- Page 1 Ag Pro Plus Steiger 350-470/NH T9 Narrow Frame Undercarriage Installation Instructions Purchase Date Serial Number Model Number Tractor Model Dealer PN: 63-18680-A Date 2-9-2016...
-
Page 2: Maintenance
Contact Us, Improvements, & Warranty To The Owner This manual contains information concerning the operation, adjustment, and maintenance of the Ag Pro Plus dozer system. You have purchased dependable, long lasting equipment, but only by proper care and operation can you expect to receive the performance and long service built into our products. Please have all operators read this manual carefully and keep the manual available for ready reference. -
Page 3: Safety Precautions
The Dozer: 1. The Ag Pro Plus Dozer should be operated only by those who are responsible and instructed to do so. 2. Read the owner’s manual carefully before using this equipment. Lack of operating knowledge can lead to accidents. - Page 4 Caution: • Always use caution when working around any equipment. • Always wear safety glasses. • Follow tractor manufacturer’s safety guidelines when installing this product. 1. Read all instructions prior to performing installation. 2. If applicable, remove front weights, weight bracket, and toolbox. If a tow cable kit was purchased from Grouser, the tow cable will be reinstalled in a later step.
- Page 5 Attach the front upper support arms to the undercarriage with 2 - 1” x 3-1/4” bolts, 2 - 1” hardened flat washers, and a 1” nut on the top bolt on each side (5). 19. Attach the rear hose routing plate to the tractor frame behind the pivot point and before the drawbar.
-
Page 6: Hose Routing
Hose Routing Route hoses through the hose loops on the undercarriage and through the large loop at the rear of the undercarriage. 6. Strap the hoses to the drawbar with a set of 2. Send hoses through the bracket at the pivot point hose holding plates in 2 locations (2). - Page 7 SCV Group A SCV Group B Lift - Orange Tilt - Green Lift Up Tilt Right Lift Cylinder Rod Tilt Cylinder Base Lift - Orange Tilt - Green Lift Down Tilt Left Lift Cylinder Base Tilt Cylinder Rod SCV Group C SCV Group D Angle - Yellow Left Angle Retract...
- Page 8 THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE PROPERTY OF GROUSER PRODUCTS INC ANY REPRODUCTION IN PART OR WHOLE WITHOUT THE WRITTEN PERMISSION OF GROUSER PRODUCTS INC IS PROHIBITED. See Detail A Below DETAIL A...
- Page 9 Item #32 - Used only with 12-20 Dozer Hydraulics in place of Item #5 5 or 32 Use only if needed. See Hose Routing Page in the Mounting Instructions. GROUSER PRODUCTS INC. 755 2nd Ave NW Phone 701.282.7710 West Fargo, ND 58078 701.282.8131 WWW.GROUSER.COM...
- Page 11 Assembling Lift Components Refer to the Ag Pro Plus Owner’s Manual & Parts Book for instructions on how to assemble the lift components. Tow Cable Components Item Qty. Part No. Description 16-20540 7/8” X 2-1/2” Hex Bolt Gr 8 NC 18-19095 Tow Cable Bracket 43-16764 7/16”...
-
Page 12: Warranty
Contact Us As always, if you have any questions about your Ag Pro Plus Dozer or other products made by Grouser, feel free to contact us. Grouser Products 755 2nd Ave NW - West Fargo, ND 58078 Phone: 1-800-747-6182 Fax: 1-701-282-8131 E-mail: grouser@grouser.com...
