1008367367
1008369606
1008369616
USE AND CARE GUIDE
LED WALLPACK
Questions, problems, missing parts? Before returning to the store,
call Commercial Electric Customer Service
8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday
1-877-527-0313
HOMEDEPOT.COM
THANK YOU
LED Wallpack. We strive
to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home
improvement needs. Thank you for choosing Commercial Electric!
Advertisement
Related Manuals for Commercial Electric 1008367367
Summary of Contents for Commercial Electric 1008367367
- Page 1 1-877-527-0313 HOMEDEPOT.COM THANK YOU LED Wallpack. We strive to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs. Thank you for choosing Commercial Electric!
-
Page 2: Table Of Contents
Table of Contents Safety Information ........2 Installation . -
Page 3: Pre-Installation
Warranty (continued) LIMITATION OF LIABILITY is not liable for any claims or damage arising out of or connected with the manufacture, sale, delivery, use, maintenance and repair or TO CLAIM Please contact The Home Depot customer service at 1-877-527-0313 or email support@homedepot.com and include your name, address and contact number, along with a copy of the purchase receipt and a brief description of the problem. - Page 4 Pre-Installation (continued) SPECIFICATIONS 1008367367 1008369606 1008369616 Model 3600 Lumens Lumens (Light Output) 5300 | 6500 | 7500 Lumens 9800 | 10800 | 12000 Lumens Watts (Power Consumption) 30 Watts LED 60-50-40 Watts LED 90-80-70 Watts LED Replaces 100 Watt Metal Halide...
-
Page 5: Installation
Pre-Installation (continued) PACKAGE CONTENTS Part Description Quantity Conduit entry plug Mounting base screw (pre-installed) Mounting base Photocell CCT / FAO switch Installation Turning off the electricity □ Verify the wall switch is in the OFF position. □ Turn OFF power at the circuit breaker that supplies power to the outlet box you are working on. - Page 6 Installation (continued) Removing the mounting base NOTE: The mounting base screws (C) come pre-installed □ Loosen the two mounting base screws (C) using a Phillips □ and stays connected on the hinge. (Fig. 2) CAUTION: DO NOT touch the LED and photocell lens (E) Fig.
- Page 7 Installation (continued) Installing the mounting base Junction Box □ Route the junction box wires through the large center hole in the mounting base (D). □ Align the holes on the mounting base (D) with the holes on your junction box. Use two (2) or four (4) #8 screws (AA), depending on the size of the holes in your junction box, to attach the mounting base (D) to your junction box.
- Page 8 Installation (continued) Making the electrical connections Junction Box □ Follow the wiring instructions given below to make the electrical connections. (Fig. 1). Surface Conduit Mount □ sides from the where conduit will enter. (Fig. 2) □ instructions given below. □ If necessary, strip 3/8 in. of insulation from junction box or Fig.
-
Page 9: Operation
IMPORTANT: NOTE: If photocell (E) is located in an area under heavy shade the photocell may not detect enough light and may turn Option 2: Switch controlled 1008367367 automatically, but is manually controlled. PHOTO-CELL 1008369606 SETTING □ Remove the photo-cell cap by selecting the DIP switch on/off. -
Page 10: Care And Cleaning
Selecting CCT and FAO Remove the CCT and DIM cap and select the desired combination of Wattage (brightness) output and CCT (light color temperature) as desired. 1008369606 CCT Setting 1008369616 Note: 3000K 4000K 5000K 4000K is default setting 1008369606 Note: 60W is default setting FAO Setting 1008369616... - Page 11 Questions, problems, missing parts? Before returning to the store, call Commercial Electric Customer Service 8 a.m. - 7 p.m., EST, Monday-Friday, 9 a.m. - 6 p.m., EST, Saturday 1-877-527-0313 HOMEDEPOT.COM Retain this manual for future use.
