760 Owner's Manual
&
Parts Book
Purchase Date
Serial Number
Model Number
Tractor Model
Dealer
PN: 63-18818
Date 4-21-2015

Advertisement

loading
Need help?

Need help?

Do you have a question about the 760 and is the answer not in the manual?

Questions and answers

Summary of Contents for Grouser Products 760

  • Page 1 760 Owner’s Manual & Parts Book Purchase Date Serial Number Model Number Tractor Model Dealer PN: 63-18818 Date 4-21-2015...
  • Page 2 27-28 To The Owner This manual contains information concerning the operation, adjustment, and maintenance of the 760 blade assembly. You have purchased dependable, long lasting equipment, but only by proper care and operation can you expect to receive the performance and long service built into our products. Please have all operators read this manual carefully and keep the manual available for ready reference.
  • Page 3 The Dozer: 1. The 760 Dozer should be operated only by those who are responsible and instructed to do so. 2. Read the owner’s manual carefully before using this equipment. Lack of operating knowledge can lead to accidents.
  • Page 4 Connecting and Disconnecting the Blade To connect the blade follow Steps #19-26 on Page 8. To disconnect the blade, set the blade on the ground, unhook all of the couplers on the top arm and pull the 3/4” pin (Part #15 on Page5) from the mushroom skid shoe link (#27 on Page 5) and store the pin in the empty hole on blade side of the skid shoe mount.
  • Page 5 Item #A for Custom Name Plate and Item #B for AG Pro Dozer Name Plate Blade Length 14’ 16’ 18’ 20’ Item Part No. Description Qty. Qty. Qty. Qty. 15-18465-XX AG Pro Blade XX’ - Slant Top 15-18475-XX AG Pro NANT Blade XX’ - Slant Top 15-14730-XX 12’...
  • Page 6 Hydraulic Instructions Prior to operating the blade, bleed all air out of the hydraulic system. Start with the furthest location away from the remote until all air is out. Hydraulic Angle System Operating Instructions If your Grouser blade was purchased with the Hydraulic Angle Option, you will have the ability to angle the blade 30 degrees left or right.
  • Page 7 If the angle system is not used correctly, frame damage may occur. Some damaged frames can be repaired, please contact Grouser Products for repair instructions if needed. Please contact Grouser Products with any questions by: Phone - 701-282-7710 or 800-747-6182;...
  • Page 8 To disconnect the blade, see Page 4. Initial System Startup Start the tractor and run the blade thru all the functions. If any function does not work properly, bleeding of the system may be required. If problem still persists, call Grouser Products.
  • Page 9 4x20 Long Cylinder - Bushed Tube Ends (647267) 31-11699-10-8 JIC Union (2403-10-8) 31-34040 Straight JIC x O-Ring (6400-8-8) 31-6400-10-8 Straight JIC x O-Ring (6400-10-8) 32-17250 760 Round Tube w/Guard Lift Frame 34-12932 Cylinder Saddle (ZR518) 34-12994 Hose Clamp 34-14961 Manual Canister 35-12931...
  • Page 10 Quick Attach (See Pages 12-13) Quick Attach Lever System (See Pages 12-13) Item Qty. Part No. Description 16-20128 1/2” x 2” Hex Bolt Gr 5 NC 16-35C612 3/8” x 3/4” Flanged Bolt Refer to Page 5 for Refer to Page 7 for 18-14658 NAXT Center Bracket Skid Shoe Parts...
  • Page 11 Hoses Not Drawn To Scale Item No. Qty. Part No. Description 25-34342 Tappet Quick Coupler Male 25-3453 Pioneer Dust Cap Tilt (Green) 25-3454 Pioneer Dust Plug Tilt (Green) 26-34711 4 x 8 Cylinder W/ Cast Clevis Ends 31-34050 Straight Thread Elbow 90° JIC x O-Ring (6801-8-8) 31-34051 Straight Thread Elbow 90°...
  • Page 12 Some Parts Hidden For Clarity Item #A for HAHT & HANT and Item #B for NAHT & NANT Item No. Qty. Part No. Description 11-3049 Bell Crank Weld 16-20040 5/16” x 2-1/2” Hex Bolt Gr 5 NC 16-20125 1/2” x 1-1/4” Hex Bolt Gr 5 NC 16-20132 1/2”...
  • Page 13 Qty 2.
  • Page 14 Item Qty. Part No. Description 11-5055 Stabilizer Arm 11-8082 Angle Arm Right 11-9039 Angle Arm Left 14-9366 Non Tilt Bar 16-20132 1/2” x 3” Hex Bolt Gr 5 NC 16-20424 1/2” x 3-1/2” Hex Bolt Gr 8 NC 16-20427 1/2” x 4-1/2” Hex Bolt Gr 8 NC 16-20564 1”...
  • Page 16 Hoses Not Drawn To Scale...
  • Page 17 Configuration HAHT HANT Item No. Part No. Description Qty. Qty. 16-20036 5/16” x 1-1/2” Hex Bolt Gr 5 NC 16-20040 5/16” x 2-1/2” Hex Bolt Gr 5 NC 16-20043 5/16” x 3-1/4” Hex Bolt Gr 5 NC 18-3074 Hose Hold Down Clamp 18-3075 Hose Hold Down Clamp Plate 25-34342...
  • Page 18 Hoses Not Drawn To Scale...
  • Page 19 Item No. Qty. Part No. Description 16-20034 5/16” x 1” Hex Bolt Gr 5 NC 16-20036 5/16” x 1-1/2” Hex Bolt Gr 5 NC 16-20040 5/16” x 2-1/2” Hex Bolt Gr 5 NC 16-20048 5/16” x 5” Hex Bolt Gr 5 NC 18-14695 Bracket, Relief Valve 18-3074...
  • Page 20 Hoses Not Drawn To Scale All Hoses Should Be Routed Thru Hose Loop. Hoses Are Shown Outside Hose Loop For Clarity. See Pages 22-23 for hydraulic connections. See Pages 25-26 for hydraulic schematics. * Parts Not Shown Configuration HAHT - 2 HANT - 2 HAHT HANT...
  • Page 21 33.88” -8 Formed Steel Line (Tilt) 35-14353 36.13” -8 Formed Steel Line (Left Lift) 35-14354 26.63” -8 Formed Steel Line (760 Right Lift) 35-14355 29.63” -8 Formed Steel Line (760 Right Lift) 35-14824 29.38” -8 Formed Steel Line (2-Stick - Left Side) 35-31132 69”...
  • Page 22 33.88” -8 Formed Steel Line (Tilt) 35-14353 36.13” -8 Formed Steel Line (Left Lift) 35-14354 26.63” -8 Formed Steel Line (760 Right Lift) 35-14355 29.63” -8 Formed Steel Line (760 Right Lift) 35-14824 29.38” -8 Formed Steel Line (2-Stick - Left Side)
  • Page 23 Right Lift Rod Right Lift Base Only Left Side Shown * Parts Not Shown End Extension Length 1’ 2’ Item No. Part No. Description Qty. Qty. 15-13990-1-L Slant Top 1’ End Extension cmb - Left 15-13990-1-R Slant Top 1’ End Extension cmb - Right 15-13990-2-L Slant Top 2’...
  • Page 27 Page Left Blank Intentionally...
  • Page 28 Contact Us As always, if you have any questions about your 760 Dozer or other products made by Grouser, feel free to contact us. Grouser Products 755 2nd Ave NW - West Fargo, ND 58078 Phone: 1-800-747-6182 Fax: 1-701-282-8131 E-mail: grouser@grouser.com Website: www.grouser.com...
