Item #1004 105 595
USE AND CARE GUIDE
24 FT. WHITE & MULTI-COLOR LED TAPE LIGHT
WITH REMOTE
Questions, problems, missing parts? Before returning to the store,
call Commercial Electric Customer Service
8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday
1-877-527-0313
HOMEDEPOT.COM
THANK YOU
We appreciate the trust and confidence you have placed in Commercial Electric through the purchase of this flexible
tape like kit. We strive to continually create quality products designed to enhance your home. Visit us online to see
our full line of products available for your home improvement needs. Thank you for choosing Commercial Electric!
Advertisement
Table of Contents
Related Manuals for Commercial Electric 1004 105 595
Summary of Contents for Commercial Electric 1004 105 595
- Page 1 THANK YOU We appreciate the trust and confidence you have placed in Commercial Electric through the purchase of this flexible tape like kit. We strive to continually create quality products designed to enhance your home. Visit us online to see...
-
Page 2: Table Of Contents
Table of Contents Table of Contents ............2 Installation ..............5 Safety Information .............2 Mounting Options ............8 Warranty..............3 Operation..............9 What is covered .............3 Care & Cleaning ............11 What is not covered ..........3 Troubleshooting ............11 Pre-Installation ............4 FCC Statement ............11 Planning Installation ..........4 Safety Information Always keep the user manual within reach while installing DANGER: Danger of eye damage! Never look directly at... -
Page 3: Warranty
Warranty THREE (3) YEAR WARRANTY WHAT IS COVERED The manufacturer warrants this fixture to be free from defects in materials and workmanship for a period of three (3) years from date of purchase. This warranty applies only to the original consumer purchaser and only to products used in normal use and service. -
Page 4: Pre-Installation
Pre-Installation PLANNING INSTALLATION It is important to read these guidelines completely to understand how RGB + White LED tape lighting works with the included RF wireless remote. This tape light is encapsulated in UV resistant, weatherproof tubing for use indoors or outdoors in any dry or wet location. -
Page 5: Installation
Installation Connecting LED tape and the adapter This tape lighting kit comes fully assembled, but for ease of installation, you may wish to temporarily disconnect the power adapter. □ Unscrew the collar at the base of the adapter (A) where the output cable exits. □... - Page 6 Installation (continued) Preparing the assembly location □ Power the LED tape lighting and temporarily hold or tape into position with painter’s tape or masking tape – do not remove the adhesive paper backing. □ Adjust the lighting to various angles and positions to get the desired level of illumination and lighting appearance.
- Page 7 Installation (continued) Installing the RF Receiver □ Remove the adhesive backing from the receiver. On a clean and dry surface, place the RF receiver (B) into the desired position and press to ensure proper adhesion to the surface. For some outdoor installations, it is recommended to supplement this bond with silicone adhesive Mounting surface Connecting the power supply...
-
Page 8: Mounting Options
Mounting Options Creating above cabinet Installing under a cabinet uplighting □ To surface mount the LED tape light under a □ Most cabinet tops have uneven surfaces. To set of cabinets in one continuous run, you may create indirect uplighting over cabinets, simply need to drill a 1/2 in. -
Page 9: Operation
Operation Functions of the remote □ Pull out the plastic battery barrier sheet from the battery compartment located on the bottom of the remote (C). □ The remote (C) does not require line-of-sight to operate the lights. □ The remote can operate up to 50 feet in optimal conitions, but each installation has unique variables that may affect range. - Page 10 Operation (continued) Pairing Multiple Kits The remote (C) in each kit comes paired with the tape light (B). For larger installations, multiple kits can be paired together for control by a single remote (C). PAIRING □ Set to all kits to be paired to the same mode. □...
-
Page 11: Care & Cleaning
Care and Cleaning □ To clean the tape light, use a clean dry or damp cloth □ Do not use cleaners with chemicals, solvents or harsh abrasives as damage to the light strip may occur. Troubleshooting Problem Possible Cause Solution The LED strip will not light. - Page 12 Questions, problems, missing parts? Before returning to the store, call Commercial Electric Customer Service 8 a.m. - 7 p.m., EST, Monday-Friday, 9 a.m. - 6 p.m., EST, Saturday 1-877-527-0313 HOMEDEPOT.COM Retain this manual for future use.
