- Page 1 19’ U-Blade w/ Adjustable Skid Shoes 770HD Steiger Quad 550 Owner’s Manual & Parts Book For Models: Case Steiger Quad - 450, 500, 550, 600 Purchase Date Serial Number Model Number Tractor Model Dealer PN: 63-12826 Date 4-9-2012...
- Page 2 Please have all operators read this manual carefully and keep the manual available for ready reference. If you have any questions or concerns, contact Grouser Products. Angle / Tilt Function Abbreviation Key...
- Page 3 4. Make sure the area is clear of people before moving any equipment. 5. Do not modify or permit anyone else to modify or alter the equipment and its components without first consulting Grouser Products. Servicing the Dozer: 1. Read and follow all safety instructions provided by the tractor manufacturer.
- Page 4 Remove existing toolboxes, front weights, and tow cable holder if equipped. Tow cable can be reinstalled later if a bracket is purchased from Grouser Products. If the bottom covers (PN: 44-14382-R,L) are not factory installed, attach to U/C with 1/2” x 1-1/4” bolts (PN: 16-20125) and 1/2”...
- Page 5 5,18,20,21 5,18,20,21 3,17 3,17 3,17 DETAIL A SCALE 1 : 17 5,19,19,21 6,16 Reuse Original Bolts 3,17 4,20 3,17 Item No. Qty. Part No. Description 1 11-15140-L Upper Undercarriage Support Arm Left - Quad 1 11-15140-R Upper Undercarriage Support Arm Right - Quad 20 16-20125 1/2"...
- Page 6 Refer to Page #11 for clarification on the wire harness ends. Initial System Startup Start the tractor and run the blade thru all the functions. If any function does not work properly, bleeding of the system may be required. If problem still persists, call Grouser Products.
- Page 7 (1-Left) * Parts Not Shown Item Qty. Part No. Description 11-16000-L HD Manual Pitch Top Arm, Female - Left 11-16000-R HD Manual Pitch Top Arm, Female - Right 11-16005 HD Manual Pitch Top Arm, Male 16-20002 1/4” x 3/4“ Hex Bolt Gr 5 NC 16-20216 3/4”...
- Page 8 Hose Routing Note: Installer is responsible to route hoses in a practical manner. The hoses need to be routed away from sharp corners and moving parts and need to be secure. 1. Route the hoses from the bulkhead fittings at the middle of the undercarriage thru all the hose loops on the undercarriage.
- Page 9 If the angle system is not used correctly, damage may occur. Please contact Grouser Products with any questions by: Phone - 701-282-7710 or 800-747-6182; Fax - 701-282-8131...
- Page 10 Skid Shoe and Tilt Plate Adjustment THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE PROPERTY OF GROUSER PRODUCTS INC ANY REPRODUCTION IN PART OR WHOLE WITHOUT THE WRITTEN PERMISSION OF GROUSER PRODUCTS INC IS PROHIBITED. Skid Shoe Adjustment: 1. Raise and secure blade to access skid shoe bolts and nuts.
- Page 11 C3 - Blade Break Away C2 - Selector Switch C6 & C7 - Left and Right Relay C8 & C9 - Coil C1 - Power Supply Part Number: 69-14675 C3 - Blade Break Away See Page 18 for Attaching to Bracket Part Number: 69-14682 C4 &...
- Page 12 Some Parts Hidden For Clarity Item No. Qty. Part No. Description 11-3049 Bell Crank Weld 16-20125 1/2” x 1-1/4” Hex Bolt Gr 5 NC 16-20132 1/2” x 3” Hex Bolt Gr 5 NC 16-20560 1” x 2-1/2” Hex Bolt Gr 8 NC 16-21064 3/8”...
- Page 13 Qty 2.
- Page 14 Item Qty. Part No. Description 11-14640-L 770 Series Angle Arm Left 11-14640-R 770 Series Angle Arm Right 11-16010 770HD Series Stabilizer Arm 16-20220 3/4” x 2-1/2” Hex Bolt Gr 5 NC 16-20424 1/2” x 3-1/2” Hex Bolt Gr 8 NC 16-20427 1/2”...
- Page 16 Hoses Not Drawn To Scale...
- Page 17 Item Qty. Part No. Description 16-20034 5/16” x 1” Hex Bolt Gr 5 NC 16-20038 5/16” x 2” Hex Bolt Gr 5 NC 16-20043 5/16” x 3-1/4” Hex Bolt Gr 5 NC 16-20048 5/16” x 5” Hex Bolt Gr 5 NC 16-35C616 3/8”...
- Page 18 Hoses Not Drawn To Scale * Parts Not Shown Item Qty. Part No. Description 16-35C612 3/8” x 3/4” Flanged Bolt 16-35C616 3/8” x 1” Flanged Bolt 16-20002 1/4” x 3/4” Hex Bolt Gr 5 NC 18-14737 700 Series Female Coupler Mount - Universal 18-15580-L Bracket, Hydraulic Cover - Top Left 18-15580-R...
- Page 19 * Parts Not Shown Item No. Qty. Part No. Description 34-14898 Dome Plug (3044) 35-14351 31.63” -8 Formed Steel Line (Angle) 35-14352 33.88” -8 Formed Steel Line (Tilt) 35-15556 36.19” -10 Formed Steel Line (HD Left Lift) 35-15557 36.22” -10 Formed Steel Line (770HD Right Lift) 35-15558 39.22”...
- Page 20 Angle Base Angle Rod Tilt Base Tilt Rod Adjustable Skid Shoe (Base) Adjustable Skid Shoe (Rod) Right Lift Rod Adjustable Skid Shoe (Rod) Tilt Rod Angle Rod Left Lift Rod Right Lift Base Angle Base Left Lift Base Adjustable Skid Shoe (Base) Tilt Base Item...
- Page 21 Angle Rod Tilt Rod Adjustable Skid Shoe (Rod) Lift Rod Adjustable Skid Shoe (Base) Lift Base Tilt Base Angle Base Item Qty. Part No. Description 16-21218 3/4” x 2” Carriage Bolt Gr 5 NC 16-35C612 3/8” x 3/4” Flanged Bolt 18-14670 770- Trunnion Mount Bracket 18-1701...
- Page 22 Item Qty. Part No. Description 15-16090 19’ U-Blade W/Adjustable Skid Shoes 16-20034 5/16” x 1” Hex Bolt Gr 5 NC 16-20038 5/16” x 2” Hex Bolt Gr 5 NC 16-20286 1” x 9” Hex Bolt Gr 5 NC 16-35C612 3/8” x 3/4” Flanged Bolt 16-20560 1”...
- Page 23 Item Qty. Part No. Description 35-30002 17” X 3/8” -8JIC/-8JIC Hose 35-30004 19” X 3/8” -8JIC/-8JIC Hose 35-30034 75” X 3/8” -8JIC/-8JIC Hose 35-30036 80” X 3/8” -8JIC/-8JIC Hose 35-30037 83” X 3/8” -8JIC/-8JIC Hose 35-30038 87” X 3/8” -8JIC/-8JIC Hose 43-13580 1”...
- Page 24 Item Qty. Part No. Description 15-16090 19’ U-Blade W/Adjustable Skid Shoes 16-21672 5/8” x 2-1/2” Plow Bolt Gr 5 NC 16-21756 3/4” x 3” Plow Bolt Gr 8 NC 16-21776 1” x 3” Plow Bolt Gr 8 NC 29-13471 Dozer Edge 10” - Center Assy 29-13472 End Bit D6H 65 - U Flat RH 29-13473...
- Page 28 If such equipment is found to be defective within one year, it is the obligation of Grouser Products under this warranty to repair or replace (exclusive of the cost of labor and transportation), any equipment or parts, in the judgment of Grouser Products to be defective in material or workmanship.
