ZT-2570/ZT-2571
Warranty
All products manufactured by ICP DAS are under warranty regarding
defective materials for a period of one year, beginning from the date of
delivery to the original purchaser.
Warning
ICP DAS assumes no liability for any damage resulting from the use of
this product. ICP DAS reserves the right to change this manual at any
time without notice. The information furnished by ICP DAS is believed to
be accurate and reliable. However, no responsibility is assumed by ICP
DAS for its use, not for any infringements of patents or other rights of
third parties resulting from its use.
Copyright
Copyright © 2013 by ICP DAS. All rights are reserved.
Trademark
Names are used for identification only and may be registered trademarks
of their respective companies.
Technology Support
If you have any problems, please feel free to contact us via
email at
+7(495)109-02-08 sales@bbrc.ru www.bbrc.ru
service@icpdas.com
User Manual

Advertisement

Table of Contents
loading

Related Manuals for ICP DAS USA ZT-2570

Summary of Contents for ICP DAS USA ZT-2570

  • Page 1 ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru ZT-2570/ZT-2571 User Manual Warranty All products manufactured by ICP DAS are under warranty regarding defective materials for a period of one year, beginning from the date of delivery to the original purchaser.

  • Page 2: Table Of Contents

    ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru Table of Content 1 Introduction of ZigBee ........1 2 Introduction to the ZT-257x module ......2 3 Information to the Hardware ........4 3.1 Specifications .......... 4 3.2 ZT-257x Front View ........
  • Page 3 ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru What’s in the shipping package? The package includes the following items: CA-0915 (ZT-2570) / ZT-257x Device ANT-124-05 Release Note CA-0910N (ZT-2571) If any of these items are missing or damaged, please contact your local distributor for more information.

  • Page 4: Introduction Of Zigbee

    The technology defined by the ZigBee specification is intended to be simpler and less expensive than other WPANs. Page 1 ICP DAS, ZT-2570/ZT-2571 User Manual, Version 1.3 Copyright @ 2013 by ICP DAS Co., Ltd. All Rights Reserved.

  • Page 5: Introduction To The Zt-257X Module

    Introduction to the ZT-257x module The Basis of ZT-257x Series Product The ZT-2570 and ZT-2571 series modules are small-sized wireless ZigBee converters based on the IEEE802.15.4 standard that allow RS-232, RS-485 and Ethernet interface to be converted to a personal area ZigBee network. The typical transmission of ICP DAS ZT series ZigBee products is 700 meters (LOS, line of sight), with a transmission frequency range of between 2.405 GHz and 2.48 GHz,...
  • Page 6 For more information, please refer to the relevant documents for these devices, which can be found at following link: http://ftp.icpdas.com/pub/cd/usbcd/napdos/zigbee/zt_series/document Page 3 ICP DAS, ZT-2570/ZT-2571 User Manual, Version 1.3 Copyright @ 2013 by ICP DAS Co., Ltd. All Rights Reserved.

  • Page 7: Information To The Hardware

    Power reverse polarity protection EMS Protection ESD, Surge, EFT Required Supply Voltage +10V ~ +30V Power Consumption 2.5 W (Max.) Page 4 ICP DAS, ZT-2570/ZT-2571 User Manual, Version 1.3 Copyright @ 2013 by ICP DAS Co., Ltd. All Rights Reserved.
  • Page 8 50 mm, you should still be careful not to touch these surfaces while mounting the device, or during normal use. Page 5 ICP DAS, ZT-2570/ZT-2571 User Manual, Version 1.3 Copyright @ 2013 by ICP DAS Co., Ltd. All Rights Reserved.

  • Page 9: Zt-257X Front View

    ZBRUN：Transmit mode is used to transmit data to the remote device.  ZBINIT：Operating system initial state, it is used to update firmware. Page 6 ICP DAS, ZT-2570/ZT-2571 User Manual, Version 1.3 Copyright @ 2013 by ICP DAS Co., Ltd. All Rights Reserved.
  • Page 10 If there is any requirement for extension cable, it must be a connector with the type RPSMA and resistance 50 Ohm. Ex. 3S001-1, 3S003-1...etc Page 7 ICP DAS, ZT-2570/ZT-2571 User Manual, Version 1.3 Copyright @ 2013 by ICP DAS Co., Ltd. All Rights Reserved.

  • Page 11: Dimensions (Units: Mm)

    +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru 3.3 Dimensions (Units: mm) Left Side View Top View Right Side View Front View Rear View Bottom View Page 8 ICP DAS, ZT-2570/ZT-2571 User Manual, Version 1.3 Copyright @ 2013 by ICP DAS Co., Ltd. All Rights Reserved.

  • Page 12: Block Diagram

    SRAM FLASH Switch Power Circuit +10 ~ 30V 3.5 Wire Connection 1. RS-232 ZT-2570 CA-0915 ZT-2571 CA-0910N RS-485 D+D - Page 9 ICP DAS, ZT-2570/ZT-2571 User Manual, Version 1.3 Copyright @ 2013 by ICP DAS Co., Ltd. All Rights Reserved.

  • Page 13: Setting Up The Zt-257X Module

    Use application tools or analyzers to detect the wireless signal, chose a RF Channel which has not been occupied. e.g. Wifi Analyzer Page 10 ICP DAS, ZT-2570/ZT-2571 User Manual, Version 1.3 Copyright @ 2013 by ICP DAS Co., Ltd. All Rights Reserved.
  • Page 14 CH 13 (2472) CH E (2475) CH 14 CH F (2480) (2484) ‧RF Channel Table to ZigBee(802.15.4) and WLAN(IEEE 802.11b/IEEE 802.11g) Page 11 ICP DAS, ZT-2570/ZT-2571 User Manual, Version 1.3 Copyright @ 2013 by ICP DAS Co., Ltd. All Rights Reserved.
  • Page 15 75ms 75ms 42 B 79 Bytes 79 Bytes RS-232 79 Bytes 79 Bytes 42 B RS-485 Ethernet (Keep relay data) Page 12 ICP DAS, ZT-2570/ZT-2571 User Manual, Version 1.3 Copyright @ 2013 by ICP DAS Co., Ltd. All Rights Reserved.
  • Page 16 These values are based on the configuration of the serial port. Item Specification Data Format N81, N82, O71, O81, E71, E81, S81, M81 Baud Rate 1200 ~ 115200 bps Page 13 ICP DAS, ZT-2570/ZT-2571 User Manual, Version 1.3 Copyright @ 2013 by ICP DAS Co., Ltd. All Rights Reserved.
  • Page 17 ※ Note: Please select “Fixed baud rate” if the virtual COM is not in the 115200 bps and N81 format. Page 14 ICP DAS, ZT-2570/ZT-2571 User Manual, Version 1.3 Copyright @ 2013 by ICP DAS Co., Ltd. All Rights Reserved.
  • Page 18 ZigBee Slave 00 01 00 02 The above schematic diagram is showing what the difference of using different application modes. Page 15 ICP DAS, ZT-2570/ZT-2571 User Manual, Version 1.3 Copyright @ 2013 by ICP DAS Co., Ltd. All Rights Reserved.
  • Page 19 ZT-2571 Unicast Data will only be sent to the coordinator [Eg1] When ZT-2570 ZigBee Host sends “DATA_01” via broadcasting frame, →Both of the ZigBee slave 0x0001 and 0x0002 will receive the DATA_01. ※ Broadcasting type frame, data will be sent to every ZigBee slaves in the same ZigBee network [Eg2] When the ZigBee slave 0x0001 sends “DATA_02”...
  • Page 20 Unicast Format: “:AAAA” + Data ZT-2571 [Eg1] When ZT-2570 ZigBee Host sends “:0001DATA_01” via unicast frame, → Only the ZigBee Slave 0x0001 receives DATA_01. ※ Unicast type frame, data will be only sent to the specific ZigBee node) [Eg2] When ZigBee slave 0x0001 sends “:0002DATA_02” via unicast frame, →...
  • Page 21 [Eg3] When ZT-2571 transmits the acknowledgement “MRTU_ACK_03”, →ZT-2570 will response the acknowledgement “MRTU_ACK_03” directly to serial port. →ZT-2570 will convert protocol then output “MTCP_CMD_01” to Ethernet. ※ Unicast type frame, data will only be sent to the ZigBee host)

  • Page 22: Connecting The Power And Host Pc

    (SELV, Limited Power Source) that is intended to be connected to the power input pins (DC.+Vs / DC.GND) comply with the requirements of EN 60950-1. Page 19 ICP DAS, ZT-2570/ZT-2571 User Manual, Version 1.3 Copyright @ 2013 by ICP DAS Co., Ltd. All Rights Reserved.
  • Page 23 Step 4. Enable the power. It means that the ZT-257x start-up procedure has been completed. If the red LED has changed from blinking to a steady light. Page 20 ICP DAS, ZT-2570/ZT-2571 User Manual, Version 1.3 Copyright @ 2013 by ICP DAS Co., Ltd. All Rights Reserved.

  • Page 24: Configure Zigbee Via Utility (Serial/Ethernet)

    IP used to select the IP address for making the address for connecting same network. the module in next step. Page 21 ICP DAS, ZT-2570/ZT-2571 User Manual, Version 1.3 Copyright @ 2013 by ICP DAS Co., Ltd. All Rights Reserved.
  • Page 25 Step 4. Once a connection is established, select either the [Default] or the [Wizard] function from the settings mode page. Wizard Default Page 22 ICP DAS, ZT-2570/ZT-2571 User Manual, Version 1.3 Copyright @ 2013 by ICP DAS Co., Ltd. All Rights Reserved.
  • Page 26 Pan ID, Node ID, RF Channel, RF Power, Baud rate, Data Format, Application Mode and so the relevant parameters. Page 23 ICP DAS, ZT-2570/ZT-2571 User Manual, Version 1.3 Copyright @ 2013 by ICP DAS Co., Ltd. All Rights Reserved.
  • Page 27 Step 6. Once the module configuration has been completed, the message “The Configuration was successful” will be displayed. Return the DIP switch to the “ZBRUN” position and reboot the ZT-257x device. Page 24 ICP DAS, ZT-2570/ZT-2571 User Manual, Version 1.3 Copyright @ 2013 by ICP DAS Co., Ltd. All Rights Reserved.

  • Page 28: Configure Zigbee Via Browser (Ethernet)

    After launching the MiniOS utility, please press the “F12” on the keyboard to search the ZT-257x device. Page 25 ICP DAS, ZT-2570/ZT-2571 User Manual, Version 1.3 Copyright @ 2013 by ICP DAS Co., Ltd. All Rights Reserved.
  • Page 29 LAN of desktop. Please also click the “Set” button to complete the configurations. Set the ZT-257x to the same network environment Page 26 ICP DAS, ZT-2570/ZT-2571 User Manual, Version 1.3 Copyright @ 2013 by ICP DAS Co., Ltd. All Rights Reserved.
  • Page 30 Step 3. If they are in the same network environment, user can use a browser to set the configurations of ZT-257x. The site of ZT-257x device： http://○○○.○○○.○○○.○○○/index.htm Page 27 ICP DAS, ZT-2570/ZT-2571 User Manual, Version 1.3 Copyright @ 2013 by ICP DAS Co., Ltd. All Rights Reserved.
  • Page 31 Note Step 5. If the new configuration is completed, please click “Update New Config” button to start the ZT-257x configuration. Page 28 ICP DAS, ZT-2570/ZT-2571 User Manual, Version 1.3 Copyright @ 2013 by ICP DAS Co., Ltd. All Rights Reserved.
  • Page 32 “Please reload the web page to see whether the configuration is correct or not” then user may follow this instructions. Page 29 ICP DAS, ZT-2570/ZT-2571 User Manual, Version 1.3 Copyright @ 2013 by ICP DAS Co., Ltd. All Rights Reserved.

  • Page 33: Configuration Example

    10.1.0.70 192.168.0.70 independent to each ZT devices, so the Port ZT-2570 and ZT-2571 are not in the same LAN. <Reminding > Please confirm the TCP client is disabled if there is not any TCP server connected – otherwise the ZT device will try to establish TCP connection continuously, which results the communication blocking.

  • Page 34: Data Transparent

    ZT-2550 ZT-2551 備註 ZT-2570 ZT-2571 Application Mode Transparent Transparent Not any special limitation Page 31 ICP DAS, ZT-2570/ZT-2571 User Manual, Version 1.3 Copyright @ 2013 by ICP DAS Co., Ltd. All Rights Reserved.

  • Page 35: Modbus Rtu Communication

    ZT-2551 備註 ZT-2570 ZT-2571 Transparent Transparent Not any special limitation Refer Advanced Configuration - Frame Application Mode Gateway Gateway Type Page 32 ICP DAS, ZT-2570/ZT-2571 User Manual, Version 1.3 Copyright @ 2013 by ICP DAS Co., Ltd. All Rights Reserved.
  • Page 36 Set-up the Address Mapping in the ZT-2550/70 which is used to redirect the unicast frame to the corresponding ZT-2551/71 device. Please refer the section “7.2 DCON/MODBUS Device Communication” for more details. Page 33 ICP DAS, ZT-2570/ZT-2571 User Manual, Version 1.3 Copyright @ 2013 by ICP DAS Co., Ltd. All Rights Reserved.

  • Page 37: Modbus Rtu To Modbus Tcp Communication

    Modbus RTU and Modbus TCP. ZT-2550 備註 ZT-2571 ZT-2570 Transparent Not any special limitation Refer Advanced Configuration - Frame Application Mode Gateway Gateway Type Page 34 ICP DAS, ZT-2570/ZT-2571 User Manual, Version 1.3 Copyright @ 2013 by ICP DAS Co., Ltd. All Rights Reserved.
  • Page 38 The Modbus TCP device of address 0x02 is only able to be connected with the ZT-2571 of Node ID 0x0002. … and so on Page 35 ICP DAS, ZT-2570/ZT-2571 User Manual, Version 1.3 Copyright @ 2013 by ICP DAS Co., Ltd. All Rights Reserved.

  • Page 39: Modbus Tcp Communication

    In this setting, the Node ID and Address of Modbus TCP device should be set to the same. Please refer the following Page 36 ICP DAS, ZT-2570/ZT-2571 User Manual, Version 1.3 Copyright @ 2013 by ICP DAS Co., Ltd. All Rights Reserved.
  • Page 40 LAN via the ZigBee wireless communication. As the described above, the LANs of ZT-2570 and ZT-2571 are independent. So, no matter which Modbus TCP devices you want to connect, all the connection target should be changed to the IP address of ZT-2570.
  • Page 41 ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru connecting the different IP addresses. However, now all the socket connections are linked to the ZT-2570, so please use the Modbus Address to distinguish the distinct Modbus TCP devices. Page 38 ICP DAS, ZT-2570/ZT-2571 User Manual, Version 1.3...

  • Page 42: Modbus Tcp To Modbus Rtu Communication

    In this setting, the Node ID and Address of Modbus RTU device should be set to the same. Please refer the following Page 39 ICP DAS, ZT-2570/ZT-2571 User Manual, Version 1.3 Copyright @ 2013 by ICP DAS Co., Ltd. All Rights Reserved.
  • Page 43 Ethernet packets cannot be sent over the ZigBee wireless communication. In the other words, there is only raw data of Ethernet packets will be sent to Page 40 ICP DAS, ZT-2570/ZT-2571 User Manual, Version 1.3 Copyright @ 2013 by ICP DAS Co., Ltd. All Rights Reserved.
  • Page 44 ZigBee. All the Modbus communication are completed via the socket connection between the controller and ZT-2570. Although all the Modbus TCP data should be transmitted via the IP address of ZT-2570, but the Modbus Address still can be used to distinguish the distinct Modbus TCP devices. Page 41 ICP DAS, ZT-2570/ZT-2571 User Manual, Version 1.3...

  • Page 45: Both Modbus Rtu & Tcp Communication

    1. The unicast frame is the default setting of Gateway Mode which is used for the wireless transmission. In this setting, the Node ID and Address of Page 42 ICP DAS, ZT-2570/ZT-2571 User Manual, Version 1.3 Copyright @ 2013 by ICP DAS Co., Ltd. All Rights Reserved.
  • Page 46 1. When the ZT-2571 acts the TCP client, there is only one Modbus TCP device can be connected to the ZT-2571. Such as the ZT-2571 acts TCP client to connect with the ET-7000. Page 43 ICP DAS, ZT-2570/ZT-2571 User Manual, Version 1.3 Copyright @ 2013 by ICP DAS Co., Ltd. All Rights Reserved.
  • Page 47 In the origin architecture, the Modbus TCP devices are distinguished via connecting the different IP addresses. However, now all the socket connections are linked to the ZT-2570, so please use the Modbus Address to distinguish the distinct Modbus TCP devices.

  • Page 48: Test Communications

    Ethernet or serial port to do communication. ZB Net ZB PWR Page 45 ICP DAS, ZT-2570/ZT-2571 User Manual, Version 1.3 Copyright @ 2013 by ICP DAS Co., Ltd. All Rights Reserved.
  • Page 49 +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru A. Serial Port Test Method (1) Connect both the ZT-2570 and ZT-2571 to the Host PC via the RS-232 port. You may need to use two serial port tools to simulate the data transmission. Serial Tool Serial Tool...
  • Page 50 Method(2)： Use the EZ-Data Logger as a TCP Client which is connected to the ZT-2570 on the Host PC to search for ZT-2000 series I/O modules. If there any devices are found, it means that the configuration is correct.

  • Page 51: Applications

    (2) ZT-257x is suitable to use in monitoring and controlling. Eg. Smart energy, Home automation and etc. Light Control Thermostat Audio Control Window treatment Security Page 48 ICP DAS, ZT-2570/ZT-2571 User Manual, Version 1.3 Copyright @ 2013 by ICP DAS Co., Ltd. All Rights Reserved.

  • Page 52: Technical Support

    Path” in the Windows “Save” dialog box. Once the configuration has been successfully saved, the following message will be displayed. Page 49 ICP DAS, ZT-2570/ZT-2571 User Manual, Version 1.3 Copyright @ 2013 by ICP DAS Co., Ltd. All Rights Reserved.

  • Page 53: Appendixes

    ZigBee PWR Blinking (200ms) Module Initialization Failure (Red LED) Blinking (200ms) Configuration Mode Blinking (1s) Watchdog Enabled Steady Unlit Power OFF Page 50 ICP DAS, ZT-2570/ZT-2571 User Manual, Version 1.3 Copyright @ 2013 by ICP DAS Co., Ltd. All Rights Reserved.

  • Page 54: Dcon/Modbus Device Communication

    Address = 02 Address = Node ID = 0x0003 Node ID = 0x0003 Broadcast Unicast Address = 03 Address = 03 Page 51 ICP DAS, ZT-2570/ZT-2571 User Manual, Version 1.3 Copyright @ 2013 by ICP DAS Co., Ltd. All Rights Reserved.
  • Page 55 ZT-2000 Configuration Utility. DCON/MODBUS Instruction To 0x04 ZT-2550/ZT-2570 Node ID = 0x0001 Node ID = 0x0002 Node ID = 0x0003 Unicast Page 52 ICP DAS, ZT-2570/ZT-2571 User Manual, Version 1.3 Copyright @ 2013 by ICP DAS Co., Ltd. All Rights Reserved.

  • Page 56: Non-Addressable Device Communication

    DDDDD BBBBB Barcode Reader RS-232 Device CCCCC EEEEE Barcode Reader Barcode Reader RS-232 Device AAAAA BBBBB CCCCC DDDDD EEEEE ….. Page 53 ICP DAS, ZT-2570/ZT-2571 User Manual, Version 1.3 Copyright @ 2013 by ICP DAS Co., Ltd. All Rights Reserved.
  • Page 57 DDDDD BBBBB Node ID=0001 Node ID=1234 CCCCC EEEEE Node ID=0002 :0001AAAAA :0002BBBBB Node ID=0003 Node ID=ABCD :0003CCCCC :1234DDDDD ….. :ABCDEEEEE Page 54 ICP DAS, ZT-2570/ZT-2571 User Manual, Version 1.3 Copyright @ 2013 by ICP DAS Co., Ltd. All Rights Reserved.
