SKU# 1005 228 888
Model# FP0.5X4/4WY/WH/HD
USE AND CARE GUIDE
0.5 X 4 LED FLAT PANEL FIXTURE
WITH SELECTABLE COLOR TEMPERATURES
Questions, problems, missing parts? Before returning to the store,
call Commercial Electric Customer Service
8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday
1-877-527-0313
HOMEDEPOT.COM
THANK YOU
We appreciate the trust and confidence you have placed in Commercial Electric through the purchase of this LED Flat Panel Fixture. We strive
to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home
improvement needs. Thank you for choosing Commercial Electric!
Advertisement
Chapters
Table of Contents
Related Manuals for Commercial Electric FP0.5X4
Summary of Contents for Commercial Electric FP0.5X4
- Page 1 THANK YOU We appreciate the trust and confidence you have placed in Commercial Electric through the purchase of this LED Flat Panel Fixture. We strive to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home...
-
Page 2: Table Of Contents
Table of Contents Table of Contents ........2 Safety Information . -
Page 3: Pre-Installation
Pre-Installation TOOLS REQUIRED Phillips Power Drill 1/2 in. Drill Bit screwdriver HARDWARE INCLUDED NOTE: Hardware not shown to actual size. Part Description Quantity Mounting Plate (8.03 in. x 3.74 in. x 0.49 in.) 3/16 in. Toggle Bolts Wire Connectors Screws #8-32 x 1 in. 0.5 x 4 LED Flat Panel Fixture HOMEDEPOT.COM Please contact 1-877-527-0313 for further assistance. -
Page 4: Installation
Installation Securing the Toggle Bolts Identifying the Wires □ Remove the mounting plate (AA) from the junction box. □ Turn OFF the main power at the circuit breaker before installing the fixture. □ Drill the marked locations using a 1/2 in. drill bit. □... - Page 5 Installation (continued) Attaching the Fixture Installing the Fixture □ Feed the junction box and fixture wires through □ Connect the three wires coming from the fixture to the mounting bracket plate’s center hole. the junction box wires (black - line voltage, white - neutral and green - ground).
- Page 6 Questions, problems, missing parts? Before returning to the store, call Commercial Electric Customer Service 8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday 1-877-527-0313 HOMEDEPOT.COM Retain this manual for future use.
- Page 7 GRACIAS Apreciamos la confianza que ha depositado en Commercial Electric a través de la compra de este accesorio de panel plano. Nos esforzamos por crear continuamente productos de calidad diseñados para mejorar su hogar. Visítenos en línea para ver nuestra línea completa de productos...
-
Page 8: Tabla De Contenido
Tabla de contenido Tabla de contenido ........8 Informacion de seguridad . -
Page 9: Preinstalación
Preinstalación HERRAMIENTAS NECESARIAS Destornillador Taladro Broca de 1/2 eléctrico Phillips o pulgada Destornillador de estrella EQUIPO INCLUIDO NOTA : Las imágenes de las piezas no representan su tamaño real. Parte Cantidad Descripción Placa de montaje (8.03 ‘’ x 3.74 ‘’ x 0.49 ‘’) Pernos de palanca de 3/16 ‘’... -
Page 10: Instalación
Instalación Identifica los cables Asegure los pernos de palanca □ Retire la placa de montaje (AA) de la caja de conexiones. □ Apague la energía principal en el disyuntor antes de instalar el dispositivo. □ Taladre las ubicaciones marcadas con una broca de 1/2 pulg. - Page 11 Instalación (continuación) Fijación de la luminaria Instala la luminaria □ Conecte los tres cables que vienen del artefacto de □ Pase los cables de la caja de conexiones y la luz a iluminación a los cables en la caja de conexiones través del orificio central de la placa de montaje.
- Page 12 ¿Preguntas, problemas o piezas faltantes? Antes de regresar a la tienda, por favor llame al servicio al cliente de Commercial Electric Lunes a viernes de 8:00 a. M. A 7:00 p. M., Hora del este; Sábado, de 9 a.m. a 6 p.m., hora del este 1-877-527-0313 HOMEDEPOT.COM...
