Grouser Products AG PRO PLUS Owner's Manual & Parts Book

Hide thumbs Also See for AG PRO PLUS:

Advertisement

Quick Links

Download this manual
AG PRO PLUS - Mushroom
Owner's Manual
&
Parts Book
Purchase Date
Serial Number
Model Number
Tractor Model
Dealer
PN: 63-17759
Date 4-14-2015

Advertisement

loading
Need help?

Need help?

Do you have a question about the AG PRO PLUS and is the answer not in the manual?

Questions and answers

Related Manuals for Grouser Products AG PRO PLUS

Summary of Contents for Grouser Products AG PRO PLUS

  • Page 1 AG PRO PLUS - Mushroom Owner’s Manual & Parts Book Purchase Date Serial Number Model Number Tractor Model Dealer PN: 63-17759 Date 4-14-2015...
  • Page 2 Contact Us, Improvements, & Warranty To The Owner This manual contains information concerning the operation, adjustment, and maintenance of the Ag Pro Plus blade assembly. You have purchased dependable, long lasting equipment, but only by proper care and opera- tion can you expect to receive the performance and long service built into our products. Please have all opera- tors read this manual carefully and keep the manual available for ready reference.
  • Page 3 The Dozer: 1. The Ag Pro Plus Dozer should be operated only by those who are responsible and instructed to do so. 2. Read the owner’s manual carefully before using this equipment. Lack of operating knowledge can lead to accidents.
  • Page 4 To disconnect the blade, see Page 6. Initial System Startup Start the tractor and run the blade thru all the functions. If any function does not work properly, bleeding of the system may be required. If problem still persists, call Grouser Products.
  • Page 5 Description Qty. Part No. Description 11-18165-L Top Arm - Left 35-18240 Ag Pro Plus - Steel Line (Lift Cylinder) 11-18165-R Top Arm - Right 35-30172 318” (26.5’) x 1/2” -8JIC/-8JIC Hose 16-20002 1/4” x 3/4“ Hex Bolt Gr 5 NC 35-30183 293”...
  • Page 6 Connecting and Disconnecting the Blade To connect the blade follow Steps #19-26 on Page 4. To disconnect the blade, set the blade on the ground, unhook all of the couplers on the top arm and pull the 3/4” pin (Part #15 on Page 7) from the mushroom skid shoe link (#27 on Page 7) and store the pin in the empty hole on blade side of the skid shoe mount.
  • Page 7 Item #A for Custom Name Plate and Item #B for AG Pro Plus Name Plate Blade Length 14’ 16’ 18’ 20’ Item Part No. Description Qty. Qty. Qty. Qty. 15-18465-XX AG Pro Blade XX’ - Slant Top 15-18475-XX AG Pro NANT Blade XX’ - Slant Top 15-14730-XX 12’...
  • Page 8 Hydraulic Instructions Prior to operating the blade, bleed all air out of the hydraulic system. Start with the furthest location away from the remote until all air is out. Hydraulic Angle System Operating Instructions If your Grouser blade was purchased with the Hydraulic Angle Option, you will have the ability to angle the blade 30 degrees left or right.
  • Page 9 If the angle system is not used correctly, frame damage may occur. Some damaged frames can be repaired, please contact Grouser Products for repair instructions if needed. Please contact Grouser Products with any questions by: Phone - 701-282-7710 or 800-747-6182;...
  • Page 10 End Extension Length 1’ 2’ Only Left Side Shown Item No. Part No. Description Qty. Qty. 15-13990-1-L Slant Top 1’ End Extension cmb - Left 15-13990-1-R Slant Top 1’ End Extension cmb - Right 15-13990-2-L Slant Top 2’ End Extension cmb - Left 15-13990-2-R Slant Top 2’...
  • Page 11 Quick Attach (See Pages 12-13) Quick Attach Lever System (See Pages 12-13) Item Qty. Part No. Description 16-20128 1/2” x 2” Hex Bolt Gr 5 NC 16-35C612 3/8” x 3/4” Flanged Bolt Refer to Page 7 for 18-14658 NAXT Center Bracket Skid Shoe Parts 19-13577 NR Pin Spacer Clevis End...
  • Page 12 Some Parts Hidden For Clarity Item #A for HAHT & HANT and Item #B for NAHT & NANT Item No. Qty. Part No. Description 11-3049 Bell Crank Weld 16-20040 5/16” x 2-1/2” Hex Bolt Gr 5 NC 16-20125 1/2” x 1-1/4” Hex Bolt Gr 5 NC 16-20132 1/2”...
  • Page 13 Qty 2.
  • Page 14 Item Qty. Part No. Description 11-5055 Stabilizer Arm 11-8082 Angle Arm Right 11-9039 Angle Arm Left 14-9366 Non Tilt Bar 16-20132 1/2” x 3” Hex Bolt Gr 5 NC 16-20424 1/2” x 3-1/2” Hex Bolt Gr 8 NC 16-20427 1/2” x 4-1/2” Hex Bolt Gr 8 NC 16-20564 1”...
  • Page 16 Hoses Not Drawn To Scale...
  • Page 17 Configuration HAHT HANT Item No. Part No. Description Qty. Qty. 16-20036 5/16” x 1-1/2” Hex Bolt Gr 5 NC 16-20040 5/16” x 2-1/2” Hex Bolt Gr 5 NC 16-20043 5/16” x 3-1/4” Hex Bolt Gr 5 NC 18-3074 Hose Hold Down Clamp 18-3075 Hose Hold Down Clamp Plate 25-34342...
  • Page 18 Hoses Not Drawn To Scale...
  • Page 19 Item No. Qty. Part No. Description 16-20034 5/16” x 1” Hex Bolt Gr 5 NC 16-20036 5/16” x 1-1/2” Hex Bolt Gr 5 NC 16-20040 5/16” x 2-1/2” Hex Bolt Gr 5 NC 16-20048 5/16” x 5” Hex Bolt Gr 5 NC 18-14695 Bracket, Relief Valve 18-3074...
  • Page 20 Hoses Not Drawn To Scale 2,20 1,21 Tilt Rod Angle Rod (2-Stick Only) Tilt Base Right Angle Base (2-Stick) or Angle Base (Electric) Left Angle Base (2-Stick) or Angle Rod (Electric) Top View - Some Parts Not Shown All Hoses Should Be Routed For Clarity Thru Hose Loop.
  • Page 24 Contact Us As always, if you have any questions about your Ag Pro Plus Dozer or other products made by Grouser, feel free to contact us. Grouser Products 755 2nd Ave NW - West Fargo, ND 58078 Phone: 1-800-747-6182 Fax: 1-701-282-8131 E-mail: grouser@grouser.com...
