NT, ensure beforehand that you have administrative privileges.
  • Page 12 Click on the Next button. The 'Program Group' dialog box will appear. Use the Next button to confirm the creation of the ELSA-RVS-COM program folder. The 'Installation Start' dialog box will appear.
  • Page 13 Euro-ISDN Connection (DSS1) The three numbers for your Euro-ISDN connection could be as follows: After the installation is complete, the new ELSA-RVS-COM program folder is automatically displayed and the RVS-CommCenter starts up. Click on the status indicator to open the program folder.

  • Page 14: The Icons And Their Meanings

    The following icons can be found in the ELSA-RVS-COM program group: CommCenter The CommCenter is active in the background when ELSA-RVS-COM is in use. It serves as the center for the control of the ISDN settings. These settings may be used to configure the various ELSA-RVS-COM services (file transfer server, fax reception, answering machine).

  • Page 15: Receiving And Sending Faxes

    TransferMaster can be used to transfer files from one PC to another. Receiving and Sending Faxes ELSA-RVS-COM requires a Windows EMail system (such as Microsoft Exchange or Outlook) to send and receive faxes. This can be installed under Windows 95 using...

  • Page 16: Connecting To Bbss

    Software on the ELSA TanGo CD Using ELSA-RVS-COM as a Telephone Click on this icon. The 'RVS Phone' dialog box will appear. Enter the desired number using the keyboard or mouse and start the dialing process with Dial. Hangup ends the call.

  • Page 17: Installation Of Elsa Configuration Manager Under Windows 95 And Nt 4.0

    ELSA Configuration Manager is a utility program which permits the simple, convenient configuration of your ELSA TanGo 2000 . It can be used to set the D channel protocol for example, to enter the MSN or to install the current firmware for the ELSA TanGo 2000 .

  • Page 18: Installation Of Elsa-Zoc Under Windows 95 And Windows Nt 4.0

    ELSA-ZOC is a communications program which you can use to address your ISDN terminal adapter from your PC. After starting ELSA-ZOC , you will be able to send individual AT commands to the terminal adapter. To install ELSA-ZOC on your computer, proceed as follows: Switch the ISDN terminal adapter on and boot Windows 95 or Windows NT 4.0.

  • Page 19: Installation Of Telix For Dos

    Software on the ELSA TanGo CD Installation of Telix for DOS The terminal program Telix Lite is included with your ELSA TanGo 2000 . To install Telix Lite on your computer, proceed as follows: Insert the ELSA TanGo CD in your CD drive (e.g. D:), switch to the ELSAWARE\ENGLISH\DOS\TELIX, directory and run the file INSTALL.BAT...

  • Page 20: Installation Of Laplink For Windows 95

    To install LapLink for Windows 95, proceed as follows: Switch the ISDN terminal adapter on and boot Windows 95. Insert the ELSA TanGo CD in your CD drive (e.g. D:). The CD setup will start automatically. Under Installation of: in the ELSA CD Setup, select LapLink 7.5 for Windows 95 in the list and click OK to start the setup program.

  • Page 21: Control Commands

    ISDN communications. A complete description of the AT command set can be found on the ELSA TanGo CD. A terminal program is required to enter AT commands via a PC (e.g. ELSA-ZOC ).

  • Page 22: Bit-Oriented Registers

    Great caution should thus be applied when changing bit-oriented registers! We recommend the use of the AT commands to change the configuration of the ISDN terminal adapter. A complete description of the S registers can be found on the ELSA TanGo CD.

  • Page 23: Appendix

    Report self-test result Report Plug & Play ID text Display of current ISDN parameters $IAD Connection without dialing $IBP Setting the B channel protocol $IBR Setting the ISDN bit rate $ICI? Display charge information $ICI Delete charge information ELSA TanGo 2000...
  • Page 24 Messages in plain text Display of firmware version &V Display configuration profiles No modified CONNECT messages Identification of connections with error correction Additional distinction of correction processes Detailed CONNECT messages &W Save configuration profile Save complete configuration profile ELSA TanGo 2000...
  • Page 25 Sets the bit m to the value x (m = 0 to 7; x = 0 to 1) AT.m? Reads the value of bit m ATSn.m=x Sets bit m in S register n to value x (m = 0 to 7; x = 0 to 1) Query of the value range of a command ELSA TanGo 2000...

  • Page 26: Status Display And Troubleshooting

    Green and yellow LEDs on the front panel of the ISDN terminal adapter serve as the status display of the ISDN connection. Green LED The green LED shows the status of your ISDN line and the connection to the exchange. ELSA TanGo 2000...
  • Page 27 ISDN terminal adapter clear to send (see also commands AT\D and AT\Q) DCD (M5) Connection established (see also command AT&C) Red LED lit during connections without error correction and during fax connections Green LED lit during error-corrected connections ELSA TanGo 2000...

  • Page 28: Technical Data

    Appendix Technical data Users with specific technical interests should refer to this chapter for detailed information on ELSA TanGo 2000 . All connections and their pin assignments are described in detail. Characteristics of the terminal adapter ELSA TanGo 2000 Power supply 24 VAC , max.
  • Page 29 Appendix RJ11 socket contact assignments socket Line a/b port pin assignment (RJ14 socket) a/b ports Line ELSA TanGo 2000...

  • Page 30: Declaration Of Conformity

    TBR 3 This declaration has been made on behalf of the manufacturer / importer ELSA AG Sonnenweg 11 D-52070 Aachen GERMANY Peter Padar Quality Management Officer Aachen, December 18, 1997 by order, Peter Padar Quality Management Officer ELSA TanGo 2000...

  • Page 31: Questions And Answers

    ISDN (DSS1) or national ISDN (1TR6)? The ELSA Configuration Manager permits the simple, convenient configuration of your ELSA TanGo 2000 . It can be used to set the D channel protocol for example, or to enter the MSN or the terminal selection digits.
  • Page 32 COM port? The throughput for CONNECTs at 64,000 bps is only around 6,000 cps The poor throughput is the result of the large number of CRC errors. Check the BIOS settings of your computer and ensure that IDE HDD BLOCK MODE is set to DISABLED. ELSA TanGo 2000...

  • Page 33: Advice And Help

    Who to contact? First you should contact the dealer where you bought your ELSA product. If there are still questions remaining, contact one of the following: ELSA on the Internet The ELSA Internet WWW site http://www.elsa.com...

  • Page 34: The Elsa Localweb

    Repair? If you are not sure whether your ELSA expansion board is defective or if the problem is just a driver which is incorrectly installed, please call the ELSA Hotline before you send the board for repair. Should you need to send in the ELSA expansion board to be repaired, please use suitable packing material and the original box to prevent damage during transport.
  • Page 35 ELSA video conferencing systems with a warranty period of 36 months. Also excepted are the ELSA TFT Monitors with a warranty period of 12 months. This period begins at the day of delivery from the ELSA dealer. Warranty services do not result in an extension of the warranty period nor do they initiate a new warranty period.
  • Page 36 ELSA Monitor, damage to the cathode ray tube (CRT) has been caused especially by mechanical load (e.g. from shock to the pitch mask assembly or damage to the glass tube), by...
  • Page 37 Upload). An ’intelli- become a world-wide standard for the syntax gent terminal’, i.e. a simple input/output device of these commands. All ELSA modems are with additional functions for storage of recei- equipped with an automatic dialing device and ved data or the transmission of local data, is can accept calls automatically.
  • Page 38 – Subscriber interface of the Basic Rate Interface. This interface is a bus I.430 – Subscriber network interfaces for the permitting the connection of up to eight ISDN ISDN Basic Rate Interface - description of layer 1. I.463 V.110 I.465 V.120 ELSA TanGo 2000...
  • Page 39 TA – Terminal adapter using the HDLC transfer process in the ISDN B channel. TEI – TEI (Terminal Endpoint Identifier) is an identification in the D channel protocol ar- ranged with the exchange and used to distin- ELSA TanGo 2000...
  • Page 40 Glossary Notes: ELSA TanGo 2000...
  • Page 41 Recording calls ..........10 Download ............. 28 Repair ............28 Driver ............28 Scope of delivery ..........3 ELSA World Wide ......... 27 Sending faxes ..........9 ELSA-RVS-COM ..........5 Status displays ..........2 ELSA-ZOC ............. 12 Support ............. 2 Escape command ..........
