USE AND CARE GUIDE
POWERWALL-X VERTICAL
LED WALLPACK
Questions, problems, missing parts? Before returning to the store,
call Commercial Electric Customer Service
8 a.m. - 7 p.m., EST, Monday – Friday, 9 a.m. – 6 p.m., EST, Saturday
1-844-584-3776
HOMEDEPOT.COM
THANK YOU
We appreciate the trust and confidence you have placed in Commercial Electric through the purchase of this LED
flood light. We strive to continually create quality products designed to enhance your home. Visit us online to see our
full line of products available for your home improvement needs. Thank you for choosing Commercial Electric!
Advertisement
Table of Contents
Related Manuals for Commercial Electric PRWX15-V-PC-4K-BZ
Summary of Contents for Commercial Electric PRWX15-V-PC-4K-BZ
- Page 1 THANK YOU We appreciate the trust and confidence you have placed in Commercial Electric through the purchase of this LED flood light. We strive to continually create quality products designed to enhance your home. Visit us online to see our...
-
Page 2: Table Of Contents
Supplier’s Declaration of Conformity 47 CFR & 2.1077 Compliance Information power source. Unique Identifier: PART NUMBER Some codes require installation by a (e.g. PRWX15-V-PC-4K-BZ / PRWX30-V-PC-4K-BZ) qualified electrician. Responsible Party – U.S. Contact Information This light fixture must be properly grounded. -
Page 3: Warranty
Warranty (continued) LIMITATION OF LIABILITY In no event shall the manufacturer be liable for indirect, consequential, incidental or special damages, or lost profits. The manufacturer is not liable for any claims or damage arising out of or connected with the manufacture, sale, delivery, use, maintenance and repair or modification of the manufacturer products, or supply of any replacement parts that exceed the purchase price of the manufacturer products giving rise to a claim. -
Page 4: Package Contents
Pre-Installation (continued) PACKAGE CONTENTS Part Description Quantity Light fixture Photocell (light sensor) Mounting plate tightening bolt (pre-installed) Mounting plate with gasket (pre-installed) Hanger wire for hands-free installation (pre-installed) HARDWARE KIT NOTE: Hardware not shown to actual size. PHOTOCELL COVER Part Description Quantity #8-32 x 3/4 in. -
Page 5: Installation
Installation For best results Install light 5-10 feet above the ground. Do not mount the fixture close to reflective surfaces such as windows, white walls, Wall Mount white surfaces and water. Do NOT wire to a dimming switch. (fig 1). 1-1/2"... - Page 6 Installation (continued) Remove the Install the mounting mounting plate plate to the NOTE: The mounting plate (D) comes pre-assembled on junction box the light fixture (A) for shipping. Route the junction box wires through NOTE: The mounting plate tightening bolt (C) comes pre-installed on the light fixture.
- Page 7 Installation (continued) Hang fixture to mounting plate Place the small sphere head of the hanger wire (E) behind the back of the small groove located on the bottom of the center hole of the mounting plate (D). (fig 8). TIP: Ensure the light fixture (A) can safely hang onto the mounting plate (D) to allow for use of two hands to make the wiring (fig 8) connections.
- Page 8 Installation (continued) Caulk around the Mount the light fixture light fixture Caulk around the mounting plate (D) Once wiring connections are done, place and surface with silicone sealant (not the light fixture (A) onto the mounting included). (fig 11). plate (D) so the top sloped groove on the plate rests on the top sloped groove on the back of the fixture.
-
Page 9: Operation
Operation Select Dusk-to-Dawn or Switch-Activated control AUTOMATIC OPTION 1: DUSK-TO-DAWN OPERATION NIGHTTIME ON Dusk-to-dawn operation enables the light fixture to automatically turn ON when dark outside and turn OFF when the sun rises, thus saving you energy. DAYTIME OFF Ensure the photocell (B) is unobstructed. (fig 12). Ensure the switch powering the light fixture/ junction box is turned to the ON position and leave it ON at all times to enable... -
Page 10: Care & Cleaning
Care and Cleaning Shut off main power supply before cleaning the product. To prolong the original appearance, clean the light fixture with clear water and a soft, damp cloth only. Do not use abrasive cleaners or cleaners that contain alcohol. Do not apply paints, solvents, or any other chemicals on this light fixture. - Page 12 Questions, problems, missing parts? Before returning to the store, call Commercial Electric Customer Service 8 a.m. - 7 p.m., EST, Monday – Friday, 9 a.m. – 6 p.m., EST, Saturday 1-844-584-3776 HOMEDEPOT.COM Retain this manual for future use.
