Special Function Register PSW (Address D0 H )
Bit No. MSB
D7 H
D0 H CY
Bit
CY
AC
F0
RS1
RS0
OV
F1
P
B Register
The B register is used during multiply and divide and serves as both source and destination. For
other instructions it can be treated as another scratch pad register.
Stack Pointer
The stack pointer (SP) register is 8 bits wide. It is incremented before data is stored during PUSH
and CALL executions and decremented after data is popped during a POP and RET (RETI)
execution, i.e. it always points to the last valid stack byte. While the stack may reside anywhere in
the on-chip RAM, the stack pointer is initialized to 07 H after a reset. This causes the stack to begin
a location = 08 H above register bank zero. The SP can be read or written under software control.
