Service Manual AFISCOOTER S v.1.9
Ver. 01
Afiscooter s
Service manual
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Afiscooter s and is the answer not in the manual?

Questions and answers

Steve
March 6, 2025

What does error 3 mean

0
1 comments:
Mr. Anderson
May 14, 2025

Error 3 on the Afikim scooter indicates a brake fault. It could be caused by a loose connection or a damaged brake.

This answer is automatically generated

0

Related Manuals for Afikim Afiscooter s

Summary of Contents for Afikim Afiscooter s

  • Page 1 Service Manual AFISCOOTER S v.1.9 Ver. 01 Afiscooter s Service manual...

  • Page 2: Table Of Contents

    Controller Trip codes using programmer SP1 & actions to repair: 12.5 12.6 Possible Faults symptoms and repair actions: Mechanical assembly drawings Quick guide troubleshoot Afiscooter S electric faults: Flow chart for electric trouble shoot: Electrical diagrams - General Wiring diagram...

  • Page 3: Safety Instructions

    Service Manual AFISCOOTER S v.1.9 Ver. 01 Safety instructions General: 1.1.1 Technicians who are servicing the scooter should be authorized to service the scooter. 1.1.2 Technicians who are servicing the scooter should be aware and follow all safety instructions within the User Manual.

  • Page 4: Specific Tools For Technicians

    Service Manual AFISCOOTER S v.1.9 Ver. 01 Specific Tools for technicians  Standard tool box (wrenches, socket-head cap screw, hexagon keys, Phillips (crosshead) tip and/or screwdrivers, etc.)  Voltmeter (To measure 24VDC)  Air pressure gauge (To measure 35 psi) ...

  • Page 5: Options / Accessories Assembling Drawing /Instructions

    Service Manual AFISCOOTER S v.1.9 Ver. 01 Options / Accessories assembling An integrated canopy consisting of a polycarbonate window, a steel frame and plastic covers. Installation instructions in appendix 1. Rear box for dual seat Rear box for single seat...
  • Page 6 Service Manual AFISCOOTER S v.1.9 Ver. 01 Connection facilities for walking sticks and crutches. Rear frame connection device - Seat connection device - connects to the ears in the rear frame connects to the armrest screws Left hand operation. Foot Pedal System.
  • Page 7 Service Manual AFISCOOTER S v.1.9 Ver. 01 Golf wheels. Golf wheels fenders. Assembly by 4 screws With washers and nuts for each fender. Flexible rain cover. Floor raise Elevation for 3 wheels Elevation for 4 wheels...
  • Page 8 Service Manual AFISCOOTER S v.1.9 Ver. 01 Canopy mirror Assemble the mirror to the bracket according to Fig. 1 Attaching the mirror to the canopy by an existing screw (Fig. 2). Figure 2 Figure 1 Shabbath Kit Installation Instructions in appendix 5.

  • Page 9: Mechanical Adjustments

    Service Manual AFISCOOTER S v.1.9 Ver. 01 Mechanical Adjustments Description image How to Adjust Seat Height Release both secure bolts (10) and level bolt (14). Change pin Level hole as required. Resecure both level bolt and secure bolt. Make sure the seat pin is parallel to the controller cover.

  • Page 10: Front Electronics Board Setup

    Service Manual AFISCOOTER S v.1.9 Ver. 01 Front Electronics Board Setup On the front board there are DIP Switches whose job is to define the operation of the buzzer in signals and faults. Can also be adjusted via the controller by changing parameters.

  • Page 11: Lcd Display Set Up And User Manual

    Service Manual AFISCOOTER S v.1.9 Ver. 01 LCD Display Set Up and User Manual 1. User interfaces Overturning Right Turn Main Danger Speed Signal Light Left Turn (future) Limit Signal Digital Information Speed Units Distance Units Clock Warning Electromagnet Battery...
  • Page 12 Service Manual AFISCOOTER S v.1.9 Ver. 01 Push buttons: Right – Mode : Use to change between different display modes and to Reset the Distance and Time. Left- Setup : Use to adjust the clock. As well as on and off the display lighting.
  • Page 13 Service Manual AFISCOOTER S v.1.9 Ver. 01 - Daylight level - When the headlight signal is inactive. A short press on Setup turns off and on the backlight. 4.2 View information: Switching between the different types of information is done by pressing with the Mode key.
  • Page 14 Service Manual AFISCOOTER S v.1.9 Ver. 01 2 - 12 hours 0- Off. Daytime running P 05 backlight 1-5 - Scale of Power. (headlight off) (Default - 5) 0- Off. Night running P 06 backlight 1-5 - Scale of Power.

  • Page 15: Controller Programming / Setup

    P/N - PCS4002 Note: In case of any need to change a parameter that is not highlighted in the list, please contact and consult with Afikim Electric Vehicle Engineering. 8.2 Operating Instructions 8.2.1 Connect the adapter to the programmer and plug into a charging socket (the programmer starts working).
  • Page 16 Service Manual AFISCOOTER S v.1.9 Ver. 01 8.3 List of parameters for S-Drive140 controller with power unit model CT10 / CT12 / CT15 8.3.1 Parameters for use in manual programmer: Note: Highlighted parameters - User customizable values can be downloaded.
  • Page 17 Service Manual AFISCOOTER S v.1.9 Ver. 01 Parameter 3 - Value-enhanced 25 Parameter 3? Param. 3 engine compensation 26 Parameter 4? Param. 4 Parameter 4-Boost Delay 27 Bridge Hold? bridge hld Bridge hold 28 Soft Stop ? soft-stop Soft Stop...
  • Page 18 Service Manual AFISCOOTER S v.1.9 Ver. 01 8.3.2 Parameters for using PC software: PC programmer Software rev. 14.6.0 Power Unit Explanation of the Parameters CT10 CT12 CT15 parameter Speed Settings Acceleration forward fast Forward Acceleration Fast Profile (0.1 Sec) Acceleration forward slow Forward Acceleration Slow Profile (0.1 Sec)
  • Page 19 Service Manual AFISCOOTER S v.1.9 Ver. 01 Latching Latching Latching Need to restart after inhibit No. 2 Inhibit 2 Operation Set speed inhibit No. 2 Inhibit 2 Speed (%) Set mode inhibit No. 3 Inhibt Mode 3 Non- Non- Non- Need to restart after inhibit No.
  • Page 20 Service Manual AFISCOOTER S v.1.9 Ver. 01 Cool time Motor Cooling Time (Sec) Driver fold back temperature Current Foldback Temp (Deg C) Min. Current limitation Current Limit Min (Amps) Motor Stall Timeout (Sec) Speed compensation - resistance of the armature...

  • Page 21: Periodic Maintenance Check

    Every Month stop Check tires wear User Every Month Check for missing parts User When receiving the Afiscooter S or after a and damaged parts long time not using it. .Use the figures #1,2,3,4 . Check emergency User Every Month...
  • Page 22 Knees/legs and not loading your Back. Tires Correct air pressure in the tires is essential for optimal steering and stability of the Afiscooter S. Check air pressure every two weeks. ±2 psi. Afiscooter Inflate to the proper air pressure: 25 4W front tires: 20±2 psi.

  • Page 23: Mechanical Fault Troubleshooting

    Service Manual AFISCOOTER S v.1.9 Ver. 01 Mechanical Fault troubleshooting Description Probable cause Repair action Noises from front Check front suspension for Replace wear parts, steering and clearances and secure of bolts. secure bolts. suspension Check front shock absorbers. Replace if needed.
  • Page 24 Service Manual AFISCOOTER S v.1.9 Ver. 01 Too short distance Power unit wear, consume high Check noise and travel between current. Also might be noisy. current and replace charging if needed. Clearances in tiller Unsecured screws and gas Check scure of piston faulty screws.

  • Page 25: Control And Electronics System Fault Troubleshooting

    Service Manual AFISCOOTER S v.1.9 Ver. 01 Control and Electronics system fault troubleshooting 12.1 General control system and Front Board Troubleshoots The front board is the center of all peripheral functions of the scooter : Lights , Horn , Information goes to the LCD display .

  • Page 26: Controller / Drive Troubleshoots

    12.3 Controller / Drive Troubleshoots The controller is the center of all driving functions of the Afiscooter S: Speed control , acceleration , deceleration , EMB (Electro Magnetic Brake used as parking brake) , Reverse drive , Speed limiting etc. . But still the functions of the controller are all connected to all the wiring, connectors and as well the Front board, power units and batteries.

  • Page 27: Controller Trip Codes Using Programmer Sp1 & Actions To Repair

    Service Manual AFISCOOTER S v.1.9 Ver. 01 Controller Trip codes using programmer SP1 & actions to repair: 12.5 When the fault exists, connect the SP1 programmer's connector directly to the controller SDRIVE140 or to the charging socket, using a special wiring adaptor.

  • Page 28: Possible Faults Symptoms And Repair Actions

    Service Manual AFISCOOTER S v.1.9 Ver. 01 3B01 Check the motor wiring & the connections to the controller, then retest 3D02 Check the motor wiring & the connections to the controller, then retest 3D03 Check the motor wiring & the connections to the controller, then retest...

  • Page 29: Mechanical Assembly Drawings

    Check that all connectors on the scooter are securely mated, and ensure that all cables are free from damage. Mechanical assembly drawings See attached assembling drawings: Afiscooter S (4W & 3W) assembling. Quick guide troubleshoot Afiscooter S electric faults: Description...

  • Page 30: Flow Chart For Electric Trouble Shoot

    Service Manual AFISCOOTER S v.1.9 Ver. 01 Flash code = 7 flashes , Possible potentiometer fault Check replace potentiometer scooter does not drive Flash code = 8 flashes, Possible controller fault Check replacement controller scooter does not drive Flash code = 9 flashes,...
  • Page 31 Service Manual AFISCOOTER S v.1.9 Ver. 01 Always check wiring and connectors! Choose the proper option - Always re-install original part if problem not solved! Afiscooter S Drive and Display faults Display ON Scooter drives but stops Display not working...
  • Page 32 Service Manual AFISCOOTER S v.1.9 Ver. 01 Finish Always check wiring and connectors! Choose the proper option – Always re-install original part if problem not solved! Drive and display problems Afiscooter S Batteries display OFF Display does not work Scooter drives and...
  • Page 33 Service Manual AFISCOOTER S v.1.9 Ver. 01 Choose the proper option – Always check wiring and connectors! Afiscooter S Charge and general problems Always re-install original part if problem not solved! Time or travel A lamp in not working Several or all lamps are not...
  • Page 34 Service Manual AFISCOOTER S v.1.9 Ver. 01 Finish Finish Finish...

  • Page 35: Electrical Diagrams - General Wiring Diagram

    Service Manual AFISCOOTER S v.1.9 Ver. 01 Electrical diagrams - General Wiring diagram...
  • Page 36 Service Manual AFISCOOTER S v.1.9 Ver. 01...
  • Page 37 Service Manual AFISCOOTER S v.1.9 Ver. 01...
