About this product
Control Elements
flocculant pump
8
2
3a
3b
Fig. 2: Control Elements: Metering System DULCODOS
Comfort (with all options and Beta
The following are used as control elements:
1. Controller keys and display
2. Flow meter (by scale)
3a. Stroke adjustment dial of the metering pump (con‐
cealed with the alpha pump)
3b. Stroke adjustment dial of the metering pump (con‐
cealed with the alpha pump)
4. Ball valve, in-line probe housing, outlet side
(Not shown Multifunctional valve
in figure)
Fig. 3: Design with flocculant pump (1.) (DF4a)
1
4
metering pumps)
®
A1725
® Pool
1.
A2082
