Grouser Products Ag Pro Classic Owner's Manual & Parts Book

Hide thumbs

Advertisement

Quick Links

Download this manual
Owner's Manual & Parts Book
Grouser Products
755 2nd Ave NW - West Fargo, ND 58078
Phone: 1-800-747-6182
Fax: 1-701-282-8131
E-mail: grouser@grouser.com
Website: www.grouser.com
PN: 41667
Ag Pro Classic
Serial Number: 10205775-...
Purchase Date
Serial Number
Model Number
Tractor Model
Dealer
Date 6-19-2019

Advertisement

loading
Need help?

Need help?

Do you have a question about the Ag Pro Classic and is the answer not in the manual?

Questions and answers

Related Manuals for Grouser Products Ag Pro Classic

Summary of Contents for Grouser Products Ag Pro Classic

  • Page 1 Ag Pro Classic Owner’s Manual & Parts Book Purchase Date Serial Number Grouser Products 755 2nd Ave NW - West Fargo, ND 58078 Model Number Phone: 1-800-747-6182 Fax: 1-701-282-8131 Tractor Model E-mail: grouser@grouser.com Dealer Website: www.grouser.com PN: 41667 Serial Number: 10205775-...
  • Page 2 Description Page Welcome To The Owner Decals Tractor Side Hydraulics Connecting and Disconnecting Hydraulic Schematics Wire Harness you. a timely manner.
  • Page 3 The Ag Pro Classic Dozer: Products. Servicing the Ag Pro Classic Dozer 2. Always use proper personal safety gear when performing maintenance on equipment. attention immediately. Storing the Ag Pro Classic: Torque - Dry (ft–lbs)
  • Page 4 AG PRO CLASSIC PN: 27-14845 PN: 27-14842-XX XX = Length of Blade PN: 27-40951 PN: 27-2409 WARNING Cancer and Reproductive Harm For more information go to www.P65Warnings.ca.gov 27-40962 PN: 27-40962 PN: 27-9504 STOP PROPER RATCHET STORAGE Handle Ratchet Ratchet Handle Keeper Ratchet Handle Must Be Secured Between The Ratchet Keeper And...
  • Page 5 Due to the harsh environment this equipment operates in, the following tasks should be performed every 10 hours or less. Dozer. For cutting edge information, see pages 34 . 2 Places 2 Places 2 Places 2 Places 2 Places 2 Places 2 Places 2 Places 2 Places...
  • Page 6 and orientation of parts. keep top arm pins tight and in place. Only use as many as needed until pin is tight. * Quantity May Vary ITEM NO. QTY. PART NO. DESCRIPTION 11-19035-L Nested Top Arm Weld 11-19035-R Nested Top Arm Weld 16-20004 1/4"...
  • Page 7 Note: Refer to Pages 8-10 for the correct hose lengths and hose location. HAHT...
  • Page 8 ITEM HAHT 2-Stick HAHT Electric HANT 2-Stick HANT Electric NAHT NANT PART NO. QTY. QTY. QTY. QTY. QTY. QTY. DESCRIPTION 16-18957 5/16” x 3-1/4” Allen Head Screw 16-812525 8mm x 1.25mm x 25mm Metric Hex Bolt Gr 10.9 25-19861 Multi-Coupling Plate - 5 Port - Fixed 25-19863 Multi-Coupling Plate - 5 Port - Cap 25-19864...
  • Page 9 ITEM HAHT 2-Stick HAHT Electric HANT 2-Stick HANT Electric NAHT NANT PART NO. QTY. QTY. QTY. QTY. QTY. QTY. DESCRIPTION 34-12932 Cylinder Saddle 34-16578 Hose Clamp (worm drive - 4.5) 34-18888-GR -12 Green - Spiral Band 34-18888-OR -12 Orange - Spiral Band 34-18888-RD -12 Red - Spiral Band 34-18888-YL...
  • Page 10 ITEM HAHT Electric HANT 2-Stick HANT Electric NAHT PART NO. DESCRIPTION QTY. QTY. QTY. QTY. 16-812525 8mm x 1.25mm x 25mm Metric Hex Bolt Gr 10.9 25-19864 Multi-Coupling Plate - 4 Port Fixed 25-19867 Multi-Coupling Plate - 4 Port - Cap 25-19868 Multi-Coupling Plate - 2 Port - Fixed 25-19871...

  • Page 11: Tilt Function

    Lift Function: 2. Actuate the raise function to supply oil to the rod end of the cylinders. Tilt Function: left cylinder. the left cylinder. 6. Actuate the tilt function in the opposite direction. Angle Function: 5. Actuate the left angle function in the opposite direction. 7.
  • Page 12 To Connect: Note: If necessary, use a spotter to help center the blade on the lift system. quick attaches. 6. Push the quick attach lock handle to engage the quick attach pins and lift the locking latch to lock the handle in place. harness on the top arm.
  • Page 13 With the Electric Hydraulic Angle Option when angled dozing. With the right cylinder. important to your system. CORRECT CORRECT Incorrect (Left or Right) CAUTION: Do not bypass the safety relief valve and plumb each cylinder to separate valves on the tractor. Allen Screw...

  • Page 14: Skid Shoe Adjustment

    Skid Shoe Adjustment: Storage handle to raise or lower the skid shoes. shoe in the desired direction. Handle Handle and the ratchet keeper. Secure the handle to the ratchet keeper with the hitch clip pin. Skid Shoe Figure 1 skid shoes. Handle Preferred Method: Non-Preferred Method:...
  • Page 15 5/8" Hex Top Lock Nut Gr 5 NC 70-20647 3/4" Hex Top Lock Nut Gr 5 NC Note: Ag Pro Classic 12' Blades are not equipped with mushroom skid shoes and can only use the skid shoe mounted underneath the blade.
  • Page 16 ITEM NO. PART NO. 14'/QTY. 16'/QTY. 18'/QTY. 20'/QTY. DESCRIPTION 15-18465-14 Blade Weld 15-18465-16 Blade Weld 15-18465-18 Blade Weld 15-18465-20 Blade Weld 15-18520-14 Top Extension Weld 15-18520-16 Top Extension Weld 15-18520-18 Top Extension Weld 15-18520-20 Top Extension Weld 16-18945 1" x 3" Hex Bolt Gr 5 NC - Short Thread 16-20538 7/8"...
  • Page 17 Item #A for Ag Pro Dozer Name Plate and Item #B for Custom Name Plate ITEM NO. PART NO. 14'/QTY. 16'/QTY. 18'/QTY. 20'/QTY. DESCRIPTION Grouser Dozer Metal Serial Tag 29-11118-6 6' - 3/4”x 8” Cutting Edge 29-11118-8 8' - 3/4”x 8” Cutting Edge 29-11118-7 7' - 3/4”x 8”...
  • Page 22 ITEM NO. QTY. PART NO. DESCRIPTION DETAIL A 16-20035 5/16" x 1-1/4 " Hex Bolt Gr 5 NC 16-20037 5/16" x 1-3/4" Hex Bolt Gr 5 NC 16-20040 5/16" x 2-1/2" Hex Bolt Gr 5 NC 16-20077 3/8" x 4-1/2" Hex Bolt Gr 5 NC 16-35C612 3/8"...
  • Page 23 ITEM NO. QTY. PART NO. DESCRIPTION 31-13332 -6 SAE Breather Fitting DETAIL B 11 31-34040 Straight JIC x O-Ring 31-34050 Straight Thread Elbow 90° JIC x O-Ring 31-34060 Branch Tee JIC x O-Ring 31-34100 Swivel Nut Elbow 90° JIC 34-18888-GR -12 Green - Spiral Band 34-18888-RD -12 Red - Spiral Band...
  • Page 24 ITEM NO. QTY. PART NO. DESCRIPTION 14-9366R2 Ag Pro Non Tilt Bar 16-20034 5/16" x 1" Hex Bolt Gr 5 NC 16-20037 5/16" x 1-3/4" Hex Bolt Gr 5 NC 16-20040 5/16" x 2-1/2" Hex Bolt Gr 5 NC 16-20564 1"...
  • Page 25 ITEM NO. QTY. PART NO. DESCRIPTION 31-34040 Straight JIC x O-Ring 31-34050 Straight Thread Elbow 90° JIC x O-Ring 31-34070 Run Tee JIC x O-Ring 31-34100 Swivel Nut Elbow 90° JIC 31-34123 Hex Socket O-Ring Plug 34-18888-RD -12 Red - Spiral Band 34-18888-YL -12 Yellow - Spiral Band 35-30132...
  • Page 26 ITEM NO. QTY. PART NO. DESCRIPTION 14-9366R2 Ag Pro Non Tilt Bar 16-20037 5/16" x 1-3/4" Hex Bolt Gr 5 NC 16-20040 5/16" x 2-1/2" Hex Bolt Gr 5 NC 16-20077 3/8" x 4-1/2" Hex Bolt Gr 5 NC 16-20564 1"...
  • Page 27 ITEM NO. QTY. PART NO. DESCRIPTION 34-18888-RD -12 Red - Spiral Band 35-30132 69" x 1/2" -8 JIC/-8 JIC Hose 35-30133 77" x 1/2" -8JIC/-8JIC Hose 35-30141 96" x 1/2" -8 JIC/-8 JIC Hose 56-13305 Hydraulic Valve 57-20740 1/4" Flat Washer 57-20744 1/2"...
  • Page 28 ITEM NO. QTY. PART NO. DESCRIPTION 11-3049 Bell Crank 16-20011 1/4" x 2-3/4" Hex Bolt Gr 5 NC 16-20125 1/2" x 1-1/4" Hex Bolt Gr 5 NC 16-20128 1/2" x 2" NC Hex Bolt Gr. 5" 16-20130 1/2" x 2-1/2" Hex Bolt Gr 5 NC 16-20560 1"...
  • Page 29 DETAIL B Tilt Rod E Green Spiral Band (X1) Tilt Base F Green Spiral Band (X2) Note: View is from Multi-Coupler Installed on Top Arm. All hoses are marked with colored spiral bands and should be attached to designated ports on the Multi-Coupler.
  • Page 30 ITEM ITEM 14'/QTY. 16'/QTY. 18'/QTY. 20'/QTY. PART NO. 14'/QTY. 16'/QTY. 18'/QTY. 20'/QTY. PART NO. DESCRIPTION DESCRIPTION 15-18475-14 Blade Weld 15-18475-14 Blade Weld 15-18475-16 Blade Weld 15-18475-16 Blade Weld 15-18475-18 Blade Weld 15-18475-18 Blade Weld 15-18475-20 Blade Weld 15-18475-20 Blade Weld 15-18520-14 Top Extension Weld 15-18520-14 Top Extension Weld 15-18520-16 Top Extension Weld...
  • Page 31 ITEM NO. QTY. PART NO. DESCRIPTION 11-3049 Bell Crank 16-20011 1/4" x 2-3/4" Hex Bolt Gr 5 NC 16-20125 1/2" x 1-1/4" Hex Bolt Gr 5 NC 16-20130 1/2" x 2-1/2" Hex Bolt Gr 5 NC 16-21065 3/8" x 1-1/4" Carriage Bolt Gr 5 NC 16-21125 1/2"...
  • Page 32 ITEM 40920-1-A 40920-2-A End Extensions NO. PART NO. QTY. QTY. DESCRIPTION ITEM 19346-K 19345-K End Plates NO. PART NO. QTY. QTY. DESCRIPTION...
  • Page 33 ITEM 19985-1-A 19985-2-A Top Extensions For End Extensions NO. PART NO. QTY. QTY. DESCRIPTION ITEM 19347-K Top Extensions For End Plates NO. PART NO. QTY. DESCRIPTION...
  • Page 34 11118-1K 11118-2K 11118-3K 11118-4K 11118-5K 11118-6K 11118-7K 11118-8K ITEM QTY. QTY. QTY. QTY. QTY. QTY. QTY. QTY. PART NO. DESCRIPTION 11118-12K 11118-14K 11118-16K 11118-18K 11118-20K ITEM QTY. QTY. QTY. QTY. QTY. PART NO. DESCRIPTION 15458-1K 15458-K ITEM QTY. QTY. NO. PART NO. DESCRIPTION...
  • Page 35 8725-1K 8725-K ITEM QTY. QTY. PART NO. DESCRIPTION Note: Only used on blades with 6" cutting edges. 40980-1K 40980-2K 16710-1K 16710-2K ITEM QTY. QTY. QTY. QTY. NO. PART NO. DESCRIPTION Note: Only used on blades with 8" cutting edges.
  • Page 36 Before Each Use: Fixed Half Mobile Half Disconnect the mobile half from the parking station and the cap from the fixed half. Check that there is no contamination (salt, sand, dirt, etc.): On the pins. Inside the cam. In the locking mechanism area. On the face of the plates and couplings.
  • Page 37 Cleaning The Female Bushing: Cleaning The Male Interface Seal Make sure the coupling is securely fastened Make sure the coupling is securely fastened Use caution not to damage or scratch the seal when inserting the wire. surfaces for contamination. contamination. wipe surfaces with a soft cloth, or use wipe surfaces with a soft cloth, or use out.
  • Page 38 Colored Lines = Quantity of Colored Spiral Bands Tilt Cylinder Tilt Cylinder Angle Cylinder Left Angle Cylinder Right Hydraulic Multi-Couplers Left Right Lift Cylinder Lift Cylinder Left Left Right Right Tilt Right Tilt Left Lift Up Lift Down Angle Angle Angle Angle Side Up Side Up...
  • Page 39 Colored Lines = Quantity of Colored Spiral Bands Tilt Cylinder Tilt Cylinder Angle Cylinder Left Angle Cylinder Right Hydraulic Multi-Couplers Left Right Lift Cylinder Lift Cylinder Angle Angle Tilt Right Tilt Left Lift Up Lift Down Retract Extend Side Up Side Up...

  • Page 44: Warranty

    Contact Us free to contact us. Grouser Products Phone: Fax: E-mail: Website: www.grouser.com Improvements Warranty...
