Grouser Products Ag Pro Plus Installation Instructions Manual
Versatile 350-550 wheeled
Hide thumbs
Also See for Ag Pro Plus:
- Owner's manual & parts book (24 pages) ,
- Installation instructions manual (12 pages) ,
- Owner's manual & parts book (24 pages)
Related Manuals for Grouser Products Ag Pro Plus
Summary of Contents for Grouser Products Ag Pro Plus
- Page 1 Ag Pro Plus/Ag Pro SS Versatile 350-550 Wheeled Undercarriage Installation Instructions Purchase Date Serial Number Model Number Tractor Model Dealer PN: 63-19645-A Serial No: 10204178-10204856 Date 2-7-2017...
-
Page 2: Torque Specifications
Contact Us, Improvements, & Warranty To The Owner This manual contains information concerning the operation, adjustment, and maintenance of the Ag Pro Plus dozer system. You have purchased dependable, long lasting equipment, but only by proper care and operation can you expect to receive the performance and long service built into our products. -
Page 3: Safety Precautions
The Dozer: 1. The Ag Pro Plus Dozer should be operated only by those who are responsible and instructed to do so. 2. Read the owner’s manual carefully before using this equipment. Lack of operating knowledge can lead to accidents. - Page 4 • Do not modify or permit anyone else to modify or alter the equipment and its components Attach the rear brackets to the rear of the without first consulting Grouser Products. undercarriage with 8 - 3/4” x 2” bolts, 16 - 3/4” washers, Note: and 8 - 3/4”...
-
Page 5: Maintenance
4. Make sure all non-rotating pins are secured properly. 5. Lubricate all joints with high quality grease. Assembling Lift Components Refer to the Ag Pro Plus Owner’s Manual & Parts Book for instructions on how to assemble the lift components. - Page 6 Note: Narrow frame uses the left rear bracket on the right side of the undercarriage and the right bracket on the left side of the undercarriage as shown in the diagram below. Narrow Frame (Versatile 350-400) Bracket Orientation Wide Frame (Versatile 450-550) Bracket Orientation 19 15...
- Page 7 Versatile T4 Shim Plate (.125") 44-15967 Versatile T4 Shim Plate (.06") 44-19646 Plate, Hose Cover 54-19645 Undercarriage Weld, Ag Pro Plus 15 57-20744 1/2" Flat Washer 36 57-20757 3/4" Flat Washer - 1-1/2" OD 12 57-3680 3/4" ID x 2.00 OD x .375" Heavy Washer CZ Plated 70-20604 1/2"...
-
Page 8: Hose Routing
Hose Routing Route hoses through the hose loops on the SCV Group A SCV Group B undercarriage. Lift - Orange Tilt - Green Lift Up Tilt Right Lift Cylinder Rod Tilt Cylinder Base Lift - Orange Tilt - Green Lift Down Tilt Left Lift Cylinder Base Tilt Cylinder Rod... - Page 9 Tow Cable Installation Note: Your undercarriage may vary slightly from the one shown in the pictures below, but the same installation procedure will be compatible. 1. Add 2 spacers in between the cable holder and the tractor frame by the front tires. Use a 5/8” x 6” bolt (PN: 16-20200), 2 - 5/8”...
- Page 10 Notes...
- Page 11 Notes...
-
Page 12: Warranty
Contact Us As always, if you have any questions about your Ag Pro Plus undercarriage or other products made by Grouser, feel free to contact us. Grouser Products 755 2nd Ave NW - West Fargo, ND 58078 Phone: 1-800-747-6182 Fax: 1-701-282-8131 E-mail: grouser@grouser.com...
