FH-443 Front Hitch
Owner's Manual & Parts Book
Grouser Products
755 2nd Ave NW - West Fargo, ND 58078
Phone: 1-800-747-6182
Fax: 1-701-282-8131
E-mail: grouser@grouser.com
Website: www.grouser.com
PN: 42471
Serial Number: 10206644-Current
Purchase Date
Serial Number
Model Number
Tractor Model
Dealer
Date 9-18-2020
Advertisement
Related Manuals for Grouser Products FH-443
Summary of Contents for Grouser Products FH-443
- Page 1 FH-443 Front Hitch Owner’s Manual & Parts Book Purchase Date Grouser Products Serial Number 755 2nd Ave NW - West Fargo, ND 58078 Model Number Phone: 1-800-747-6182 Fax: 1-701-282-8131 Tractor Model E-mail: grouser@grouser.com Dealer Website: www.grouser.com PN: 42471 Serial Number: 10206644-Current...
- Page 2 Thank you for your recent purchase of a Grouser FH-440 Front Hitch. Welcome to the family of satisfied Grouser Front Hitch owners. Grouser Products is committed to offering quality products to help professionals in their daily jobs. We are also committed to providing you the highest level of customer satisfaction possible. Again, thank you for your patronage.
- Page 3 4. Make sure the area is clear of people before moving any equipment. 5. Do not modify or permit anyone else to modify or alter the equipment and its components without first consulting Grouser Products. 6. Lower the blade to the ground when not in use.
- Page 4 WARNING Cancer and Reproductive Harm For more information go to www.P65Warnings.ca.gov 27-40962 PN: 27-40962 WARNING INSURE THERE IS ADEQUATE CLEARANCE BETWEEN TIRES AND BACK OF BLADE SYSTEM SEE OWNER’S MANUAL FOR CORRECT EXTENSION TO GAIN ADEQUATE CLEARANCE 27-9503 27-40425 PN: 27-9503 PN: 27-2409 PN: 27-40425 Left and Right Side...
- Page 5 Due to the harsh environment this equipment operates in, the following tasks should be performed every 10 hours or less . • Inspect all equipment before operation for existing or potential damage. • Lubricate all joints with high quality grease. See below for grease locations. •...
- Page 6 DETAIL A...
- Page 7 ITEM Item Qty. PART NO. Qty. Part No. DESCRIPTION Description 11-19000 FH-440 Lower Arm 11-19000 Lower Arm 11-19010 Top Arm 11-19010 FH-440 Top Arm 16-20035 5/16" x 1-1/4" Hex Bolt Gr. 5 16-20035 5/16” x 1-1/4“ Hex Bolt Gr 5 NC 16-20125 1/2"...
- Page 8 42720-A ITEM NO. Qty. PART NO. DESCRIPTION 16-20218 3/4" x 2" Hex Bolt Gr.5 NC 18-42720 Bracket, Quick Hook 43-42599 57-20747 3/4" Flat Washer 70-20607 3/4" Center Lock Hex Nut Gr 2 NC Note: After top link is adjusted, torque bolts to 260 ft-lbs. 42710-A ITEM NO.
- Page 9 Mounts May Vary Some parts hidden for clarity See Page 10 for hydraulic schematic. Configuration HAHT HANT Item Part No. Description Qty. Qty. 16-35C612 3/8” x 3/4” Flanged Bolt 16-20037 5/16” x 1-3/4 “ Hex Bolt Gr 5 NC 18-19311-03-P-087 Hose Clamp (TS-CLH-03-P-087) 18-19312-03 Twin Cover Plate (TS-TCP-03-Z)
- Page 10 Tilt Cylinder Angle Cylinder Left Angle Cylinder Right Green Spiral Band Green Spiral Band Red Spiral Band Red Spiral Band & Green Cap & Green Cap & Red Cap & Red Cap Tilt Disconnects Angle Disconnects Green Spiral Band Red Spiral Band Green Spiral Band Red Spiral Band &...
- Page 11 Page Left Blank Intentionally...
-
