- Page 1 770 - Plus Owner’s Manual & Parts Book Purchase Date Serial Number Model Number Tractor Model Dealer PN: 63-19653 Date 9-11-16...
-
Page 2: Table Of Contents
Please have all operators read this manual carefully and keep the manual available for ready reference. If you have any questions or concerns, contact Grouser Products. Maintenance Due to the harsh environment many of our equipment operates in, the following tasks should be performed every 10 hours or less. -
Page 3: Torque Specifications & Safety Precautions
4. Make sure the area is clear of people before moving any equipment. 5. Do not modify or permit anyone else to modify or alter the equipment and its components without first consulting Grouser Products. Servicing the Dozer: 1. Read and follow all safety instructions provided by the tractor manufacturer. -
Page 4: Unpacking Components & Undercarriage Installation Instructions
Unpacking Components Unstrap and remove the lift frame, hoses, top arms, and any boxes of hardware from the undercarriage. If any components are missing, call Grouser. Undercarriage Installation Install undercarriage per the tractor specific mounting instructions. Assembling Lift Components Some assembly of Lift system components is necessary. Follow the steps listed below. Refer to Page 5 for the correct hardware and orientation of parts. -
Page 5: Description
Detail A: Scale 1:10 * Parts Not Shown Item #A for Claas Tractors (24-18239) Item #B for Steiger (24-18238), New Holland (24-18238), and JD 9R Tractors (24-18843, 24-18269 or 24-19441) Item #C for JD 9RX (24-18951), Versatile (24-18262) and Challenger Tractors (24-18255) NO. -
Page 6: Tractor Side Hydraulic Hose Routing
Hoses Not Drawn To Scale 2,14,17 Tilt Rod 1,18 Tilt Base Angle Base Angle Rod NOTE: 4 Spacers (#14) goes between plate on Top Arm and Coupler Bracket #14. All Hoses Should Be Routed Thru Hose Loop. Hoses Are Top View - Some Shown Outside Of The Hose Parts Not Shown Loop For Clarity. -
Page 7: Initial Startup Instructions
Run the blade through all the functions. If any function does not operate correctly, refer to corresponding section above and re-bleed. If problem still persists, call Grouser Products. NOTE: If blade does not function to the operator’s liking or preferred direction, swap the couplers at the rear... -
Page 8: Connecting & Disconnecting The Blade, Skid Shoe And Tilt Plate Adjustment
Connecting and Disconnecting the Blade To Connect: 1. Remove the 3/4” pin (#18 on Page 10) so the skid shoes can move freely. The blade will lean back further for easier connection onto the male quick attaches. Store the pin in the empty hole right behind the hole you just took the pin out of. -
Page 9: Angle / Tilt Function Abbreviation Key
Skid Shoe and Tilt Plate Adjustment Skid Shoe Adjustment: 1. Remove the handle from the ratchet keeper by pulling the hitch clip pin and insert into the handle on the ratchet jack. 2. Loosen the locking nut on the ratchet jack. 3. -
Page 10: Blade Assembly & Nant Blade Assembly
Detail View A Item #A for Custom Name Plate and Item #B for AG Pro Plus Name Plate Blade Length 14’ 16’ 18’ 20’ Refer to Pages 16-17 for Refer to Pages 12-13 for Quick Attach System Quick Attach System Item Part No. -
Page 11: Electric Hydraulic Angle & 2-Lever Angle System Operating Instructions
If the angle system is not used correctly, damage may occur. Please contact Grouser Products with any questions by: Phone - 701-282-7710 or 800-747-6182; Fax - 701-282-8131... -
Page 12: End Extensions
End Extension Length 1’ 2’ Only Left Side Shown Item No. Part No. Description Qty. Qty. 15-13990-1-L Slant Top 1’ End Extension cmb - Left 15-13990-1-R Slant Top 1’ End Extension cmb - Right 15-13990-2-L Slant Top 2’ End Extension cmb - Left 15-13990-2-R Slant Top 2’... -
Page 13: Angle Hydraulic Components
Hoses Not Drawn To Scale Item No. Qty. Part No. Description 25-34342 Tappet Quick Coupler Male 25-3453 Pioneer Dust Cap Tilt (Green) 25-3454 Pioneer Dust Plug Tilt (Green) 26-34711 4 x 8 Cylinder W/ Cast Clevis Ends 31-34050 Straight Thread Elbow 90° JIC x O-Ring (6801-8-8) 31-34051 Straight Thread Elbow 90°... -
Page 14: Quick Attach System
Note: Angle frame may look slightly different than what is on your system. Some Parts Hidden For Clarity Item No. Qty. Part No. Description 11-3049 Bell Crank Weld 16-20011 1/4” x 2-3/4” Hex Bolt Gr 5 NC 16-20125 1/2” x 1-1/4” Hex Bolt Gr 5 NC 16-20130 1/2”... - Page 15 Qty 2.
-
Page 16: Hydraulic Angle - Hydraulic Tilt & Hydraulic Angle - No Tilt System
Item Qty. Part No. Description 11-14640-L 770 Series Angle Arm Left 11-14640-R 770 Series Angle Arm Right 11-14650 770 Series Stabilizer Arm 14-9366 Non Tilt Bar 16-20036 5/16” x 1-1/2” Hex Bolt Gr 5 NC 16-20043 5/16” x 3-1/4” Hex Bolt Gr 5 NC 16-20220 3/4”... -
Page 18: Hydraulic Angle - Hydraulic Tilt & Hydraulic Angle - No Tilt Hose Routing (Blade Side)
Hoses Not Drawn To Scale #3 for HAHT #1 for HANT... - Page 19 Configuration HAHT HANT Item No. Part No. Description Qty. Qty. 16-20036 5/16” x 1-1/2” Hex Bolt Gr 5 NC 16-20040 5/16” x 2-1/2” Hex Bolt Gr 5 NC 16-20043 5/16” x 3-1/4” Hex Bolt Gr 5 NC 16-35C616 3/8” x 1” Flanged Bolt 18-3074 Hose Hold Down Clamp 18-3075...
-
Page 22: Angle Wire Harness
C3 - Blade Break Away C6 & C7 - Left and Right Relay C2 - Selector Switch C8 & C9 - Coil C1 - Power Supply Part Number: 69-14675 C3 - Blade Break Away Part Number: 69-14676 C4 & C5 - Left and Right Proximity Valve Part Number: 69-14677 Right Angle Cyylinder... -
Page 24: Contact Us, Improvements, & Warranty
If such equipment is found to be defective within two years, it is the obligation of Grouser Products under this warranty to repair or replace (exclusive of the cost of labor and transportation), any equipment or parts, in the judgment of Grouser Products to be defective in material or workmanship.
