ZB-2550/ZB-2551 Series
Warranty
All products manufactured by ICP DAS are under warranty
regarding defective materials for a period of one year, beginning
from the date of delivery to the original purchaser.
Warning!
ICP DAS assumes no liability for any damage resulting from
the use of this product. ICP DAS reserves the right to change this
manual at any time without notice. The information furnished by
ICP DAS is believed to be accurate and reliable. However, no
responsibility is assumed by ICP DAS for its use, not for any
infringements of patents or other rights of third parties resulting
from its use.
Copyright
Copyright @ 2007 by ICP DAS Co., Ltd. All rights are
.
reserved
Trademark
The names used for identification only may be registered
trademarks of their respective companies
ZB-2550/ZB-2551 Series User Manual Ver1.3, Feb /2011 ---1
User Manual
.
Advertisement
Table of Contents
Related Manuals for ICP DAS USA ZB-2550
Summary of Contents for ICP DAS USA ZB-2550
-
Page 1: User Manual
Copyright Copyright @ 2007 by ICP DAS Co., Ltd. All rights are reserved Trademark The names used for identification only may be registered trademarks of their respective companies ZB-2550/ZB-2551 Series User Manual Ver1.3, Feb /2011 ---1... -
Page 2: Table Of Contents
Operating Mode 3 : Addressable Mode ............22 Operating Mode 4 : ZBIO Mode ..............23 2.3 ZigBee Network Groups .................. 24 3. Appendix ......... 26 3.1 Zigbee Version Comparison ................. 26 ZB-2550/ZB-2551 Series User Manual Ver1.3, Feb /2011 ---2... -
Page 3: Introduction
At present, the ICP DAS ZigBee converter ZB-2550 series and ZB-2550 series, supports the RS-232 RS-485 interfaces. -
Page 4: More Information
1.1 More Information The ZB-2550 series and the ZB-2551 series are small-sized wireless ZigBee converters based on the IEEE 802.15.4 standard. They allow RS-485/RS-232 interfaces to be converted to a ZigBee wireless network. Only one ZB-2550 series (Host) allowed in a ZigBee network and is used to initialize and manage the data transmission routes. - Page 5 Please refer to ZigBee converter other document for more information as following links: http://ftp.icpdas.com/pub/cd/usbcd/napdos/zigbee/zigbee_conv erter/ ZB-2550/ZB-2551 Series User Manual Ver1.3, Feb /2011 ---5...
-
Page 6: Pin Assignment
1.2 Pin Assignment ZB-2550/ZB-2551 Series ZB-2550/ZB-2551 Series User Manual Ver1.3, Feb /2011 ---6... -
Page 7: Specifications
EMS Protection ESD, Surge, EFT Required Supply +10 V ~ +30 V Voltage Power Consumption 0.5 W 2 W (max) 0.5 W 2 W (max) Connection 5-Pin 5.08 mm Removable Terminal Block ZB-2550/ZB-2551 Series User Manual Ver1.3, Feb /2011 ---7... -
Page 8: Block Diagram
Temperature Storage -40 °C ~ +80 °C Temperature Relative Humidity 5 ~ 95% RH, non-condensing 1.4 Block Diagram The Normal and T-version of ZB-2550/ZB-2551 Series: The P-version and PA-version of ZB-2550/ZB-2551 series. ZB-2550/ZB-2551 Series User Manual Ver1.3, Feb /2011 ---8... -
Page 9: Wire Connection
1.5 Wire Connection Serial Port - RS-232 ZB-2550 Series Controller RS-232 (Female) CA-0915 ZB-2551 Series Remote I/O RS-232 (Male) CA-0910N ZB-2550/ZB-2551 Series User Manual Ver1.3, Feb /2011 ---9... - Page 10 Serial Port - RS-485 ZB-2550 Series Controller RS-485 (DATA+, DATA-) DATA+ DATA- +10~+30 V ZB-2551 Series Remote I/O RS-485 (DATA+, DATA-) DATA+ DATA- +10~+30 V ZB-2550/ZB-2551 Series User Manual Ver1.3, Feb /2011 ---10...
-
Page 11: Quick Start
After configuration is complete, adjust the switch to the position then re-boot (power off/on) the module. 2. When the following screen is displayed, click on the Module button. Please scroll the bar to switch the COM port number. ZB-2550/ZB-2551 Series User Manual Ver1.3, Feb /2011 ---11... - Page 12 3. Click the ZB-255x series buttons to read the configuration. 4. Please select the Configuration item on the utility. ZB-2550/ZB-2551 Series User Manual Ver1.3, Feb /2011 ---12...
- Page 13 6. After ZigBee module configuration has been successfully established. Now, adjust the switch to the RUN position then re-boot (power off/on) the module. Leverage the power of your data. Make it work for you. ZB-2550/ZB-2551 Series User Manual Ver1.3, Feb /2011 ---13...
- Page 14 Note : A Work Zigbee Network - Running on the same PAN ID RF Channel Network Survival Detecting Time ZB-2551 series will connect with Parent (ZB-2550 series) periodically to confirm the survival of network. If it detects unsuccessfully, and it process initialize network again to find a new parent.
-
Page 15: Default Settings
1.7 Default Settings Default settings for the ZB-2550 series are as follows： ： ： ： ZB Node ID： 0x0000 ZB PAN ID： 0xFF00 ZB Channel (RF Channel)： 0x00 ZBSET Data Format： 115200,n,8,1 Operating Mode： Transparent Default settings for the ZB-2551 series are as follows： ： ： ：... -
Page 16: Applications
Operating Mode Transparent Mode (Original data will be broken down into many small data, each small data is 50 Byte) Transparent mode lets you use the ZB-2550/ZB-2551 series module like a router. (Maximum original data size is 200 bytes. Original data must not more than 200 bytes, e.g. - Page 17 Operating Mode Modbus is the most suitable. (Maximum original data size is 200 byte. Original data must not more than 200 bytes, e.g. “$01M” = 4 Bytes) ZB-2550/ZB-2551 Series User Manual Ver1.3, Feb /2011 ---17...
- Page 18 Device, such as barcode reader. :ADDRxxx , ADDR Syntax, is your ZB-2551 series Node ID. (Maximum original data size is 200 byte. Original data must not more than 200 byte, e.g. “xxx” = 3 Byte) ZB-2550/ZB-2551 Series User Manual Ver1.3, Feb /2011 ---18...
- Page 19 200 byte, e.g. “$01M” = 4 Byte) ZB-2060 ZB-2510 $02M Node ID:0001 Node ID:FF01 RS-232 $02M $02M ZB-2550 $02M RS-485 ZB-2510 I-7000/M-7000 ZB-2551 Node ID:FF02 ZB-2060 Node ID:0002 Node ID:0002 Node ID:0003 ZB-2550/ZB-2551 Series User Manual Ver1.3, Feb /2011 ---19...
-
Page 20: Application Example
ZigBee Wireless Networks, such as the ICPDAS I-7000/M-7000/I-87k remote I/O modules, you can use the ZB-2551 series (slave) to connect to these I/O modules and use the ZB-2550 series (host) to connect to your controller or PC. If original data size is less than 50 Byte most of the time, this Mode is the most suitable. -
Page 21: Operating Mode 2 : Modbus Mode
ZigBee Wireless Networks, such as the ICPDAS I-7000/M-7000/I-87k remote I/O modules, you can use the ZB-2551 series (slave) to connect to these I/O modules and use the ZB-2550 series (host) to connect to your controller or PC. If original data size is greater than 50 byte most of the time, this Mode is the most suitable. -
Page 22: Operating Mode 3 : Addressable Mode
This mode is similar to that used in ICPDAS I-752N products. Syntax: :ADDRxxx Delimiter character ADDR The ADDR is your ZB-2551(P) Node ID xxx is your original data ZB-2550/ZB-2551 Series User Manual Ver1.3, Feb /2011 ---22... -
Page 23: Operating Mode 4 : Zbio Mode
If the zigbee network is multi-layers and the transmission using DCON or Modbus protocol. The mode will catch the address like addressble mode to be index to send the correct device. The other device won’t receive unless message. ZB-2550/ZB-2551 Series User Manual Ver1.3, Feb /2011 ---23... -
Page 24: Zigbee Network Groups
2.3 ZigBee Network Groups ZB-2570/ZB-2550 Series ZB-2551/ZB-2571/ZB-2510/ ZB-DIO/ZB-AIO series ZB-2550/ZB-2551 Series User Manual Ver1.3, Feb /2011 ---24... - Page 25 50 Byte most of the time, Operating Mode Modbus is the most suitable. If you want to transmit more than 200 Byte one data or high-speed rate, please order an advanced ZigBee Converter ZB-2570 and ZB-2571. ZB-2550/ZB-2551 Series User Manual Ver1.3, Feb /2011 ---25...
-
Page 26: Appendix
1 km(Max.) (LOS) ZB-100R/ZB-100T Supported Supports Max. Slaves (Host) CE/FCC,FCC ID Certification Technical Support If you have problems about using the ZB-2000 series modules, please contact ICP DAS Product Support. Email: Service@icpdas.com ZB-2550/ZB-2551 Series User Manual Ver1.3, Feb /2011 ---26...
